ML64168-XXXTB: DescriptionMicrocontroller, 4-Bit, MROM, 0.7MHz, CMOS, PQFP80, 0.50 MM PITCH, PLASTIC, TQFP-80; CategoryMicrocontrollers and processors; File Size317KB，49 Pages; ManufacturerOKI; Websitehttp://www.oki.com

Download Datasheet Parametric Compare View All

ML64168-XXXTB Overview

Microcontroller, 4-Bit, MROM, 0.7MHz, CMOS, PQFP80, 0.50 MM PITCH, PLASTIC, TQFP-80

ML64168-XXXTB Parametric

Parameter Name	Attribute value
Maker	OKI
Parts packaging code	QFP
package instruction	TFQFP,
Contacts	80
Reach Compliance Code	unknown
Is Samacsys	N
Has ADC	YES
Other features	ALSO OPERATES AT 3V SUPPLY
Address bus width
bit size	4
maximum clock frequency	0.7 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G80
length	12 mm
Number of I/O lines	28
Number of terminals	80
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	NO
Package body material	PLASTIC/EPOXY
encapsulated code	TFQFP
Package shape	SQUARE
Package form	FLATPACK, THIN PROFILE, FINE PITCH
Certification status	Not Qualified
ROM programmability	MROM
Maximum seat height	1.2 mm
speed	0.7 MHz
Maximum supply voltage	1.7 V
Minimum supply voltage	1.25 V
Nominal supply voltage	1.5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	12 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

FEDL64168-01

Semiconductor

ML64168

GENERAL DESCRIPTION

This version: Sep. 27,1999

Previous version: Jun. 22,1999

4-Bit Microcontroller with Built-in RC Oscillation Type A/D Converter and LCD Driver

The ML64168 is a low power 4-bit microcontroller incorporating the Oki's original CPU core nX-4/30.

The ML64168 provides a minimum instruction execution time of 4.3µs (@700kHz).

The ML64168 contains 8160-byte program memory, 512-nibble data memory, three 4-bit input-output

ports, 4-bit input port, 4-bit output port, 2-channel RC oscillation type A/D converter, LCD driver for up

to 120 segments, and buzzer output port.

The ML64P168 is the one-time-programmable ROM version of ML64168, having one-time

PROM(OTP) as internal program memory. The ML64P168 is used to evaluate the software

development.

APPLICATION

The ML64168 is best suited for low power, high precision thermometers and hygrometers.

FEATURES

∙

Processing speed

Minimum instruction execution time

: 4.3

µs

@700 kHz

91.6

µs

@32.768 kHz

∙

Clock generation circuit

Low-speed clock

: 32.768 kHz crystal oscillator

High-speed clock

: 700 kHz RC oscillator ( with an external resistor )

CPU clock is selectable as Low-speed clock / High-speed clock by software.

∙

Operating voltage

: 1.5 V spec. / 3.0 V spec. ( selectable by mask option )

1.25 to 1.70 V (1.5 V spec.)

2.0 to 3.50 V (3.0 V spec.)

2.2 to 3.50 V (3.0 V spec., 1/2duty)

∙

Operating temperature

: - 40 to +85°C

∙

Memory space

Internal program memory

: 8160 bytes

Internal data memory

: 512 nibbles

∙

RC oscillation type A/D converter

: 2 channels

Time division 2-channel method

Counter A

: 1 / ( 10

4

×

8 )

×

1

Counter B

: 1 / 2

14

×

1

The information contained herein can change without notice owing to product and/or technical improvements.

Before using the product, please make sure that the information being referred to is up-to-date.

1/49
