BAS40-00-G to BAS40-06-G
www.vishay.com
Vishay Semiconductors
Small Signal Schottky Diodes, Single and Dual
FEATURES
• These diodes feature very low turn-on voltage
and fast switching
• These devices are protected by a PN junction
guardring against excessive voltage, such as
electrostatic discharges
BAS40-00-G
3
BAS40-04-G
3
• AEC-Q101 qualified available
(part number on request)
• Base P/N-G3 - green, commercial grade
• Material categorization:
for definitions of compliance
www.vishay.com/doc?99912
please
see
Top View
1
2
1
2
BAS40-05-G
3
BAS40-06-G
3
MECHANICAL DATA
Case:
SOT-23
Weight:
approx. 8.1 mg
Packaging codes/options:
18/10K per 13" reel (8 mm tape), 10K/box
08/3K per 7" reel (8 mm tape), 15K/box
Top View
1
2
1
2
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
PARTS TABLE
PART
BAS40-00-G
BAS40-04-G
BAS40-05-G
BAS40-06-G
ORDERING CODE
BAS40-00-G3-08 or BAS40-00-G3-18
BAS40-04-G3-08 or BAS40-04-G3-18
BAS40-05-G3-08 or BAS40-05-G3-18
BAS40-06-G3-08 or BAS40-06-G3-18
CIRCUIT CONFIGURATION
Single
Dual serial
Common cathode
Common anode
TYPE MARKING
43G
44G
45G
46G
Tape and reel
REMARKS
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Repetitive peak reverse voltage
Forward continuous current
Surge forward current
Power dissipation
(1)
Note
(1)
Device on fiberglass substrate, see layout on next page
(1)
(1)
TEST CONDITION
SYMBOL
V
RRM
= V
RWM
= V
R
I
F
VALUE
40
200
600
200
UNIT
V
mA
mA
mW
t
p
< 1 s
I
FSM
P
tot
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
(1)
Junction temperature
Storage temperature range
Operating temperature range
Note
(1)
Device on fiberglass substrate, see layout on next page
Rev. 1.2, 13-Feb-18
Document Number: 85156
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TEST CONDITION
SYMBOL
R
thJA
T
j
T
stg
T
op
VALUE
500
125
-65 to +150
-55 to +125
UNIT
K/W
°C
°C
°C
BAS40-00-G to BAS40-06-G
www.vishay.com
Vishay Semiconductors
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Reverse breakdown voltage
Leakage current
Forward voltage
Forward voltage
(1)
Diode capacitance
Reverse recovery time
Note
(1)
Pulse test t < 300 μs
p
TEST CONDITION
I
R
= 10 μA (pulsed)
V
R
= 30 V
I
F
= 1 mA
I
F
= 40 mA
V
R
= 0 V, f = 1 MHz
I
F
= I
R
= 10 mA, i
R
= 1 mA, R
L
= 100
SYMBOL
V
(BR)
I
R
V
F
V
F
C
D
t
rr
4
MIN.
40
20
100
380
1000
5
5
TYP.
MAX.
UNIT
V
nA
mV
mV
pF
ns
LAYOUT FOR R
thJA
TEST
Thickness:
Fiberglass 1.5 mm (0.059 inches)
Copper leads 0.3 mm (0.012 inches)
7.5 (0.3)
3 (0.12)
1 (0.4)
12 (0.47)
15 (0.59)
0.8 (0.03)
2 (0.8)
1 (0.4)
2 (0.8)
5 (0.2)
1.5 (0.06)
5.1 (0.2)
17451
PACKAGE DIMENSIONS
in millimeters (inches):
SOT-23
1.15 (0.045)
2.6 (0.102)
2.35 (0.093)
0.45 (0.018)
1.43 (0.056)
1.20 (0.047)
0.35 (0.014)
0.7 (0.028)
0.95 (0.037)
0.1 (0.004) max.
0.9 (0.035)
0.9 (0.035)
3.1 (0.122)
2.8 (0.110)
0.550 ref. (0.022 ref.)
0.175 (0.007)
0.098 (0.004)
0.2 (0.008)
0.45 (0.018)
0.35 (0.014)
0.45 (0.018)
0.35 (0.014)
0.3 (0.012)
Foot print recommendation:
1 (0.039)
0.9 (0.035)
1 (0.039)
0.9 (0.035)
Document no.: 6.541-5014.01-4
Rev. 8 - Date: 23.Sept.2009
17418
Rev. 1.2, 13-Feb-18
Document Number: 85156
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
2 (0.079)
0.95 (0.037)
0° t
0.5 (0.020)
o8
°
