BAS70W-13: DescriptionRectifier Diode, Schottky, 1 Element, 0.07A, 70V V(RRM), Silicon, ULTRA SMALL, PLASTIC PACKAGE-3; Categorydiode Rectifier diode; File Size75KB，3 Pages; ManufacturerDiodes Incorporated

Download Datasheet Parametric Compare View All

BAS70W-13 Overview

Rectifier Diode, Schottky, 1 Element, 0.07A, 70V V(RRM), Silicon, ULTRA SMALL, PLASTIC PACKAGE-3

BAS70W-13 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Diodes Incorporated
package instruction	ULTRA SMALL, PLASTIC PACKAGE-3
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Maximum output current	0.07 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	235
Maximum power dissipation	0.2 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	70 V
Maximum reverse recovery time	0.005 µs
surface mount	YES
technology	SCHOTTKY
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Base Number Matches	1

Preview

Download Datasheet

View All

SPICE MODELS: BAS70W BAS70W-04 BAS70W-05 BAS70W-06

BAS70W/ -04/ -05/ -06

SURFACE MOUNT SCHOTTKY BARRIER DIODE

Features

·

Low Turn-on Voltage

Fast Switching

PN Junction Guard Ring for Transient and ESD Protection

Ultra-Small Surface Mount Package

Available in Lead Free/RoHS Compliant Version (Note 3)

B C

A

SOT-323

Dim

A

B

C

D

G

H

K

M

Min

0.25

1.15

2.00

0.30

1.20

1.80

0.0

0.90

0.25

0.10

0°

Max

0.40

1.35

2.20

0.40

1.40

2.20

0.10

1.00

0.40

0.18

8°

Mechanical Data

·

Case: SOT-323

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020C

Terminals: Solderable per MIL-STD-202, Method 208

Also Available in Lead Free Plating (Matte Tin Finish

annealed over Alloy 42 leadframe). Please see Ordering

Information, Note 5, on Page 3

Polarity: See Diagrams Below

Marking: See Diagrams Below & Page 3

Weight: 0.006 grams (approximate)

J

D

E

L

0.65 Nominal

E

G

H

J

K

L

M

a

All Dimensions in mm

TOP VIEW

BAS70W Marking: K73

BAS70W-04 Marking: K74

BAS70W-05 Marking: K75

BAS70W-06 Marking: K76

Maximum Ratings and Electrical Characteristics, Single Diode

@ T

A

= 25°C unless otherwise specified

Characteristic

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

RMS Reverse Voltage

Forward Continuous Current (Note 1)

Non-Repetitive Peak Forward Surge Current @ t

p

<

1.0s

Power Dissipation (Note 1)

Thermal Resistance Junction to Ambient Air (Note 1)

Operating Temperature Range

Storage Temperature Range

Symbol

V

RRM

V

RWM

V

R

V

R(RMS)

I

F

I

FSM

P

d

R

qJA

T

j

T

STG

@ T

A

= 25°C unless otherwise specified

Symbol

V

(BR)R

V

F

I

R

C

T

t

rr

Min

70

—

¾

—

Max

—

410

1000

100

2.0

5.0

Unit

—

mV

nA

pF

ns

Test Condition

I

R

= 10mA

t

p

<300µs, I

F

= 1.0mA

t

p

<300µs, I

F

= 15mA

t

p

< 300µs, V

R

= 50V

V

R

= 0V, f = 1.0MHz

I

F

= I

R

= 10mA to I

R

= 1.0mA,

Irr = 0.1 x I

R

, R

L

= 100W

Value

70

49

70

100

200

625

-55 to +125

-65 to +150

Unit

V

mA

mW

°C/W

°C

Electrical Ratings

Characteristic

Reverse Breakdown Voltage (Note 2)

Forward Voltage (Note 2)

Reverse Current (Note 2)

Total Capacitance

Reverse Recovery Time

Notes:

1. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout

document AP02001, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.

2. Short duration test pulse used to minimize self-heating effect.

3. No purposefully added lead.

DS30113 Rev. 9 - 2

1 of 3

www.diodes.com

BAS70W/ -04/ -05/ -06

ã

Diodes Incorporated
