SMD POWER INDUCTORS(NR SERIES H TYPE/S TYPE/V TYPE)
SMD POWER INDUCTORS (NR SERIES H TYPE/ S TYPE/ V TYPE)
AEC-Q200 Grade 3 (we conduct the evaluation at the test condition of Grade 3.)
*Operating environment Temp:-40½85℃
■PART
NUMBER
*Operating Temp. :
-40½125℃（Including self-generated heat）
REFLOW
AEC-Q200
REFLOW
AEC-Q200
N
R S
①
4
0
②
1
8
T △
③
Series name
1
0 0
④
M
⑤
D
G V
⑥
V
⑦
△＝Blank space
①Series name
Code
NRH
NRS
NRV
③Packaging
Code
T△
④Nominal inductance
Code
（example）
2R2
100
101
※R＝Decimal point
⑤Inductance tolerance
Code
M
N
⑥Special code
⑦Internal code
Code
V
Packaging
Taping
Coating resin specification
Nominal inductance［μ
H½
2.2
10
100
INDUCTORS POWER INDUCTORS
／
44
②Dimensions（L×W×H）
Code
2010
2012
2410
2412
3010
3012
3015
4010
4012
4018
5010
5012
5014
5020
5024
5030
5040
6010
6012
6014
6020
6028
6045
8030
8040
Dimensions（L×W×H）［mm½
2.0×2.0×1.0
2.0×2.0×1.2
2.4×2.4×1.0
2.4×2.4×1.2
3.0×3.0×1.0
3.0×3.0×1.2
3.0×3.0×1.5
4.0×4.0×1.0
4.0×4.0×1.2
4.0×4.0×1.8
4.9×4.9×1.0
4.9×4.9×1.2
4.9×4.9×1.4
4.9×4.9×2.0
4.9×4.9×2.4
4.9×4.9×3.0
4.9×4.9×4.0
6.0×6.0×1.0
6.0×6.0×1.2
6.0×6.0×1.4
6.0×6.0×2.0
6.0×6.0×2.8
6.0×6.0×4.5
8.0×8.0×3.0
8.0×8.0×4.0
Inductance tolerance
±20％
±30％
Internal code
Inductor for Industrial and Automotive
