BTB16-800BRG

CategoryAnalog mixed-signal IC    Trigger device
File Size208KB,18 Pages
ManufacturerSTMicroelectronics
Websitehttp://www.st.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

BTB16-800BRG Online Shopping

Suppliers Part Number Price MOQ In stock
BTB16-800BRG - - View Buy Now

BTB16-800BRG Parametric

Parameter NameAttribute value
Brand NameSTMicroelectronics
Is it Rohs certified?conform to
MakerSTMicroelectronics
Parts packaging codeTO-220AB
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codenot_compliant
ECCN codeEAR99
Factory Lead Time9 weeks
Samacsys Confidence3
Samacsys StatusReleased
Samacsys PartID221709
Samacsys Pin Count3
Samacsys Part CategoryIntegrated Circuit
Samacsys Package CategoryTransistor Outline, Vertical
Samacsys Footprint NameTO-220AB
Samacsys Released Date2015-08-24 16:14:05
Is SamacsysN
Shell connectionMAIN TERMINAL 2
ConfigurationSINGLE
Critical rise rate of commutation voltage - minimum value10 V/us
Critical rise rate of minimum off-state voltage400 V/us
Maximum DC gate trigger current50 mA
Maximum DC gate trigger voltage1.3 V
Maximum holding current50 mA
JEDEC-95 codeTO-220AB
JESD-30 codeR-PSFM-T3
JESD-609 codee3
Maximum leakage current2 mA
Number of components1
Number of terminals3
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum rms on-state current16 A
Off-state repetitive peak voltage800 V
surface mountNO
Terminal surfaceMatte Tin (Sn) - annealed
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device type4 QUADRANT LOGIC LEVEL TRIAC
Base Number Matches1
T1610, T1635, T1650
BTA16, BTB16
Datasheet
Snubberless™, logic level and standard 16 A Triacs
A2
Features
Medium current Triac
Low thermal resistance with clip bonding
Low thermal resistance insulation ceramic for insulated BTA
High commutation (4Q) or very high commutation (3Q, Snubberless™)
capability
BTA series UL1557 certified (file ref: 81734)
Packages are RoHS (2002/95/EC) compliant
Insulated tab (BTA series, rated at 2500 V
RMS
)
G
A1
A2
A2
A1
G
A1
A2
G
TO-220AB
A2
TO-220AB Ins.
Applications
D²PAK
A2
A1
G
Snubberless versions (BTA/BTB...W and T1635) especially recommended for
use on inductive loads, because of their high commutation performances
On/off or phase angle function in applications such as static relays, light
dimmers and appliance motor speed controllers
Description
Available either in through-hole or surface mount packages, the BTA16, BTB16 and
T1610, T1635 and T1650 Triac series are suitable for general purpose mains power
AC switching. They can be used as ON/OFF function in applications such as static
relays, heating regulation or induction motor starting circuit. They are also
recommended for phase control operations in light dimmers and appliance motors
speed controllers.
The Snubberless™ versions (W suffix and T1610, T1635, T1650) are especially
recommended for use on inductive loads, because of their high commutation
performance.
By using an internal ceramic pad, the Snubberless™ series provide an insulated tab
(rated at 2500 V
RMS
) complying with UL standards (file reference: E81734).
Product status link
BTA16
BTB16
T1610
T1635
T1650
Product summary
I
T(RMS)
V
DRM
/V
RRM
I
GT
Snubberless™
I
GT
standard
16 A
600, 800 V
10, 35, 50 mA
25, 50 mA
DS2114
-
Rev 11
-
May 2018
For further information contact your local STMicroelectronics sales office.
www.st.com

BTB16-800BRG Related Products

BTB16-800BRG T1610-600G-TR T1635-800G-TR T1610-800G-TR
Description On-state current (It (RMS)) (Max): 16A On-state current (It (AV)) (Max): - Off-state voltage Vdrm: 800V Gate trigger voltage: 1.3V Type: Triac gate trigger Current: 10mA -
Brand Name STMicroelectronics STMicroelectronics STMicroelectronics STMicroelectronics
Parts packaging code TO-220AB D2PAK D2PAK D2PAK
package instruction FLANGE MOUNT, R-PSFM-T3 SMALL OUTLINE, R-PSSO-G2 SMALL OUTLINE, R-PSSO-G2 SMALL OUTLINE, R-PSSO-G2
Contacts 3 3 3 3
Reach Compliance Code not_compliant not_compliant not_compliant not_compliant
ECCN code EAR99 EAR99 EAR99 EAR99
Configuration SINGLE SINGLE SINGLE SINGLE
Critical rise rate of minimum off-state voltage 400 V/us 40 V/us 500 V/us 40 V/us
Maximum DC gate trigger current 50 mA 10 mA 35 mA 10 mA
Maximum DC gate trigger voltage 1.3 V 1.3 V 1.3 V 1.3 V
Maximum holding current 50 mA 15 mA 35 mA 15 mA
JESD-30 code R-PSFM-T3 R-PSSO-G2 R-PSSO-G2 R-PSSO-G2
JESD-609 code e3 e3 e3 e3
Maximum leakage current 2 mA 2 mA 2 mA 2 mA
Number of components 1 1 1 1
Number of terminals 3 2 2 2
Maximum operating temperature 125 °C 125 °C 125 °C 125 °C
Minimum operating temperature -40 °C -40 °C -40 °C -40 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form FLANGE MOUNT SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Certification status Not Qualified Not Qualified Not Qualified Not Qualified
Maximum rms on-state current 16 A 16 A 16 A 16 A
Off-state repetitive peak voltage 800 V 600 V 800 V 800 V
surface mount NO YES YES YES
Terminal surface Matte Tin (Sn) - annealed Matte Tin (Sn) - annealed Matte Tin (Sn) Matte Tin (Sn) - annealed
Terminal form THROUGH-HOLE GULL WING GULL WING GULL WING
Terminal location SINGLE SINGLE SINGLE SINGLE
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Trigger device type 4 QUADRANT LOGIC LEVEL TRIAC 4 QUADRANT LOGIC LEVEL TRIAC SNUBBERLESS TRIAC 4 QUADRANT LOGIC LEVEL TRIAC
Base Number Matches 1 1 1 1
Maker STMicroelectronics STMicroelectronics - STMicroelectronics
Factory Lead Time 9 weeks 11 weeks - 11 weeks
