BV03C
Order Code: BV03C
Transient Voltage Suppressor
Features
IEC 61000-4-2(ESD)±15KV(air),
±8KV(contact)
150Watts peak pulse power (tp=8/20μS)
Ultra low capacitance: 1.5pF maximum
Low clamping voltage
Moisture sensitivity level：Level 1
Weight 5.0 mg
Small package: SOD-323
Version: A1 2016-08-15
Exterior
SOD-323
Application Information
xDSL secondary
Ethernet
Agency Approvals
Icon
Description
Compliance with 2011/65/EU
Compliance withIEC61249-2-21:2003
Mean lead free
Part Number and Electrical Parameter
Part
Number
BV03C
I
DRM
@V
DRM
μ
A
V
BR
①
@I
R
V
MIN
4
mA
1
V
Vc@Ipp
②
A
1
V
MAX
5.15
Vc@Ipp
②
A
8
MAX
13.9
C
O
③
pF
MAX
1.5
V
3
MAX
20
Absolute maximum ratings measured at T= 25ºC RH = 45%-75% (unless otherwise noted).
①
V
BR
is measured at I
R
=1mA
②
Surge Waveform: 8/20
μ
S.
③
Off-state capacitance is measured in V
DC
=0V,V
RMS
=1V,f=1MHz
Part Numbering System
BV
(1)
03
(2)
C
(3)
Mark
(1) Bencent Transient Voltage Suppressor
(2)
Stand-state
Voltage,e.g.03=3V
(3)
Bidirectional polar
B006U2G
CC
0909
0909
CC: Part Number
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications
B42LC
1/4
www.bencent.com.cn
BV03C
Order Code: BV03C
Transient Voltage Suppressor
V-I Curve
Parameters
V
C
I
pp
V
DRM
V
BR
I
DRM
I
R
Ppp
Definition
Clamping Voltage
Surge Waveform 8/20μs
Stand-off Voltage
Breakdown Voltage
Reverse Leakage Current
Test Current
Peak Pulse Power Dissipation
Version: A1 2016-08-15
I
PP
V
C
V
BR
V
DRM
I
R
I
DRM
I
DRM
I
R
V
DRM
V
BR
V
C
V
I
PP
Thermal Considerations
symbol
T
J
T
S
Parameter
Operating Junction Temperature Range
Storage Temperature Range
Value
-55 to +150
-55 to +150
Unit
℃
℃
Environmental Characteristics
Testing items
High Temperature Reverse Bias Test
High Temperature Life Test
High-low Temperature Cycle Test
High Temperature &High Humidity Test
Pressure Cooker Test
Resistance of Soldering Heat
Technical standards
Temperature: 150±3℃ Bias=80%V
DRM
Time:168H
Temperature: 150℃
Time:168H
Temperature: From -40℃ to125℃
Dwell time
：30min,10cycles
Temperature: 85℃Humidity:85%
Time:168H
Temperature: 121℃，2atm. Humidity:100%
Time:24H
Temperature: 260±5℃
Time of dip soldering：10s，3times
Note: The above testing items can be specified by customer’s special request
2/4
www.bencent.com.cn
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications
BV03C
Order Code: BV03C
Transient Voltage Suppressor
Product Dimensions
REF
A
A1
b
c
D
E
H
L
Q1
mm
1.17(max)
0.10(max)
0.34±0.10
0.17±0.08
1.66±0.14
1.28±0.17
2.5±0.2
0.28±0.18
0.25±0.15
inch
0.046(max)
0.004(max)
0.013±0.0039
0.007±0.0032
0.065±0.0055
0.050±0.0066
0.098±0.0079
0.011±0.0071
0.010±0.0059
Version: A1 2016-08-15
Recommended Soldering Pad
A
REF
A
mm
3.20
1.08
1.06
0.54
inch
0.126
0.043
0.042
0.021
D
C
B
B
C
D
Reflow Profile
Reflow Condition
Temperature Min
Pre Heat
Temperature Max
Time
（min
to max）
Pb-Free
assembly
150°C
200°C
60 – 180 secs
T
L
Temperature
T
S(max)
Ramp-up
T
P
T
P
Critical Zone
T
L
to T
P
Average ramp up rate（Liquidus）Tamp（T
L
）
3°C/s max
to peak
T
S
(max) to T
L
- Ramp-up Rate
Reflow
- Temperature (T
L
) (Liquidus)
- Temperature (T
L
)
3°C/s max
217°C
60 – 150 secs
260+0/-5 °C
30secs
6°C/s max
8 min max.
260°C
T
L
Ramp-down
Preheat
Peak Temperature (T
P
)
Time within 5°C of actual peak Temperature
(T
P
)
Ramp-down Rate
Time 25°C to peak Temperature (T
P
)
Do not exceed
3/4
T
S(min)
T
S
25
time to peak temperature
Time
www.bencent.com.cn
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications
BV03C
Order Code: BV03C
Transient Voltage Suppressor
Package
Reel
Information
REF
A
B
d
D
D1
D2
E
F
P
P0
P1
W
W1
mm
1.46+/-0.1
3.10+/-0.3
1.50+/-0.1
178+/-1.0
55+/-3
13+/-0.5
1.75+/-0.1
3.5+/-0.2
4.0+/-0.2
4.0+/-0.2
2.0+/-0.2
8.0+/-0.2
12.3+/-1.0
inch
0.057+/-0.004
0.122+/-0.012
0.059+/-0.004
7.008+/-0.039
2.165+/-0.118
0.512+/-0.020
0.069+/-0.004
0.138+/-0.008
0.157+/-0.008
0.157+/-0.008
0.079+/-0.008
0.315+/-0.008
0.484+/-0.039
Version: A1 2016-08-15
OUTLINE
TAPING
REEL
(PCS)
3,000
PER CARTON
(PCS)
90,000
REEL
DIAMETERS
(mm)
177
CARTON SIZE(mm)
L
390
W
370
H
220
4/4
www.bencent.com.cn
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications
