ECS-1612MV-240-CN-TR datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> ECS-1612MV-240-CN-TR

ECS-1612MV-240-CN-TR: Description24MHz±25ppm,-40°C ~ 85°C,-,Surface Mount,4-SMD, MULTI-VOLT 1.6 ~ 3.63V L x 0.047" W (1.60mm x 1.20mm x 0.7mm); CategoryPassive components oscillator; File Size578KB，2 Pages; ManufacturerECS; Websitehttp://www.ecsxtal.com/

Download Datasheet Parametric View All

ECS-1612MV-240-CN-TR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ECS-1612MV-240-CN-TR	-	-	View	Buy Now

ECS-1612MV-240-CN-TR Overview

24MHz±25ppm,-40°C ~ 85°C,-,Surface Mount,4-SMD, MULTI-VOLT 1.6 ~ 3.63V L x 0.047" W (1.60mm x 1.20mm x 0.7mm)

ECS-1612MV-240-CN-TR Parametric

Parameter Name	Attribute value
package instruction	SMD, 4 PIN
Reach Compliance Code	compliant
Factory Lead Time	14 weeks
Other features	STANDBY; TRI-STATE; ENABLE/DISABLE FUNCTION; TR
maximum descent time	4.5 ns
Frequency Adjustment - Mechanical	NO
frequency stability	25%
Installation features	SURFACE MOUNT
Nominal operating frequency	24 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	HCMOS
Output load	15 pF
physical size	1.6mm x 1.2mm x 0.6mm
longest rise time	4.5 ns
Maximum supply voltage	3.63 V
Minimum supply voltage	1.6 V
surface mount	YES
maximum symmetry	45/55 %
Base Number Matches	1

Preview

Download Datasheet

View All

ECS-1612MV

SMD Multi Volt Crystal Oscillator

The ECS-1612MV is a miniature SMD HCMOS Oscillator with Multi

Volt capability of 1.6 ~ 3.6 V. The 1.6 x 1.2x 0.7 mm ceramic

package is ideal for Low Power/Portable, Industrial and IOT.

applications.

ECS-1612MV SMD XO

Request a Sample

OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS

PARAMETERS

Frequency Range

* Frequency Stability

Supply Voltage

Output Load

Output voltage Level

Rise & Fall time

Start Up Time

Phase Jitter

Duty Cycle

Standby Current

Operating Temp*

Storage Temp

CONDITIONS

MIN

ECS-1612MV

TYP

MAX

UNITS

•

1.6 x 1.2 mm Footprint

Extended Temp Range

RoHS Compliant

Wide Supply Voltage

Low Jitter

DIMENSIONS (mm)

80.000

MHz

-40 ~ +85°C (CN Opt)

±25

ppm

1.6

3.63

CMOS

OL:

0.4 Max./V

OH:

-0.4 Min.V DC

10%V

dd –

90%V

4.5

1.8V

12 KHz to 5 MHz

@ ½ V

45/55

µA

N Option

-40

+85

°C

-40

+105

°C

3.000

CURRENT CONSUMPTION mA

FREQ.

+1.8V

+2.5V

+3.3V

~ 20 MHz

2 Typ./2.5 Max.

2 Typ./3 Max.

3 Typ./4 Max.

~ 50 MHz

2.5 Typ./ 3 Max.

2.5 Typ./ 4 Max.

4 Typ./ 5 Max.

~ 80 MHz

3 Typ./4 Max.

3 Typ./5 Max.

5 Typ./7 Max.

PAD CONNECTIONS

Stand-by

Gnd

Output

Vdd

Tri State Function

Pin 1

Output

0.7 * Vdd

Min

Active

0.3 * Vdd

Max

High-Z

Figure 1)

Top, Side, and Bottom views

Figure 2)

Suggested Land Pattern

PART NUMBERING GUIDE: Example ECS-1612MV-250-CN-TR

ECS

SERIES

FREQUENCY

ABBREVIATION

250 = 25.000 MHz

See Developed

Frequencies Pg.2

* STABILITY

TEMP RANGE -

PACKAGING

1612MV

1.6 x 1.2 mm

Multi Volt Oscillator

A= ±100 ppm

B = ±50 ppm

G = ±30 ppm

C= ±25 ppm

D = ±20 ppm

M = -20 ~ +70°C

N = -40 ~ +85°C

-TR =

Tape

& Reel

3K/Reel

* Frequency Stability includes initial tolerance, temperature, supply voltage & load change reflow frequency shift, and aging.

Rev.2018

15351 West 109

Street

Lenexa, KS 66219

Phone: 913.782.7787

Fax: 913.782.6991

www.ecsxtal.com
