SLW252012P Series
Wire Wound SMD Power Inductor
◆
Features
Pb
2
3
4
5
◆
Applications
3
4
5
6
7
◆
Dimensions
Recommended Land Pattern
Unit:mm
Series
SLW252012P
A
2.5±0.2
B
2.0±0.2
C
1.2Max.
D
1.5±0.2
E
0.80±0.2
F
0.80±0.2
a Typ.
0.80
b Typ.
0.85
c Typ.
2.0
Rev.01
Page 1 of 3
www.Sunltech.com
±
：
± ：
；
；
：
× × × ×：
；
；
。
；
；
；
、
、
、
、
、
、
、
1
2
Smart phone
Mobile devices with multifunction such as
adding color TV and camera
Flat-screen TVs, blue-ray disc recorders,
set top boxes
Notebooks, desktop computers, servers,
graphic cards
Portable gaming devices, personal navigation
systems, personal multimedia devices
Automotive systems;
Telecomm base stations
；
；
。
、
、
、
、
、
1
Magnetic-resin shielded construction reduces
buzz noise to ultra-low levels
Metallization on ferrite core results in excellent
shock resistance and damage-free durability
Closed magnetic circuit design reduces leakage
Small and low profile inductor;
Take up less PCB real estate and save more
power
◆
Lead Free Part Numbering
SLW
(1)
(1)
(2)
(3)
(4)
252012 P
(2) (3)
2R2 M S
T
(4) (5) (6) (7)
Series Type
Dimension L W H(2.5 2.0 1.2mm)
Material Code
Inductance 2R2=2.2μH
100=10µH 101=100µH
(5) Inductance Tolerance M= 20%, N= 30%
(6) Company Code
(7) Packaging Tape Carrier Package
SLW252012P Series
◆
Electrical Characteristics
1) Operating temperature range Including self-heating) -40 ~ +125
2) Storage temperature range (packaging conditions): -10 ~+40 and RH 70% (Max.)
◆
Construction and material
◆
REFLOW-PROFILE
Rev.01
Page 2 of 3
℃
℃ ℃
℃ ：
（
www.Sunltech.com
SLW252012P Series
◆
Specification
Inductance
Part Number
@100KHz,1V
(µH)
DC Resistance(m )
DCR
Typ.
Max.
Saturation Current
Isat
Min(A)
Typ. (A)
SLW252012P Series
SLW252012PR24MST
SLW252012PR33MST
SLW252012PR47MST
SLW252012PR68MST
SLW252012P1R0MST
SLW252012P1R5MST
SLW252012P2R2MST
SLW252012P3R3MST
SLW252012P4R7MST
SLW252012P6R8MST
SLW252012P100MST
0.24±20%
0.33±20%
0.47±20%
0.68±20%
1.0±20%
1.5±20%
2.2±20%
3.3±20%
4.7±20%
6.8±20%
10±20%
19
23
29
36
48
60
100
136
225
305
450
23
28
35
43
54
72
120
163
260
366
500
7.00
6.00
5.10
3.90
3.70
2.90
2.60
1.70
1.60
1.15
1.10
8.50
7.00
5.80
4.50
4.30
3.50
3.00
2.10
1.90
1.35
1.35
4.05
3.7
3.45
3.15
3.0
2.4
1.9
1.8
1.25
0.95
0.85
4.70
4.30
4.00
3.60
3.40
2.80
2.15
2.05
1.45
1.10
1.00
◆
Standard Packing Quantity：2000 pcs/reel
：
◆
TYPICAL ELECTRICAL CHARACTERISTICS
SLW252012P Series
Temperature vs.DC Current Characteristics
Inductance vs.DC Current Characteristics
SLW252012P
Rev.01
Page 3 of 3
△
1
2
3
4
Note
All test data is referenced to 20°C ambient;
Rated current: Isat or Irms, whichever is smaller;
Isat: DC current at which the inductance drops approximate 30% from its value without current;
Irms: DC current that causes the temperature rise ( T =40°C) from 20°C ambient.
Ω
Heat Rating Current
Irms
Min(A)
Typ. (A)
：
：
：
：
◆
◆
◆
◆
www.Sunltech.com
