C4530
Typical Applications
Base Stations
Test Equipment
Synthesizers
Digital Switching
OCXO
Features
Surface Mount Package
Reflow Process Compatible
AT-Cut and SC-Cut Crystal Options
Low Profile Compact Package
OCO1000, C4500
Previous Vectron Model Numbers
Frequency range
Standard frequencies
10 MHz – 160 MHz
10; 12.8; 16.384; 19.2 ; 20; 26, 30.72, 38.4, 52 MHz
Frequency stabilities
1
[AT Cut Crystal – 10 MHz to 160MHz]
Parameter
vs. operating temperature range
(Referenced to +25°C)
Parameter
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging / day
vs aging / year
vs. aging / year
Warm-up Time
Min
-100
-250
-250
Min
-500
-20
-10
-10
-300
-500
Typ
Max.
+100
+250
+250
Max.
+500
+20
+10
+10
+300
+500
3
Units
ppb
ppb
ppb
Units
ppb
ppb
ppb
ppb
ppb
ppb
minutes
Operating temp range
Ordering Code
-20 … +70°C
D107
-20 … +70°C
D257
-40 … +85°C
F257
Condition
at time of shipment, nominal EFC
V
S
± 5%
Load ± 5%
after 30 days of operation
≤
60MHz; after 30 days of operation
>60MHz; after 30 days of operation
to
±
100ppb of final frequency (1 hour reading) @
+25°C
Typ
Frequency stabilities
1
[SC Cut Crystal – 15 to 40 MHz]
Parameter
vs. operating temperature range
(Referenced to +25°C)
Min
-25
-50
Typ
Max.
+25
+50
Units
ppb
ppb
Operating temp range
-20 … +70°C
-40 … +85°C
Ordering Code
D258
F508
Parameter
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging / day
vs aging /1 Year
vs. aging / year (following Years)
Warm-up Time
Min
-200
-5.0
-5.0
-1.0
-100
-80
Typ
Max.
+200
+5.0
+5.0
+1.0
+100
+80
3
Units
ppb
ppb
ppb
ppb
ppb
ppb
minutes
Condition
at time of shipment, nominal EFC
V
S
± 5%
Load ± 5%
after 30 days of operation
after 30 days of operation
to
±
10ppb of final frequency (1 hour reading) @
+25°C
Supply voltage (Vs)
Parameter
Supply voltage [Standard]
Supply voltage [Option]
Power consumption
Min
4.75
3.135
Typ
5
3.3
Max.
5.25
3.465
2.5
1.0
Units
VDC
VDC
Watts
Watts
during warm-up
steady state @ +25°C
Condition
Ordering Code
SV050
SV033
Vectron International
·
www.vectron.com
Vectron International
Headquarters
267 Lowell Road
Hudson, New Hampshire 03051
+1-888-328-7661 tel
+1-888-329-8328 fax
Vectron International LLC.
100 Watts Street
Mount Holly Springs, PA 17065
USA
+1-717-486-3411 tel
+1-717-486-5920 fax
Vectron international GmbH & Co. KG
Landstrasse
D-74924 Neckarbischofsheim
Germany
+49-07268-801-0 tel
+49-07268-801-281 fax
v.2006-11-10 · page 1 of 5
Vectron Asia Pacific Sales Office
1F-2F, No 8 Workshop, No 308 Fenju
Road, WaiGaoQiao Free Trade Zone,
Pudong, Shanghai, P.R. China 200131
+86 21 5048 0777 tel.
+86 21 5048 1881 fax
C4530
RF output
Parameter
Signal [Standard]
Load
Signal Level (Vol)
Signal Level (Voh)
Duty cycle
Signal [Option]
Load
Output Power
Harmonics
3.7
2.4
45
Sinewave
+0
50
+2.5
+5.0
-30
Ω
dBm
dBc
Min
Typ
HCMOS
15
0.5
0.3
pF
VDC
VDC
VDC
VDC
%
Max.
Units
Condition
OCXO
Ordering Code
RFH
55
with Vs=r 5.0V and 15pF load
with Vs=3.3V and 15pF load
with Vs= 5.0V and 15pF load
with Vs=3.3V and 15pF load
@ (Voh-Vol)/2
RFS
50 Ohm load
50 Ohm load
Frequency Tuning (EFC)
Parameter
Tuning Range
Tuning Range
Linearity
Tuning Slope
Control Voltage Range
0.0
0.0
2.0
1.4
Positive
4.0
2.8
VDC
VDC
with Vs=5.0VDC
with Vs=3.3VDC
Min
±1.0
±3.0
Typ
Max.
