RADIAL LEAD ALUMINUM ELECTROLYTIC CAPACITORS
PX
PX
SERIES
105℃ Standard
・
Load Life : 105℃ 1000∼2000 hours.
RoHS
compliance
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
−55∼＋105℃
6.3∼100Vdc
−40∼＋105℃
160∼400Vdc
±20%(20℃, 120Hz)
−25∼＋105℃
450Vdc
6.3∼100Vdc
I＝0.01CV
or 3μA whichever is greater.
(After 2 minutes application of rated voltage)
160∼450Vdc
CV≦1000
CV＞1000
I=0.04CV＋100
μ
A (1minute)
Leakage Current(MAX)
I=0.1CV＋40
μ
A (1minute)
I=0.03CV＋15
μ
A (5minutes)
I=0.02CV＋25
μ
A (5minutes)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(Vdc)
Rated Voltage
6.3 10 16 25 35 50 63 100 160 200 250 350 400 450
(Vdc)
tanδ
0.28 0.24 0.20 0.16 0.14 0.12 0.10 0.08 0.20 0.20 0.20 0.25 0.25 0.25
(20℃, 120Hz)
Dissipation Factor(MAX)
(tanδ)
When capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with increase of every 1000μF.
After applying rated voltage with rated ripple current for specified time at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Rated Voltage
6.3
(Vdc)
Z(−25℃)/Z(20℃) 5
Z(−40℃)/Z(20℃) 10
10
4
8
Within ±25％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
16
3
6
25
2
4
35
2
3
50
2
3
Case Size
φD≦8
φD≧10
Life Time
(hrs)
1000
2000
Low Temperature Stability
Impedance Ratio(MAX)
63 100 160 200 250 350 400 450
2
3
2
3
3
4
3
4
4
8
6
8
6
10
7
−
(120Hz)
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
◆DIMENSIONS
SLEEVE(PET)
(mm)
φd
60 50） 120 500
（
0.50
0.65
0.80
0.80
0.80
1.00
1.00
1.00
1.00
1.00
1.20
1.20
1.20
1.10
1.05
1k 10k≦
1.30
1.30
1.30
1.15
1.10
1.50
1.50
1.50
1.20
1.15
0.47∼1μF
2.2∼4.7μF
Coefficient
10∼47μF
100∼1000μF
2200∼33000μF
L＋ MAX
α
15MIN
4MIN
φD＋0.5MAX
◆OPTION
Code
PET Sleeve
φD
φd
F
α
Ｅ
ＦC
10 12.5
0.5
0.6
2.0
2.5
3.5
5.0
Vdc≦100：
α=1.5
Vdc≧160：
α=2.0
5
6.3
8
16
0.8
7.5
2.0
18
◆PART NUMBER
□□□
Rated Voltage
PX
Series
□□□□□
Capacitance
Ｍ
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
F
±0.5
RADIAL LEAD ALUMINUM ELECTROLYTIC CAPACITORS
PX
◆STANDARD SIZE
Size φD×L(mm), Rated Ripple Current (mA r.m.s./105℃, 120Hz)
Vdc
6.3
Size
Ripple
Size
10
Ripple
Size
16
Ripple
Size
25
Ripple
Size
35
Ripple
Size
50
Ripple
Size
63
Ripple
Cap(μF)
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
680
1000
2200
3300
4700
6800
10000
15000
22000
33000
Vdc
Cap(μF)
5×11
5×11
5×11
5×11
5×11
5×11
5×11
5×11
5×11
5×11
6.3×11
6.3×11
6.3×11
8×11.5
10×16
10×20
96
160
210
275
285
460
775
985
5×11
5×11
6.3×11
6.3×11
8×11.5
8×11.5
10×16
10×20
105
165
235
295
430
500
860
5×11
6.3×11
6.3×11
8×11.5
8×11.5
80
130
220
270
375
480
5×11
5×11
6.3×11
8×11.5
8×11.5
69
84
135
240
335
440
5×11
5×11
6.3×11
8×11.5
64
77
100
170
300
5×11
5×11
6.3×11
8×11.5
10
20
25
32
47
70
94
115
200
5×11
5×11
6.3×11
6.3×11
8×11.5
10×16
10×20
48
80
100
140
230
390
540
10×12.5 360
10×16
10×20
470
600
10×12.5 400
10×12.5 525
10×16
10×20
16×25
16×25
760
865
12.5×20 700
12.5×25 800
16×25
1200
10×12.5 630
10×16
740
12.5×20 980
12.5×25 1060
10×12.5 640
10×20
1050 12.5×20 1090
16×25
16×25
1500
1370 16×31.5 1600 18×31.5 1400
1680 18×35.5 1780
1100 12.5×20 1300
12.5×20 1150 12.5×20 1350 12.5×25 1650
12.5×25 1480
16×25
1700
16×25
16×25
1700
16×25
1800 16×35.5 1870
1900 16×35.5 1910 18×35.5 1920
1950 16×31.5 1950 18×35.5 2050
16×31.5 2090 16×35.5 2090 18×35.5 2070
18×31.5 2280 18×35.5 2180
18×40
100
Size
Ripple
2350
160
Size
Ripple
200
Size
Ripple
250
Size
Ripple
350
Size
Ripple
400
Size
Ripple
450
Size
Ripple
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
680
1000
5×11
5×11
5×11
5×11
5×11
6.3×11
8×11.5
8×11.5
10×16
15
21
30
35
60
98
140
185
290
6.3×11
8×11.5
10×12.5
10×16
10×20
43
77
92
125
150
6.3×11
6.3×11
8×11.5
10×16
10×20
10×20
16×25
36
40
57
105
140
195
340
6.3×11
6.3×11
6.3×11
6.3×11
8×11.5
10×12.5
10×16
10×20
8
16
30
30
45
90
105
140
6.3×11
6.3×11
6.3×11
8×11.5
8×11.5
10×16
8
16
25
30
45
95
6.3×11
8×11.5
8×11.5
10×12.5
10×16
16
31
34
42
64
6.3×11
8×11.5
10×12.5
10×12.5
10×20
15
20
33
35
37
12.5×20 175
12.5×25 220
16×25
260
12.5×20 140
16×25
16×25
170
200
12.5×25 100
16×25
125
12.5×20 190
16×25
310
16×31.5 155
18×40
200
12.5×25 320
16×31.5 410
18×31.5 570
18×40
855
18×31.5 370
18×35.5 310
12.5×20 560
12.5×25 690
16×25
880
16×35.5 580
18×40
675
18×35.5 485
16×31.5 900
18×35.5 985
