Chip Inductors -
MPCI 10000
Series
.....High
Grade Technologies............
.....RF
and Data magnetics.............
.....Miniature
Chip Inductors............
•
qualified
3201/008
and as per Mil Spec
M83446/5
• Excellent Q values even at high frequencies
• Very high self-resonant frequencies (SFRs)
• Extremely stable inductance values from
-
55
°C
to
+
125
°C
• With or without tab terminations
• Tinned or gold plated terminations
• Frequency range :
7.9
MHz
to
500
MHz
• Operating temperature range :
-
55
°C
to
+
125
°C
• Weight :
0.07
gram
Electrical Data
( 25°C )
ID Code
MPCI 10 000 010
MPCI 10 000 012
MPCI 10 000 015
MPCI 10 000 018
MPCI 10 000 022
MPCI 10 000 027
MPCI 10 000 033
MPCI 10 000 039
MPCI 10 000 047
MPCI 10 000 056
MPCI 10 000 068
MPCI 10 000 082
MPCI 10 000 100
MPCI 10 000 120
MPCI 10 000 150
MPCI 10 000 180
MPCI 10 000 220
MPCI 10 000 270
MPCI 10 000 330
MPCI 10 000 390
MPCI 10 000 470
MPCI 10 000 560
Inductance* Q Test Freq. SFR Min. DCR Max. DC Current Tol**
µH
Min
MHz
MHz
Ω
mA max % Min
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
60
60
60
60
51
51
47
47
47
47
47
47
47
47
47
51
51
51
51
47
47
52
150
150
150
150
100
100
100
100
100
100
100
100
50
50
50
50
50
50
50
50
25
25
2000
2000
1800
1500
1400
1200
1200
1200
1000
900
900
750
620
540
450
400
380
340
280
240
210
180
0.025
0.025
0.04
0.04
0.04
0.04
0.05
0.07
0.08
0.09
0.10
0.11
0.11
0.11
0.12
0.14
0.20
0.25
0.30
0.45
0.50
0.55
750
750
750
750
750
750
640
600
550
520
480
470
470
470
450
430
350
310
280
240
230
220
ID Code
MPCI 10 000 680
MPCI 10 000 820
MPCI 10 001 000
MPCI 10 001 200
MPCI 10 001 500
MPCI 10 001 800
MPCI 10 002 200
MPCI 10 002 700
MPCI 10 003 300
MPCI 10 003 900
MPCI 10 004 700
MPCI 10 005 600
MPCI 10 006 800
MPCI 10 008 200
MPCI 10 010 000
Inductance* Q Test Freq. SFR Min. DCR Max. DC Current Tol**
µH
Min
MHz
MHz
Ω
mA max % Min
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
52
52
52
42
42
48
48
48
48
48
48
48
46
46
46
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
160
130
110
110
100
95
90
65
55
45
43
40
38
35
33
0.58
0.60
0.65
0.75
1.1
1.2
1.3
1.5
1.8
2.0
2.3
2.5
2.6
2.8
3.3
210
200
190
180
160
150
140
130
120
110
100
100
98
95
87
5
10
5
2
10
5
* Standard inductance tolerance :
±
10
%
** Tightest achievable tolerances.
Other inductance values and S parameters on request.
Inductance variation :
35
PPM / °C max.
in the range
0.01
to
1.2
µH
80
PPM / °C max.
in the range
1.5
to
10
µH
Packaging
Tape and Reel (without tab) :
500
pieces
or Tray :
81
pieces without tab,
49
pieces with tab
Typical Dimensions
(mm)
110
1
st
significant figure (2 times wider)
2
nd
significant figure
Multiplier (nH)
100
90
80
3
0.1
X
MA
Q vs frequency
0
27
µH
2.16
MAX
0.4
6
470
to
6
8
2.2
µ
H
0µ
H
70
60
1.
5
6
0
to
8
20
µH
2
2.6
7
M
AX
o
1t
.8
0
1.8
µH
0µ
39
0-
H
0
18
to
µH
0.96
2.8
2.6
50
40
33
0-
22
1.
1t
10
0µ
H
o
1
.8
µH
"S" Version
"A" Version
2.66
3.7
30
20
1
10
100
Frequency - MHz
Tel : + 33 (0) 3 82 59 13 33
www.microspire.com
Specifications may change without prior notice - Revised 06/09
11
Miniature Chip Inductors
MSCI 10000
QPL Components
MPCI 10000
series are usually installed on Military applications and breadboards for Space applications.
Since January 2003, Microspire has been manufacturing Radio Frequency Fixed Coils,
MPCI 10000
series fulfilling
ESA ESCC
Generic specification
N°
3201
and detail specification
N°
3201/008.
This range is named
MSCI
(S for space applications).
This qualification approval includes final production tests Chart II, burn-in and electrical measurements to testing
level B Chart III and qualification testing Chart IV.
For procurement, different quality levels are offered :
• Final production tests Chart II
• Burn-in and electrical measurements Chart III with level B or C (as required)
• Lot acceptance testing Chart V if required
Components delivered through this specification need to be processed and inspected in accordance with the
Microspire Process Identification Document (P.I.D.).
Each component delivered is traceable to its production lot.
.....High
Grade Technologies............
.....RF
and Data Magnetics.............
.....Miniature
Chip Inductors............
