DE1B3RA101KJ4BP01F datasheet, PDF

Datasheet> All Categories > Passive components> Into ceramics capacitors> DE1B3RA101KJ4BP01F

DE1B3RA101KJ4BP01F: DescriptionCapacitance: 100pF Accuracy: ±10% Rated voltage: 300VAC; CategoryPassive components Into ceramics capacitors; File Size2MB，73 Pages; ManufacturerMurata; Websitehttps://www.murata.com

Download Datasheet Parametric View All

DE1B3RA101KJ4BP01F Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DE1B3RA101KJ4BP01F	-	-	View	Buy Now

DE1B3RA101KJ4BP01F Overview

Capacitance: 100pF Accuracy: ±10% Rated voltage: 300VAC

DE1B3RA101KJ4BP01F Parametric

Parameter Name	Attribute value
Foot distance (mm)	10
Capacitance	100pF
Accuracy	±10%
Rated voltage	300VAC

Preview

Download Datasheet

View All

C85E.pdf

Sep.14,2018

Lead Type Disc Ceramic Capacitors

(Safety Standard Certiﬁed)

Resin Molding SMD Type Ceramic Capacitors

(Safety Standard Certiﬁed)

!Note

• Please read rating and

!CAUTION

(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.

• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.

C85E.pdf

Sep.14,2018

EU RoHS Compliant

• All the products in this catalog comply

with EU RoHS.

• EU RoHS is "the European Directive

2011/65/EU on the Restriction of the

Use of Certain Hazardous Substances in

Electrical and Electronic Equipment."

•

For

more details, please refer to our web

page, "Murata's Approach for EU RoHS"

(https://www.murata.com/en-eu/support/

compliance/rohs).

!Note

• Please read rating and

!CAUTION

(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.

• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.

C85E.pdf

Sep.14,2018

Contents

Product speciﬁcations are as of

August

2018

Part Numbering

Safety Standard Certiﬁed Resin Molding SMD Type Ceramic Capacitors for General Purpose

Type EA (Reinforced Insulation) -Class X1, Y1- (Recommend)

Type EA Speciﬁcations and Test Methods

Type EA Complemant of Test Methods

Type EA Packing

Type EA

!Caution

Type EA Notice

Safety Standard Certiﬁed Lead Type Disc Ceramic Capacitors for General Purpose

Type SA: AC400V (Basic Insulation) -Class X1, Y2- (Recommend)

Type RA: AC500V (Reinforced Insulation) -Class X1, Y1- (Recommend)

p10

p11

p14

p15

p17

p19

p23

p26

p29

p33

p35

p39

p42

p45

p49

p53

p55

p58

Type SA: AC400V / RA: AC500V Speciﬁcations and Test Methods

Type SA: AC250V or AC300V (Basic Insulation) -Class X1, Y2- (Recommend)

Type RA: AC250V or AC300V (Reinforced Insulation) -Class X1, Y1- (Recommend)

Type SA: AC250V or AC300V / RA: AC250V or AC300V Speciﬁcations and Test Methods

Type RB (Reinforced Insulation) -Class X1, Y1- (Recommend)

Type RB: X1: AC760V Speciﬁcations and Test Methods

Type KY (Basic Insulation) -Class X1, Y2-

Type KX New Small Size (Reinforced Insulation) -Class X1, Y1-

Type KY/KX Speciﬁcations and Test Methods

Characteristics Data (Typical Example)

Packaging

!Caution

Notice

Safety Standard Certiﬁed Lead Type Disc Ceramic Capacitors for Automotive

Type KJ -Class X1, Y2- (For Automotive Use/AC Line Filter of PHEV/EV Charger)

Type KJ Speciﬁcations and Test Methods

Characteristics Data (Typical Example)

Packaging

!Caution

Notice

Lead Type Disc Ceramic Capacitors (Safety Certiﬁed)/

Resin Molding SMD Type Ceramic Capacitors (Safety Certiﬁed) ISO9000 Certiﬁcations

Please check the MURATA website (https://www.murata.com/)

if you cannot ﬁnd a part number in this catalog.

p59

p60

p64

p65

p66

p69

p70

!Note

• Please read rating and

!CAUTION

(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.

• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.

C85E.pdf

Sep.14,2018

Part Numbering

Safety Standard Certiﬁed Resin Molding SMD Type Ceramic Capacitors for General Purpose

(Part Number)

EA 102 M 86

AH01

6Capacitance

Tolerance

Contents

IEC60384-14 ClassX1, Y1

Code

7Case

Size

3Temperature

Characteristics

Code

Temperature

Characteristics

Cap. Change

or Temp. Coeff.

±10%

+20%, -55%

Temperature

Range

-25 to +85°C

Code

8Packaging

Code

Packaging

ø330mm Embossed Taping

Dimensions

8.0 x 6.0mm

Capacitance Tolerance

±10%

±20%

1Product

2Series

Category

Product

Code

Outline

Safety Standard

Certiﬁed

+350 to -1000ppm/°C +20 to +85°C

4Rated

Voltage/Safety Standard Certiﬁed Type

Code

Rated Voltage

X1: AC440V (r.m.s.), Y1: AC250V (r.m.s.)

or X1: AC440V (r.m.s.), Y1: AC300V (r.m.s.)

(Safety Standard Certiﬁed Type EA)

9Individual

Speciﬁcation Code

Expressed by four ﬁgures.

5Capacitance

Expressed by three ﬁgures. The unit is pico-farad (pF). The ﬁrst

and second ﬁgures are signiﬁcant digits, and the third ﬁgure

expresses the number of zeros that follow the two numbers.

!Note

• Please read rating and

!CAUTION

(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.

• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.

C85E.pdf

Sep.14,2018

Safety Standard Certiﬁed Lead Type Disc Ceramic Capacitors for General Purpose

(Part Number)

KY 102 M N3

6Capacitance

Tolerance

Contents

IEC60384-14 Class X1, Y1

IEC60384-14 Class X1, Y2

Code

7Lead

Style

Dimensions (mm)

Code

3Temperature

Characteristics

Code

Temperature

Characteristics

Cap. Change

or Temp. Coeff.

±10%

+20%, -55%

+30%, -80%

+350 to -1000ppm/°C +20 to +85°C

-25 to +85°C

Temperature

Range

B2/J2

B3/J3

B4/J4

4Rated

Voltage/Safety Standard Certiﬁed Type

Code

Rated Voltage

X1: AC440V (r.m.s.), Y1: AC250V (r.m.s.)

or X1: AC440V (r.m.s.), Y1: AC300V (r.m.s.)

or X1: AC500V (r.m.s.), Y1: AC500V (r.m.s.)

(Safety Standard Certiﬁed Type RA)

X1: AC760V (r.m.s.), Y1: AC500V (r.m.s.)

(Safety Standard Certiﬁed Type RB)

X1: AC440V (r.m.s.), Y1: AC250V (r.m.s.)

or X1: AC440V (r.m.s.), Y1: AC300V (r.m.s.)

(Safety Standard Certiﬁed Type KX)

X1: AC300V (r.m.s.), Y2: AC250V (r.m.s.)

or X1: AC300V (r.m.s.), Y2: AC300V (r.m.s.)

or X1: AC440V (r.m.s.), Y2: AC400V (r.m.s.)

(Safety Standard Certiﬁed Type SA)

X1: AC250V (r.m.s.), Y2: AC250V (r.m.s.)

or X1: AC250V (r.m.s.), Y2: AC300V (r.m.s.)

(Safety Standard Certiﬁed Type KY)

8Packaging

Code

9Individual

Speciﬁcation Code

For part number that cannot be identiﬁed without "Individual

Speciﬁcation," it is added at the end of part number, expressed by

three-digit alphanumerics.

:Halogen-free

Compatible Product

Packaging

Ammo Pack Taping

Bulk

Lead Style

Lead

Spacing

Vertical Crimp

Long

7.5

Vertical Crimp

Short

7.5

Vertical Crimp

Taping

7.5

ø0.6±0.05

12.7

25.4

ø0.6±0.05

—

ø0.6±0.05

—

Lead

Diameter

Pitch of

Components

Capacitance Tolerance

±5%

±10%

±20%

8 9 :

1Product

2Series
