DataSheet
HS151DR Series Assemblies
•
40 amp AC output @ 40°C
•
Single or Dual Channel output
•
3 to 32 VDC input control voltage
•
DIN Rail mounted
•
uL, CSA, VDE, CE approved SSRs
•
Epoxy free design
DIN Rail Mount
PRODUCT SELECTION
Description
3-32 VDC Control
40A
HS151DR-D2450
(1)
40A
HS151DR-HD6050
OUTPUT SPECIFICATIONS
Description
HS151DR-D2450
24-280
600
1.0
500
40
150
625
1.15
1620
0.5
HS151DR-HD6050
48-660
1200
1.0
500
40
150
625
1.15
1620
0.5
INPUT SPECIFICATIONS
Description
Control Voltage Range
Minimum Turn-On Voltage
Minimum Turn-Off Voltage
Maximum Reverse Voltage
Minimum Input Current
Maximum Input Current
Nominal Input Impeadance
Maximum Turn-On Time [msec]
Maximum Turn-Off Time [msec]
Operating Voltage (47-63Hz) [Vrms]
Transient Overvoltage [Vpk]
Maximum Off-State Leakage Current @ Rated Voltage [mArms]
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/µsec]
(1)
Maximum Load Current [Arms]
Minimum Load Current [Arms]
Maximum Surge Current (16.6ms) [Apk]
Maximum On-State Voltage Drop @ Rated Current [Vac]
Maximum I²t for Fusing (8.3 msec) [A² sec]
Minimum Power Factor (with Maximum Load)
(1)
HS151DR-D2450
3-32 VDC
3.0 VDC
1.0 VDC
-32 VDC
7.0 mA
12 mA
Current Regulared
1/2 Cycle
1/2 Cycle
HS151DR-HD6050
4-32 VDC
4.0 VDC
1.0 VDC
-32 VDC
7.0 ma
12 ma
Current Regulated
1/2 Cycle
1/2 Cycle
GENERAL SPECIFICATIONS
Description
Dielectric Strength, Input/Output/Base (50/60Hz)
Minimum Insulation Resistance (@ 500 V DC)
Maximum Capacitance, Input/Output
Ambient Operating Temperature Range
Ambient Storage Temperature Range
Status Indicator Display
Weight (typical)
Recommended Terminal Screw Torque Range: (in-lb/Nm)
Thermal pad installed
HS151DR-Dxx50
4000 Vrms
10
9
Ohms
8 pF
-40 to 80˚C
-40 to 125˚C
None
1.08 lb. (425 g)
6-32 Screws - 13-15/1.5-7.7. 8-32 Screws - 18-20/2-2.2.
(Screws dry without grease)
Yes
(1)
All parameters at 25°C unless otherwise specified.
(2)
Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
GENERAL NOTES
