CHIP ALUMINUM ELECTROLYTIC CAPACITORS
TGV
TGV
SERIES
UPGRADE
Load Life : 125℃ 3000∼5000 hours Low ESR
・
ESR standard after endurance test.（φ8 φ10）
・
・
AEC-Q200.
RoHS
compliance
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
−40∼＋125℃
16∼50Vdc
±20％
（20℃，
120Hz）
I＝0.01CV
or 3μA whichever is greater.(After 2 minutes application of rated voltage)
Leakage Current(MAX)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
圧(Vdc)
Rated Voltage
（Vdc)
Dissipation Factor(MAX)
φ8∼φ10
φ12.5∼φ18
16
0.23
0.18
25
0.18
0.16
35
0.16
0.14
50
0.14
0.12
（20℃，
120Hz）
(tanδ)
When rated capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with Increase of every 1000 μF.
After applying rated voltage for specified time at 125℃, the capacitors shall meet the following requirements.
Capacitance Change
Endurance
Dissipation Factor
Leakage Current
Within ±30％ of the initial value.
Not more than 300％ of the specified value.
Not more than the specified value.
Case Size
φD≦10
φD≧12.5
LifeTime
（hrs）
3000
5000
ESR standard after endurance test
（125℃, 2000 hrs with rated voltage applied）
20℃
−40℃
16∼35Vdc
8×10.5 10×10.5
0.6
0.4
3.5
4.5
(Ω/100kHz)
Low Temperature Stability
Impedance Ratio(MAX)
Rated Voltage
16
(Vdc)
Z
（−40℃） （20℃） 3
/Z
25
3
35
3
50
3
（120Hz）
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
◆MARKING
100k≦
1.00
1.00
1.00
〈φ8,φ10〉
Lot No.
Capacitance
Series
※
Rated voltage code
Negative
※Voltage code
120
0.45
0.50
0.60
1k
0.75
0.80
0.85
10k
0.90
0.95
0.95
〈φ12.5∼φ18〉
Lot No.
Capacitance
AA
2200
1C TG
33μF
Coefficient
47∼100μF
220∼3300μF
AA
470
CTG
Series
※
Rated voltage code
Negative
◆PART NUMBER
□□□
Rated Voltage
Rated voltage
（Vdc)
16
C
1C
25
E
1E
35
V
1V
50
H
1H
TGV
Series
□□□□□
Capacitance
Ｍ
Capacitance Tolerance
□□□
Option
D×L
Case Size
Voltage
code
φD≦10
φD≧12.5
CHIP ALUMINUM ELECTROLYTIC CAPACITORS
TGV
(mm)
◆DIMENSIONS
L＋ MAX
α
A
1±0.2
φD
L
A1 B1
C
W1
P
K
α
C
8 10.5 8.3 8.3 2.9 0.8∼1.1 3.1 0.5Max 0
φD＋0.5MAX
10 10.5 10.3 10.3 3.2 0.8∼1.1 4.5 0.5Max 0
B
1±0.2
P
12.5 13.5 13 13 4.9 0.8∼1.1 4.5 0.7±0.4 0.5
12.5 16 13 13 4.9 0.8∼1.1 4.5 0.7±0.4 0.5
16 16.5 17 17
6 1.0∼1.6 6.8 0.7±0.4 0.5
6 1.0∼1.6 6.8 0.7±0.4 0.5
7 1.0∼1.6 6.8 0.7±0.4 0.5
7 1.0∼1.6 6.8 0.7±0.4 0.5
16 21.5 17 17
18 16.5 19 19
18 21.5 19 19
0.3MAX
W
1
◆STANDARD SIZE
Vdc
Cap
(μF)
100
220
330
470
16
820
1000
1500
1800
2200
3300
100
220
330
25
680
820
1200
1500
2200
2700
Size
(φDXL)
8×10.5
8×10.5
10×10.5
10×10.5
12.5×13.5
12.5×16
16×16.5
18×16.5
16×21.5
18×21.5
8×10.5
8×10.5
10×10.5
10×10.5
12.5×13.5
12.5×16
16×16.5
18×16.5
16×21.5
18×21.5
Ripple
350
350
550
550
850
1000
1200
1300
1650
1800
350
350
550
550
850
1000
1200
1300
1650
1800
Size φD×L ㎜） Rated Ripple Current
（ ,
（mA r.m.s./125℃, 100kHz） ESR（Ω MAX/100kHz）
,
ESR
20℃
0.150
0.150
0.120
0.120
0.092
0.074
0.066
0.064
0.041
0.039
0.150
0.150
0.120
0.120
0.092
0.074
0.066
0.064
0.041
0.039
−40℃
3.0
3.0
2.0
2.0
1.1
0.9
0.7
0.6
0.4
0.3
3.0
3.0
2.0
2.0
1.1
0.9
0.7
0.6
0.4
0.3
50
35
Vdc
Cap
(μF)
47
100
220
470
560
820
1000
1500
1800
33
47
100
360
510
680
820
1200
Size
(φDXL)
8×10.5
8×10.5
10×10.5
10×10.5
12.5×13.5
12.5×16
16×16.5
18×16.5
16×21.5
18×21.5
8×10.5
8×10.5
10×10.5
10×10.5
12.5×16
16×16.5
18×16.5
16×21.5
18×21.5
Ripple
350
350
550
550
850
1000
1200
1300
1650
1800
300
300
500
500
900
950
1000
1300
1450
ESR
20℃
0.150
0.150
0.120
0.120
0.092
0.074
0.066
0.064
0.041
0.039
0.340
0.340
0.220
0.220
0.150
0.120
0.110
0.073
0.066
−40℃
3.0
3.0
2.0
2.0
1.1
0.9
0.7
0.6
0.4
0.3
6.7
6.7
4.4
4.4
3.0
2.0
1.8
1.3
1.1
C
K
PCB Design
