SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
BXA
Series
•
105℃ 1,000~2,000Hrs assured.
Solvent-
proof
•Vertical SMD type.
•Low Impedance.
•For STB, Satellite Radio, Computer Server.
•RoHS
compliant.
•Halogen-free
capacitors are also available.
SPECIFICATIONS
Item
Rated Voltage Range
Operating Temperature Range
Capacitance Tolerance
Leakage Current
MVY
Low Imp.
BXA
Characteristics
6.3 ~ 50 V
DC
-55 ~ +105℃
±20%(M)
(at 20℃, 120Hz)
I=0.01CV(μ or 3 μ whichever is greater.
A)
A,
Where, I:Max. Leakage current(μ C:Nominal capacitance(μ V:Rated voltage(V
DC
)
A),
F),
(at 20℃, 2 minutes)
Rated Voltage(V
DC
)
SIZE
6.3
0.24
0.28
6.3
3
5
10
2
4
10
0.20
0.24
16
2
4
16
0.16
0.20
25
0.14
0.16
25
2
3
35
0.12
0.14
35
2
3
50
0.12
0.12
50
2
3
(at 120Hz)
(at 20℃, 120Hz)
Dissipation Factor( T a n δ
)
D56~H63
H10~J10
Rated voltage(V
DC
)
Z(-25℃)/Z(20℃)
Z(-55℃)/Z(20℃)
Temperature Characteristics
(Max. Impedance ratio)
The following specifications shall be satisfied when the capacitors are restored to 20℃ after the rated
voltage is applied with the following conditions.
Load Life
Ø4~Ø6.3 : 105℃, 1,000 hours, Ø8 & Ø10 : 105℃, 2,000 hours.
Capacitance change ≦ ±25% of the initial value
Tanδ
Leakage current
≦ 200% of the initial specified value
≦ The initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing
them for 1000 hours at 105℃ without voltage applied. The rated voltage shall be applied to the
capacitors for a minimum of 30 minutes, at least 24 hours and not more than 48 hours before
the measurements.
Shelf Life
Capacitance change ≦ ±25% of the initial value
Tanδ
Leakage current
Others
≦ 200% of the initial specified value
≦ The initial specified value
BXA
Series
Satisfied characteristics KS C IEC 60384-4
PART NUMBERING SYSTEM
RATED RIPPLE CURRENT MULTIPLIERS
Frequency Multipliers
BXA
16
VC
100 M
F60
TP
With tape
Case code
Capacitance tolerance(±20%)
Nominal capacitance code
(ex.
0.1㎌:R1, 1.0㎌:1, 4.7㎌:4R7, 10㎌:10
)
Lead type
Rated voltage
Series name
Freq.(㎐)
Cap.(㎌)
2.2 ~ 4.7
10 ~ 100
220 ~ 470
1,000 ~ 1,500
120
0.35
0.40
0.50
0.60
1K
0.70
0.75
0.85
0.87
10K
0.90
0.90
0.94
0.95
100K
1.00
1.00
1.00
1.00
59
SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
DIMENSIONS OF BXA Series
DIMENSIONS
MARKING
Unit
(mm)
Note 1 : L±0.5 for 8×6.3(H63), 10×10(J10)
Note 2 : 4×5.3(D56), 5×5.3(E56) is excluded symbol mark.
Note 3 : 6.3WV is marked by 6V.
Case code Ø D
D56
4
E56
5
F60
6.3
6.3
Recommended solder land on PC board
F80
H63
8
H10
8
J10
10
L
A
5.3 4.3
5.3 5.3
5.7 6.6
7.7 6.6
6.3 8.3
10 8.3
10 10.3
B
4.3
5.3
6.6
6.6
8.3
8.3
10.3
C
5.1
5.9
7.2
7.2
9.0
9.0
11.0
W
0.5~0.8
0.5~0.8
0.5~0.8
0.5~0.8
0.5~0.8
0.7~1.1
0.7~1.1
P
1.0
1.4
1.9
1.9
2.3
3.1
4.5
a
1.0
1.4
1.9
1.9
2.3
3.1
4.5
b
2.6
3.0
3.5
3.5
4.5
4.2
4.4
c
1.6
1.6
1.6
1.6
1.6
2.2
2.2
: Solder land on PC board
RATINGS OF BXA Series
㎌
V
DC
2.2
4.7
10
22
33
47
68
100
220
330
470
1,000
1,500
D56 2.10
E56
F60
F60
F60
F80
0.90
0.44
0.44
0.44
0.34
80
150
230
230
230
280
450
450
670
D56 2.10
E56
F60
F60
F60
F80
0.90
0.44
0.44
0.44
0.34
80
150
230
230
230
280
450
450
670
E56 0.90 150
F60
F60
F60
F60
F80
0.44 230
0.44 230
0.44 230
0.44 230
0.34 280
D56 2.10
E56
F60
F60
F60
F80
0.90
0.44
0.44
0.44
0.34
80
150
230
230
230
280
300
450
450
670
D56 2.10
80
E56 0.90 150
E56 0.90 150
F60
F60
F80
0.44 230
0.44 230
0.34 280
6.3
10
16
25
35
50
D56 4.80
E56
F60
F60
F80
H63
3.00
2.00
2.00
30
50
70
70
1.00 170
0.90 180
H10 0.44 230
H10 0.44 230
J10
0.30 350
H63 0.32
H10 0.17
H10 0.17
J10
0.09
H10 0.17 450
H10 0.17 450
J10
0.09 670
H10 0.17
H10 0.17
J10
0.09
H10 0.17 450
H10 0.17 450
H10 0.17
H10 0.17
J10
0.09
Rated Ripple Current (mArms/105℃, 100kHz)
Impedance (Ωmax./20℃, 100kHz)
Case code
60
stm32/stm8