Cross reference chart
Microspire Non-QPL
ID Code
MPCI 10 000 010 x y 10
MPCI 10 000 012 x y 10
MPCI 10 000 015 x y 10
MPCI 10 000 018 x y 10
MPCI 10 000 022 x y 10/5
MPCI 10 000 027 x y 10/5
MPCI 10 000 033 x y 10/5
MPCI 10 000 039 x y 10/5
MPCI 10 000 047 x y 10/5
MPCI 10 000 056 x y 10/5
MPCI 10 000 068 x y 10/5
MPCI 10 000 082 x y 10/5
MPCI 10 000 100 x y 10
MPCI 10 000 120 x y 10
MPCI 10 000 150 x y 10
MPCI 10 000 180 x y 10
MPCI 10 000 220 x y 10
MPCI 10 000 270 x y 10
MPCI 10 000 330 x y 10
MPCI 10 000 390 x y 10
MPCI 10 000 470 x y 10/5
Microspire QPL
ID Code
MSCI 10 000 010 x y 10
MSCI 10 000 012 x y 10
MSCI 10 000 015 x y 10
MSCI 10 000 018 x y 10
MSCI 10 000 022 x y 10/5
MSCI 10 000 027 x y 10/5
MSCI 10 000 033 x y 10/5
MSCI 10 000 039 x y 10/5
MSCI 10 000 047 x y 10/5
MSCI 10 000 056 x y 10/5
MSCI 10 000 068 x y 10/5
MSCI 10 000 082 x y 10/5
MSCI 10 000 100 x y 10
MSCI 10 000 120 x y 10
MSCI 10 000 150 x y 10
MSCI 10 000 180 x y 10
MSCI 10 000 220 x y 10
MSCI 10 000 270 x y 10
MSCI 10 000 330 x y 10
MSCI 10 000 390 x y 10
MSCI 10 000 470 x y 10/5
ESA SCC
Component Part Number
3201008 aa b L010 K
3201008 aa b L012 K
3201008 aa b L015 K
3201008 aa b L018 K
3201008 aa b L022 K/J
3201008 aa b L027 K/J
3201008 aa b L033 K/J
3201008 aa b L039 K/J
3201008 aa b L047 K/J
3201008 aa b L056 K/J
3201008 aa b L068 K/J
3201008 aa b L082 K/J
3201008 aa b L10 K
3201008 aa b L12 K
3201008 aa b L15 K
3201008 aa b L18 K
3201008 aa b L22 K
3201008 aa b L27 K
3201008 aa b L33 K
3201008 aa b L39 K
3201008 aa b L47 K/J
Microspire Non-QPL
ID Code
MPCI 10 000 560 x y 10/5
MPCI 10 000 680 x y 10/5
MPCI 10 000 820 x y 10/5
MPCI 10 001 000 x y 10/5
MPCI 10 001 200 x y 10/5/2
MPCI 10 001 500 x y 10/5/2
MPCI 10 001 800 x y 10/5/2
MPCI 10 002 200 x y 10/5/2
MPCI 10 002 700 x y 10/5/2
MPCI 10 003 300 x y 10/5/2
MPCI 10 003 900 x y 10/5/2
MPCI 10 004 700 x y 10/5/2
MPCI 10 005 600 x y 10/5/2
MPCI 10 006 800 x y 10/5/2
MPCI 10 008 200 x y 10/5/2
MPCI 10 010 000 x y 10/5/2
aa
aa =
01
for Au Termination
aa =
02
for SnPb Termination
Microspire QPL
ID Code
MSCI 10 000 560 x y 10/5
MSCI 10 000 680 x y 10/5
MSCI 10 000 820 x y 10/5
MSCI 10 001 000 x y 10/5
MSCI 10 001 200 x y 10/5/2
MSCI 10 001 500 x y 10/5/2
MSCI 10 001 800 x y 10/5/2
MSCI 10 002 200 x y 10/5/2
MSCI 10 002 700 x y 10/5/2
MSCI 10 003 300 x y 10/5/2
MSCI 10 003 900 x y 10/5/2
MSCI 10 004 700 x y 10/5/2
MSCI 10 005 600 x y 10/5/2
MSCI 10 006 800 x y 10/5/2
MSCI 10 008 200 x y 10/5/2
MSCI 10 010 000 x y 10/5/2
b
b =
B
for Chart III level B
b =
C
for Chart III level C
ESA SCC
Component Part Number
3201008 aa b L56 K/J
3201008 aa b L68 K/J
3201008 aa b L82 K/J
3201008 aa b 1L0 K/J
3201008 aa b 1L2 K/J/G
3201008 aa b 1L5 K/J/G
3201008 aa b 1L8 K/J/G
3201008 aa b 2L2 K/J/G
3201008 aa b 2L7 K/J/G
3201008 aa b 3L3 K/J/G
3201008 aa b 3L9 K/J/G
3201008 aa b 4L7 K/J/G
3201008 aa b 5L6 K/J/G
3201008 aa b 6L8 K/J/G
3201008 aa b 8L2 K/J/G
3201008 aa b 100 K/J/G
K/J/G (tolerance)
K
for ±10%
J
for ±5%
G
for ±2%
To Order
MPCI
Radio Frequency
Fixed Coils
10
Size
### ###
Inductance Value (nH)
from 000 010
to 010 000
x
Terminations
x =
G
for Gold
x =
T
for Tinned
y
MPCI 10
### ###
x y z
z
Tolerance :
z =
10
for ±10%
z =
5
for ±5%
z =
2
for ±2%
Terminations shape
y =
S
without tab
y =
A
with tab (Not valid for space use)
Tel : + 33 (0) 3 82 59 13 33
www.microspire.com
Specifications may change without prior notice - Revised 06/08
