MOSPEC
Schottky Barrier rectifiers
Using the Schottky Barrier principle with a Refractory metal capable of
high temperature operation metal. proprietary barrier technology allows for
reliable operation up to 150℃ junction temperature. Typical application are
in switching Mode Power Supplies such as adaptors, DC/DC converters
free- wheeling and polarity protection diodes.
＊Low
Forward Voltage.
＊Low
Switching noise.
＊High
Current Capacity
＊Guarantee
Reverse Avalanche.
＊Guard-Ring
for Stress Protection.
＊Low
Power Loss & High efficiency.
＊150℃
Operating Junction Temperature
＊Low
Stored Charge Majority Carrier Conduction.
＊Plastic
Material used Carries Underwriters Laboratory
Flammability Classification 94V-O
SR2100L
SCHOTTKY BARRIER
RECTIFIERS
2.0 AMPERES
100 VOLTS
DO-201AD
＊In
compliance with EU RoHs 2002/95/EC directives
The marking is indicated by part no. with. “M”. ex:SR2100LM
MAXIMUM RATINGS
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectifier Forward Current
Non-Repetitive Peak Surge Current (Surge
applied at rate load conditions halfware, single
phase, 60Hz)
Operating and Storage Junction Temperature
Range
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
SR2100L
100
70
2.0
50
-65 to +150
Unit
V
V
A
A
℃
DIM
A
B
MILLIMETERS
MIN
5.00
25.40
8.50
1.20
MAX
5.60
---
9.50
1.30
T
J
, T
STG
ELECTRICAL CHARACTERISTICS
Characteristic
Maximum Instantaneous Forward Voltage
( I
F
=0.1 Amp T
C
= 25℃)
( I
F
=1.0 Amp T
C
= 25℃)
( I
F
=2.0 Amp T
C
= 25℃)
Maximum Instantaneous Reverse Current
( Rated DC Voltage, T
C
= 25℃ )
( Rated DC Voltage, T
C
= 125℃ )
Maximum Thermal Resistance Junction to case
Typical Junction Capacitance
( Reverse Voltage of 4 volts & f=1 MHz )
Symbol
Min.
---
---
---
SR2100L
Typ.
0.36
0.65
0.79
0.01
10
55
Max.
0.38
0.70
0.82
Unit
C
D
V
F
V
CASE---
Transfer molded
plastic
OLARITY---
Cathode indicated
polarity band
I
R
R
θJC
C
P
mA
℃/W
P
F
80
SR2100L
FIG-1 FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD RECTIFIED CURRENT (Amp.)
NSTANTANEOUS FORWARD CURRENT (Amp.)
FIG-2 TYPICAL FORWARD CHARACTERISITICS
T
J
=125℃
T
J
=75℃
T
J
=25℃
CASE TEMPERATURE (℃)
FORWARD VOLTAGE (Volts)
FIG-3 TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT (mA.)
FIG-4 TYPICAL JUNCTION CAPACITANCE
T
j
=125
o
T
j
=75 c
o
T
j
=25 c
o
REVERSE VOLTAGE (Volts)
JUNCTION CAPACITANCE (
P
F)
REVERSE VOLTAGE (Volts)
FIG-5 PEAK FORWARD SURGE CURRENT
CURRENT (Amp.)
PEAK FORWARD SURGE
NUMBER OF CYCLES AT 60 Hz
7M-A
