Halogen and Antimony Free. "Green" Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
PPAP Capable (Note 4)
Part Number
DDC124EU
DDC144EU
DDC114YU
DDC123JU
DDC114EU
DDC143ZU
DDC115EU
R1 (NOM)
22kΩ
47kΩ
10kΩ
2.2kΩ
10kΩ
4.7kΩ
100kΩ
R2 (NOM)
22kΩ
47kΩ
47kΩ
47kΩ
10kΩ
47kΩ
100kΩ
Mechanical Data
Case: SOT363
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
Weight: 0.006 grams (Approximate)
Part Number
DDC113TU
DDC143TU
DDC114TU
R1 Only
1kΩ
4.7kΩ
10kΩ
SOT363
6
5
R
1
R
2
R
2
R
1
4
6
5
R
1
R
1
4
1
2
3
1
2
3
R1, R2
Top View
Device Schematic
R1 Only
Ordering Information
(Notes 4 & 5)
Product
DDC124EU-7-F
DDC124EUQ-7-F
DDC144EU-7-F
DDC114YU-7-F
DDC114YUQ-7-F
DDC114YUQ-13-F
DDC123JU-7-F
DDC114EU-7-F
DDC114EUQ-7-F
DDC114EUQ-13-F
DDC113TU-7-F
DDC143TU-7-F
DDC114TU-7-F
DDC114TUQ-7-F
DDC143ZU-7-F
DDC115EU-7-F
Notes:
Compliance
AEC-Q101
Automotive
AEC-Q101
AEC-Q101
Automotive
Automotive
AEC-Q101
AEC-Q101
Automotive
Automotive
AEC-Q101
AEC-Q101
AEC-Q101
Automotive
AEC-Q101
AEC-Q101
Marking
N17
N17
N20
N14
N14
N14
N06
N13
N13
N13
N01
N07
N12
N12
N03
N02
Reel Size (inches)
7
7
7
7
7
13
7
7
7
13
7
7
7
7
7
7
Tape Width (mm)
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
Quantity per Reel
3,000
3,000
3,000
3,000
3,000
10,000
3,000
3,000
3,000
10,000
3,000
3,000
3,000
3,000
3,000
3,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the
same, except where specified. For more information, please refer to http://www.diodes.com/quality/product_compliance_definitions/.
5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