Fixed OCXO; No adjust
±1.75
±2.5
±5.0
±8
5
Units
ppm
ppm
%
Condition
with SC Cut Crystal
with AT Cut Crystal
Ordering Code
0
1
1
5
Reference Voltage Output (Vref)
Parameter
Reference Voltage
Min
3.85
2.7
Typ
4.0
2.8
Max.
4.15
2.9
Units
VDC
VDC
Condition
with Vs=5.0VDC
with Vs=3.3VDC
Additional parameters
Parameter
3
Phase Noise
Min
Typ
-75
-110
-135
-150
-150
-75
-105
-130
-155
-160
Max.
Units
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
g
1
10
100
1
10
10
100
1
10
100
Condition
Hz
with 30.72 MHz
Hz
SC-Cut
Hz
HCMOS
kHz
kHz
Hz
with 110 MHz AT Cut
Hz
Sinewave
kHz
kHz
kHz
Phase Noise
3
Weight
Processing & Packing
10
Handling & processing note
Absolute Maximum Ratings
Parameter
Supply voltage (Vs)
Output Load
Operable temperature range
Storage temperature range
Min
Typ
Max.
7.0
7.0
50
+85
+125
Units
V
V
pF
°C
°C
Condition
with Vs=5.0VDC
with Vs=3.3VDC
-55
-55
Vectron International
·
www.vectron.com
Vectron International
Headquarters
267 Lowell Road
Hudson, New Hampshire 03051
+1-888-328-7661 tel
+1-888-329-8328 fax
Vectron International LLC.
100 Watts Street
Mount Holly Springs, PA 17065
USA
+1-717-486-3411 tel
+1-717-486-5920 fax
Vectron international GmbH & Co. KG
Landstrasse
D-74924 Neckarbischofsheim
Germany
+49-07268-801-0 tel
+49-07268-801-281 fax
v.2006-11-10 · page 2 of 5
Vectron Asia Pacific Sales Office
1F-2F, No 8 Workshop, No 308 Fenju
Road, WaiGaoQiao Free Trade Zone,
Pudong, Shanghai, P.R. China 200131
+86 21 5048 0777 tel.
+86 21 5048 1881 fax
C4530
Enclosures
OCXO
Type A, for HCMOS output
Type B, for Sinewave output,
only with reduced AT-stabilities
available
Type C, for HCMOS output
Package Codes:
Code
A1
A2
Height “H”
12.1
7.8
G185C
G185D
Code
B1
B2
Height “H”
12.1
7.8
G185C
G185D
Code
C1
C2
Height “H”
12.1
7.8
G270C
G270C
Pin Connections
1
2
3
4
5
6
7
Electronic Frequency Control Input (EFC)
Reference Voltage Output
Supply Voltage Input (Vs)
RF Output
Oven Alarm
I.C. Intern Connected
Ground (Case)
1 RF Output
2 N.C.
Pin Connections
1
2
3
4
5
Pin Connections
Electronic Frequency Control Input (EFC)
Reference Voltage Output
Supply Voltage Input (Vs)
RF Output
Ground (Case)
3 Ground (Case)
4 N.C.
5 Electronic Frequency Control Input (EFC)
6 Supply voltage Vs oscillator
7 Supply voltage Vs heater
*Pin 6 must be remain unconnected.
Vectron International
·
www.vectron.com
Vectron International
Headquarters
267 Lowell Road
Hudson, New Hampshire 03051
+1-888-328-7661 tel
+1-888-329-8328 fax
Vectron International LLC.
100 Watts Street
Mount Holly Springs, PA 17065
USA
+1-717-486-3411 tel
+1-717-486-5920 fax
Vectron international GmbH & Co. KG
Landstrasse
D-74924 Neckarbischofsheim
Germany
+49-07268-801-0 tel
+49-07268-801-281 fax
v.2006-11-10 · page 3 of 5
Vectron Asia Pacific Sales Office
1F-2F, No 8 Workshop, No 308 Fenju
Road, WaiGaoQiao Free Trade Zone,
Pudong, Shanghai, P.R. China 200131
+86 21 5048 0777 tel.
