PO
Provides 0.40
o
C/W Junction-to-Case, Thermal Resistance
75, 100 and 120 Ampere Bridges
ion under the component
This mark indicates recognit
boratories, inc.
program of Underwriters La
PRV/LEG
TYPE NUMBER
100
200
400
PO120-04
PO100-04
PO75-04
600
PO120-06
PO100-06
PO75-06
800
PO120-08
PO100-08
PO75-08
1000
PO120-10
PO100-10
PO75-10
1200
PO120-12
PO100-12
PO75-12
1400
PO120-14
PO100-14
PO75-14
PO120-01 PO120-02
PO100-01 PO100-02
PO75-01
PO75-02
TYPE NUMBER
TYPE NUMBER
ELECTRICAL CHARACTERISTICS
Series Type Number
Max. Repetitive Peak
Reverse Voltage
O
PO 75
PO 100 PO 120
100 to 1400
UNIT
Volts
Max. DC Output Current. Tc=80 C
Max. DC Reverse Current @ PRV and 125
o
C, I
R
Max. Peak Non-Rep. Surge Current,8.3mS
Max.I
2
t for Fusing (t < 8.3ms)
Max. Instantaneous Forward Voltage @ IF=100Apk
Pulse Width=300
S
. Duty cycle<2.0%
Max. Isolation Voltage
Thermal Resistance R
0jc
Junction To Case
Operating Temperature Range,
75
5
1000
4000
1.3
2000
100
5
1000
4000
1.3
2000
120
5
1000
4000
1.3
2000
Adc
MmA.
Apk
A
2
SEC.
Vpk
V
RMS
o
0.40 typ. 0.40 typ. 0.40 typ.
-55 to+150
o
C
C/W
EDI reserves the right to change these specifications at any time without notice
PO
Figure 1
CURRENT DERATING
120
I
F(AV)
AVERAGE FORWARD CURRENT (AMP.)
For large capacitive load derate by up to 20%
100
PO
120
PO
100
80
60
PO
75
40
20
0
0
25
50
75
100
O
125
150
T
C
TEMPERATURE
( C)
Figure 2
NON- REPETITIVE SURGE CURRENT
PEAK HALF SINE WAVE
FORWARD CURRENT IN AMPERES
1000
875
750
625
500
375
250
125
1
2
4
6
8 10
20
40
60
NUMBER OF CYCLES AT 60 H
Z
PO SERIES MECHANICAL OUTLINE
2.25 (57.15)
0.177(4.50)
DIA.(TYP.)
+
+
AC
0.02(0.51)MIN.
+
1.75
(44.45)
0.177
(4.50)
+
+
1.07
(27.17)
REF.
+
-
AC
+
1.08
(27.43)
MAX.
1.88 (47.75)
TERMINAL
.375(9.53)HEX.
WITH 10-32 SCREW
4 PALCE
1.63(41.40)
REF.
DIMENSIONS IN INCHES
(MILLIMETERS)
NOTE: A thin film of silicone thermal compound is recommended between the Bridge
case and mounting surface for improved thermal conduction.
ELECTRONIC DEVICES, INC.
DESIGNERS AND MANUFACTURERS OF SOLID STATE DEVICES SINCE 1951.
21 GRAY OAKS AVENUE
* YONKERS. NEW YORK 10710 914-965-4400
* FAX 914-965-5531
* 1-800-678-0828
Ee-mail:sales@edidiodes.com
*
Wwebsite:
http://www.edidiodes.com
