TC7SB3157CFU
CMOS Digital Integrated Circuits Silicon Monolithic
TC7SB3157CFU
1. Functional Description
•
Single 1-of-2 Multiplexer/Demultiplexer
2. General
The TC7SB3157CFU is a high-speed CMOS single 1-of-2 multiplexer/demultiplexer. The low ON resistance of
the switch allows connections to be made with minimal propagation delay time.
This device is 1 to 2 multiplexer/demultiplexer controlled by the select input (S). The A input is connected to B1
or B2 output based on the selection of Control input (S).
All inputs are equipped with protection circuits against static discharge.
3. Features
(1)
(2)
(3)
(4)
(5)
Operating voltage: V
CC
= 1.65 to 5.5 V
ON capacitance: C
I/O
= 15 pF Switch On (typ.) @V
CC
= 5.0 V
ON resistance: R
ON
= 4
Ω
(typ.) @V
CC
= 4.5 V, V
IS
= 0 V
ESD performance: Machine model
≥ ±200
V, Human body model
≥ ±2000
V
Package: US6
4. Packaging and Pin Assignment
1: B2
2: GND
3: B1
4: A
5: V
CC
6: S
US6
5. Marking
Start of commercial production
©2016 Toshiba Corporation
1
2010-03
2016-08-01
Rev.4.0
TC7SB3157CFU
6. Block Diagram
7. Principle of Operation
7.1. Truth Table
Inputs
S
L
H
Function
A port = B1 port
A port = B2 port
8. Absolute Maximum Ratings (Note)
Characteristics
Supply voltage
Input voltage (S)
Switch I/O voltage
Clamp diode current
Switch I/O current
Power dissipation
V
CC
/ground current
Storage temperature
Symbol
V
CC
V
IN
V
S
I
IK
I
S
P
D
I
CC
/I
GND
T
stg
Note
Rating
-0.5 to 7.0
-0.5 to 7.0
-0.5 to V
CC
+0.5
-50
50
200
±100
-65 to 150
mW
mA
mA
Unit
V
Note:
Exceeding any of the absolute maximum ratings, even briefly, lead to deterioration in IC performance or even
destruction.
Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings and the operating ranges.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test report
and estimated failure rate, etc).
9. Operating Ranges (Note)
Characteristics
Supply voltage
Input voltage (S)
Switch I/O voltage
Operating temperature
Input rise time
Input fall time
Symbol
V
CC
V
IN
V
S
T
opr
dt/dv
dt/dv
Note
Rating
1.65 to 5.5
0 to 5.5
0 to V
CC
-40 to 85
0 to 10
0 to 10
ns/V
Unit
V
Note:
The operating ranges must be maintained to ensure the normal operation of the device.
Unused inputs and bus inputs must be tied to either V
CC
or GND.
©2016 Toshiba Corporation
2
2016-08-01
Rev.4.0
TC7SB3157CFU
10. Electrical Characteristics
10.1. DC Characteristics (Unless otherwise specified, T
a
= -40 to 85
)
Characteristics
High-level input voltage
Low-level input voltage
Input leakage current
Switch OFF-state
leakage current
ON-resistance
Symbol
V
IH
V
IL
I
IN
I
SZ
R
ON
Note
Test Condition
V
CC
(V)
1.65 to 1.95
2.3 to 5.5
1.65 to 1.95
2.3 to 5.5
V
IN
= 0 to 5.5 V
B1, B2 = 0 to V
CC
(Note 1), V
IS
= 0 V, I
IS
= 30 mA
(Note 2)
V
IS
= 2.4 V, I
IS
= 30 mA
V
IS
= 4.5 V, I
IS
= 30 mA
V
IS
= 0 V, I
IS
= 24 mA
V
IS
= 3.0 V, I
IS
= 24 mA
V
IS
= 0 V, I
IS
= 8 mA
V
IS
= 2.3 V, I
IS
= 8 mA
V
IS
= 0 V, I
IS
= 4 mA
V
IS
= 1.65 V, I
IS
= 4 mA
Quiescent supply
current
I
CC
∆I
CC
V
IN
= V
CC
or GND, I
OUT
= 0 A
V
IN
= V
CC
- 0.6 V
1.65 to 5.5
1.65 to 5.5
4.5
4.5
4.5
3.0
3.0
2.3
2.3
1.65
1.65
5.5
5.5
Min
0.8
×
V
CC
0.7
×
V
CC
Typ.