+86 21 5048 1881 fax
C4530
Standard Shipping Method
OCXO
Lage im Gurt
Position in tape
Pin 1
A
X
B
P
K
*bei W
≤ 24
mm
nur untere Lochreihe
∗by
W
≤
24 mm only lower hole line
Abwickelrichtung
Unwinding direction
Gurtunterseite
Tape buttom side
Gurtoberseite
Tape upper side
Production tolerance complying DIN IEC 286-3
Enclosure Type
Tape width
W [mm]
Type A1/A2
44
Quantity
per meter
37.5
Quantity
per reel
175 or 230
Dimension
P
32
Recommended Reflow Profile
Profile Feature
Average ramp-up rate (T
L
to Tp)
Preheat -Temperature Min Ts
min
)
-Temperature Min Ts
max
)
-Time (min to max) (ts)
Ts
max
to T
L
- Ramp-up Rate
Time maintainted above - Temperature (T
L
)
- Time (t
L
)
Peak Temperature (Tp)
Pb-Free Assembly
/Sn-Pb Assembly
3°C/second max.
150°c
200°c
60-180 seconds
3°C/second max.
217°C
60-150 seconds
max 260°C
Profile Feature
Time 25°C to Peak Temperature
Time maintainted above
- Temperature (T
L
)
- Time (t
L
)
Pb-Free Assembly
/Sn-Pb Assembly
8 minutes max.
217°C
60-150 seconds
Time within 5°C of actual
Peak Temperature (tp)
Ramp-down Rate
20-40 seconds
6°C/second max.
Note: All temperatures refer to topside of the package, measured on the package body surface.
Vectron International
·
www.vectron.com
Vectron International
Headquarters
267 Lowell Road
Hudson, New Hampshire 03051
+1-888-328-7661 tel
+1-888-329-8328 fax
Vectron International LLC.
100 Watts Street
Mount Holly Springs, PA 17065
USA
+1-717-486-3411 tel
+1-717-486-5920 fax
Vectron international GmbH & Co. KG
Landstrasse
D-74924 Neckarbischofsheim
Germany
+49-07268-801-0 tel
+49-07268-801-281 fax
v.2006-11-10 · page 4 of 5
Vectron Asia Pacific Sales Office
1F-2F, No 8 Workshop, No 308 Fenju
Road, WaiGaoQiao Free Trade Zone,
Pudong, Shanghai, P.R. China 200131
+86 21 5048 0777 tel.
+86 21 5048 1881 fax
C4530
Processing note:
OCXO
This FR 4 based SMD OCXO is a non-hermetic construction for use in No-Clean reflow processes and is 6/6 RoHS compliant. If you intend to wash
this SMD OCXO, please contact your Sales representative to discuss the possibility.
How to order this product:
Step 1
Model
C4530
Use this worksheet to forward the following information to your factory representative :
Stability Code
D107
Supply Voltage
Code
SV050
RF Output Code
RFH
Package Code
A1
Frequency
Control/ Enable
1
Frequency
10MHz
Vs.operat. Temp. Range
D107:
D257:
F257:
D258:
F508:
±100ppb
±250ppb
±250ppb
±25ppb
±50ppb
-20 …+70°C
-20 …+70°C
-40 …+85°C
-20 …+70°C
-40 …+85°C
Signal:
RFH: HCMOS
RFS: Sinewave
Tuning Range:
0: Fixed OCXO; No adjust
1: ±1.0 ppm..±2.5 ppm(SC)
1: ±3.0 ppm..±8.0 ppm(AT)
Enclosure:
A1: G185C
A2: G185D
B1: G185C
B2: G185D
C1: G270D
C2: G270D
Supply:
SV050: 5V
SV033: 3.3V
Step 2
The factory representative will then respond with a Vectron Model Number in the following configuration:
Model
C4530
Package Code
[Customer Specified Package Code]
Dash
-
Dash Number
[Factory Generated 4 digit number]
Typical P/N = C4530A1-0001
Notes:
1 Contact factory for improved stabilities or additional product options. Not all options and codes are available at all frequencies.
2 Unless otherwise stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency control voltage,
load, temperature (25°C)
3 Phase noise degrades with increasing output frequency.
4 Subject to technical modification.
5 Contact factory for availability.
Vectron International
·
www.vectron.com
Vectron International
Headquarters
267 Lowell Road
Hudson, New Hampshire 03051
+1-888-328-7661 tel
+1-888-329-8328 fax
Vectron International LLC.
100 Watts Street
Mount Holly Springs, PA 17065
USA
+1-717-486-3411 tel
+1-717-486-5920 fax
Vectron international GmbH & Co. KG
Landstrasse
D-74924 Neckarbischofsheim
Germany
+49-07268-801-0 tel
+49-07268-801-281 fax
v.2006-11-10 · page 5 of 5
Vectron Asia Pacific Sales Office
1F-2F, No 8 Workshop, No 308 Fenju
Road, WaiGaoQiao Free Trade Zone,
Pudong, Shanghai, P.R. China 200131
+86 21 5048 0777 tel.
+86 21 5048 1881 fax
京公网安备 11010802033920号
EEWORLD
