1N6643U Overview

0.1 A, 50 V, SILICON, SIGNAL DIODE

Preview

Download Datasheet

View All

• 1N6638US,1N6642US, 1N6643US AVAILABLE IN

JAN, JANTX, JANTXV

AND

JANS

PER MIL-PRF-19500/578

• 1N6638U,1N6642U, 1N6643U AVAILABLE IN

JAN, JANTX, JANTXV

AND

JANS

PER MIL-PRF-19500/578

• SWITCHING DIODES

• NON-CAVITY GLASS PACKAGE

• METALLURGICALLY BONDED

1N6638U & US

1N6642U & US

1N6643U & US

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +175°C

Operating Current: 300 mA

Derating: 4.6 mA/°C Above TEC = + 110°C

Surge Current: I

FSM

= 2.5A, half sine wave, Pw = 8.3ms

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified.

V BR

TYPES

@ IR

=100 µA

V RWM

V F1

IFM

=10 mA

(Pulsed)

V (pk)

1N6638U & US

1N6642U & US

1N6643U & US

150

100

V (pk)

125

V dc

0.8

1.0

V dc

1.1

1.2

(Pulsed)

200

100

V F2

@ I F2

tfr

=50 mA

trr

IR = 10 mA

IF = 10 mA

IREC = 1 mA

4.5

5.0

6.0

DIM

MILLIMETERS

MIN

MAX

1.78

2.16

0.48

0.71

4.19

4.95

0.08MIN.

INCHES

MIN MAX

0.070 0.085

0.019 0.028

0.165 0.195

0.003MIN.

FIGURE 1

DESIGN DATA

CASE:

D-5D, Hermetically sealed glass

case, per MIL-PRF- 19500/578

LEAD FINISH:

Tin / Lead

I R1

TYPES

= 20 V

nA dc

I R2

@V R

= V RWM

µA dc

I R3

V R = 20 V

TA = 150°C

µA dc

I R4

V R = V RWM

TA = 150°C

µA dc

C T1

VR=

C T2

VR=

1.5V

THERMAL RESISTANCE: (R

OJEC):

50 °C/W maximum at L = 0

THERMAL IMPEDANCE: (Z

OJX): 25

°C/W maximum

POLARITY:

Cathode end is banded.

1N6638U & US

1N6642U & US

1N6643U & US

0.5

100

160

2.5

5.0

2.0

2.8

MOUNTING SURFACE SELECTION:

The Axial Coefficient of Expansion

(COE) of this device is approximately

+ 4PPM / °C. The COE of the Mounting

Surface System should be selected to

provide a suitable match with this

device.

22 COREY STREET, MELROSE, MASSACHUSETTS 02176

PHONE (781) 665-1071

FAX (781) 665-7379

WEBSITE: http://www.cdi-diodes.com

E-mail: mail@cdi-diodes.com
