XAD
CONNECTOR
ラジアル
2.5mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC (AWG #20)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10m
Ω
max.
After environmental testing/20m
Ω
max.
• Insulation resistance: 1,000M
Ω
min.
• Withstanding voltage: 1,000V AC/minute
• Applicable wire: AWG #28 to #20
• Applicable PC board thickness: 1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Double-row construction connector with
secure locking device.
• Secure locking device
• Solder crack preventive material
• Polarizing boss
• Mis-insertion preventive design
Standards ––––––––––––––––––––––
1
Certified LR20812
2
R9851219
0
Recognized E60389
PC board layout (viewed from component side) and Assembly layout
Top entry type
With a boss
Even number
circuits
Odd number
circuits
＋0.1
φ0.9
0
11.5
Without a boss
φ0.9
＋0.1
0
Circuit No.1
＋0.1
φ1.1
0
2.5
±0.05
2.5
±0.05
Even number circuits
Odd number circuits
Circuit No.1
A
±0.05
1.7
±0.05
1.8
±0.05
2.5
±0.05
2.5
±0.05
A
±0.05
Side entry type
2.8
±0.05
19.9
Even number
circuits
2.5
±0.05
A
±0.05
φ0.9
＋0.1
0
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline.
Contact JST for details.
2.5
±0.05
Odd number
circuits
13.5
Circuit No.1
2.0
±0.05
7.6
±0.05
13.8
1
XAD CONNECTOR
Contact
Model No.
SXA-01T-P0.6
SXA-001T-P0.6
SXA-001T-P0.6L
6.5
3.1
1.3
1.6
Applicable wire
mm
2
AWG#
0.22∼0.5
0.08∼0.33
0.13∼0.33
24∼20
28∼22
26∼22
Insulation O.D.
(
mm
)
1.5∼1.9
0.8∼1.9
1.3∼1.7
Q'ty / reel
8,000
8,000
8,000
1.9
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
Note: 1. SXA-001T-P0.6L is low-insertion force type contact, for easier
insertion/withdrawal, which would be less resistant to the vibration.
The crimp height is different from the standard contact.
2. Contact JST for gold-plated products.
Applicator
Dies
Contact
SXA-001T-P0.6
Crimping
machine Crimp applicator
MKS-L
AP-K2N
*MKS-SC
MKS-L
*MKS-SC
2.3
Crimp applicator with dies
Contact
SXA-01T-P0.6
Crimping
machine Crimp applicator
AP-K2N
MKS-L
*MKS-SC
Applicator
Dies
SC/SXA/M-01-06
Crimp applicator with dies
APLSC SXA/M01-06
MK/SXA/M-001-06 APLMK SXA/M001-06
SC/SXA/M-001-06 APLSC SXA/M001-06
MK/SXA-001-06L APLMK SXA001-06L
SC/SXA-001-06L
APLSC SXA001-06L
MK/SXA/M-01-06 APLMK SXA/M01-06
SXA-001T-P0.6L
Note:*Strip-crimp applicator
Housing
Circuits
Model No.
Dimensions (mm)
A
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
32.5
35.0
37.5
40.0
42.5
47.5
(8 to 16 circuits)
B
A
2.5
Circuit No.1
mark
3.6
11.4
B
14.7
17.2
19.7
22.2
24.7
27.2
29.7
32.2
34.7
37.2
39.7
42.2
44.7
47.2
49.7
54.7
Q'ty / bag
1,000
1,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
500
500
250
250
8
10
12
14
12.0
6.8
XADRP-08V
XADRP-10V
XADRP-12V
XADRP-14V
XADRP-16V
XADRP-18V
XADRP-20V
XADRP-22V
XADRP-24V
XADRP-26V
XADRP-28V
XADRP-30V
XADRP-32V
XADRP-34V
XADRP-36V
XADRP-40V
Material
H JST 12
16
18
20
22
24
(18 to 40 circuits)
B
A
2.5
Circuit No.1 mark
3.6
11.4
26
28
30
32
34
6.8
H JST 30
12.0
36
40
PA 66, UL94V-0, natural (white)
RoHS compliance
Note: Contact JST if retainers are required.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
XADRP-08V-oo-
(blank)…natural (white)
K…black R…red E…blue O…orange M…green
L…lemon yellow PK…pink
2
XAD CONNECTOR
Shrouded header
Top entry type
(8 to 16 circuits)
B
A
2.5
10.1
Circuit No.1
Mark
2.5
Model No.
Circuits
8
10
10.1
Top entry type
Without a boss
With a boss
B08B-XADSS-N B08B-XADSS-N-A
B10B-XADSS-N B10B-XADSS-N-A
B12B-XADSS-N B12B-XADSS-N-A
B14B-XADSS-N B14B-XADSS-N-A
B16B-XADSS-N B16B-XADSS-N-A
B18B-XADSS-N B18B-XADSS-N-A
B20B-XADSS-N B20B-XADSS-N-A
B22B-XADSS-N B22B-XADSS-N-A
B24B-XADSS-N B24B-XADSS-N-A
B26B-XADSS-N B26B-XADSS-N-A
B28B-XADSS-N B28B-XADSS-N-A
B30B-XADSS-N B30B-XADSS-N-A
B32B-XADSS-N B32B-XADSS-N-A
B34B-XADSS-N B34B-XADSS-N-A
B36B-XADSS-N B36B-XADSS-N-A
B40B-XADSS-N B40B-XADSS-N-A
Dimensions (mm)
Q'ty / box
Top Side
Side entry type A
B entry entry
type type
S08B-XADSS-N
S10B-XADSS-N
S12B-XADSS-N
S14B-XADSS-N
S16B-XADSS-N
S18B-XADSS-N
S20B-XADSS-N
−
−
S26B-XADSS-N
−
−
−
−
−
−
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
32.5
35.0
37.5
40.0
42.5
47.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
32.5
35.0
37.5
40.0
42.5
45.0
47.5
50.0
55.0
200
200
200
150
150
150
100
100
100
100
100
50
50
50
50
50
270
234
198
180
162
144
126
H
JST 12
12
1.5
（3.5）
14
16
1.8
φ0.9
φ0.6
1.7
18
20
(18 to 40 circuits)
B
A
2.5
Circuit No.1
Mark
10.1
2.5
22
24
26
−
−
108
（3.5） 10.1
1.5
H JST 22
28
30
32
1.8
φ0.9
−
−
−
−
−
−
φ0.6
1.7
34
36
40
Side entry type
(8 to 16 circuits)
2.5
2.7
B
A
3.5
12.1
2.5
Material and Finish
Pin: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Glass-filled PA 66, UL94V-0, natural (white)
RoHS compliance
This product displays (LF)(SN) on a label.
Note: Contact JST for the headers with gold-plated pins.
9.9
16.2
10.3
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
B08B-XADSS-N-
S…natural (white)
K…black R…red E…blue O…orange M…green
L…lemon yellow PK…pink
（3.4）
φ0.6
2.5
9.9
(18 to 26 circuits)
B
A
2.5
2.7
3.5
2.5
12.1
16.2
10.3
2.5
（3.4）
φ0.6
9.9
9.9
3