4
5
6
5
7
6
9
8
15
Max
0.2
×
V
CC
0.3
×
V
CC
±1.0
±10
7
12
10
9
14
12
18
20
30
10
50
µA
µA
µA
Ω
V
Unit
V
Note 1: All typical values are at T
a
= 25
.
Note 2: Measured by the voltage drop between A and B pins at the indicated current through the switch. On-resistance
is determined by the lower of the voltages on the two (A or B) pins.
10.2. AC Characteristics (Unless otherwise specified, T
a
= -40 to 85
)
Characteristics
3-state output enable time
Symbol
t
PZL
/
t
PZH
Note
Test Condition
See Fig. 10.2.1, 10.2.2,
Table 10.2.1.
V
CC
(V)
5.0
±
0.5
3.3
±
0.3
2.5
±
0.2
1.8
±
0.15
3-state output disable time
t
PLZ
/
t
PHZ
See Fig. 10.2.1, 10.2.2,
Table 10.2.1.
5.0
±
0.5
3.3
±
0.3
2.5
±
0.2
1.8
±
0.15
Min
Max
4
6
8
16
4.5
7
9
16
ns
Unit
ns
©2016 Toshiba Corporation
3
2016-08-01
Rev.4.0
TC7SB3157CFU
10.3. Capacitive Characteristics (Unless otherwise specified, T
a
= 25
)
Characteristics
Input capacitance
Switch terminal OFF-capacitance (B port)
Switch terminal ON-capacitance (A port)
Switch terminal ON-capacitance (B port)
Symbol
C
IN
C
I/O
Note
Test Condition
V
CC
(V)
5.0
5.0
5.0
5.0
Typ.
4
5
15
15
Unit
pF
(Note 1) V
IN
= 0 V
V
I/O
= 0 V
Note 1: Parameter guaranteed by design.
Fig. 10.2.1 AC Test Circuit
Table 10.2.1 Parameter for AC Test Circuit
Parameter
t
PLZ
, t
PZL
t
PHZ
, t
PZH
Switch
2
×
V
CC
GND
Fig. 10.2.2 AC Waveform t
PLZ
, t
PHZ
, t
PZL
, t
PZH
©2016 Toshiba Corporation
4
2016-08-01
Rev.4.0
TC7SB3157CFU
11. Rise and Fall Time (t
r
/t
f
)
The t
r(out)
and t
f(out)
values of the output signals are affected by the CR time constant of the input, which consists
of the switch terminal capacitance (C
I/O
) and the on-resistance (R
ON
) of the input.
In practice, the t
r(out)
and t
f(out)
values are also affected by the circuit's capacitance and resistance components
other than the capacitance of TC7SB3157CFU
The t
r
/t
f(out)
values can be approximated as follows.
(Figure 11.1, Table 11.1 shows the test circuit.)
t
r
/t
f(out)
(approx) = - (C
I/O
+ C
L
)
(R
DRIVE
+ R
ON
)
ln (((V
OH
- V
OL
) - V
M
) / (V
OH
- V
OL
))
Where, R
DRIVE
is the output impedance of the previous-stage circuit.
Calculation example:
t
r(out)
(approx) = - (15 + 15) E - 12
(120 + 4)
ln (((4.5 - 0) - 2.25) / (4.5 - 0))
≈
2.6 ns
Calculation conditions:
V
CC
= 4.5 V, C
L
= 15 pF, R
DRIVE
= 120
Ω
(output impedance of the previous IC), V
M
= 2.25 V (V
CC
/2)
Output of the previous IC = digital (i.e., high-level voltage = V
CC
, low-level voltage = GND)
Fig. 11.1 Calculation Circuit
Table 11.1 Calculation Circuit
Characteristics
V
M
V
CC
= 5.0
±
0.5 V
V
CC
/2
©2016 Toshiba Corporation
5
2016-08-01
Rev.4.0
