LTC3415EUHF#PBF datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> LTC3415EUHF#PBF

LTC3415EUHF#PBF: DescriptionOutput current: 7A Switch operating frequency: 1.5MHz Output type: Adjustable Number of output voltage channels: 1 Function type: Step-Down Output configuration: Positive; CategoryPower/power management The power supply circuit; File Size582KB，24 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html; Environmental Compliance

Download Datasheet Parametric View All

LTC3415EUHF#PBF Overview

Output current: 7A Switch operating frequency: 1.5MHz Output type: Adjustable Number of output voltage channels: 1 Function type: Step-Down Output configuration: Positive

LTC3415EUHF#PBF Parametric

Parameter Name	Attribute value
Brand Name	Linear Technology
Is it Rohs certified?	conform to
Maker	Linear ( ADI )
Parts packaging code	QFN
package instruction	HVQCCN, LCC38,.2X.28,20
Contacts	38
Manufacturer packaging code	UHF
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
control mode	CURRENT-MODE
Maximum input voltage	5.5 V
Minimum input voltage	2.375 V
Nominal input voltage	3.3 V
JESD-30 code	R-PQCC-N38
JESD-609 code	e3
length	7 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	38
Maximum operating temperature	85 °C
Minimum operating temperature
Maximum output current	15 A
Package body material	PLASTIC/EPOXY
encapsulated code	HVQCCN
Encapsulate equivalent code	LCC38,.2X.28,20
Package shape	RECTANGULAR
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	0.8 mm
surface mount	YES
Switch configuration	BUCK
Maximum switching frequency	1700 kHz
technology	CMOS
Temperature level	OTHER
Terminal surface	Matte Tin (Sn)
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	30
width	5 mm

Preview

Download Datasheet
