5.0V TTL CLOCK OSCILLATOR
MODEL: F1100E
FEATURES
• 5.0V Operation
• TTL Output
• 14-Pin DIP
• PART NUMBER SELECTION
Part Number
049-Frequency-xxxxx
343-Frequency-xxxxx
060-Frequency-xxxxx
061-Frequency-xxxxx
055-Frequency-xxxxx
465-Frequency-xxxxx
Learn More - Internet Required
Frequency
Operating
Model
Stability
1
Temperature (ºC)
Number
0 ~ +70
F1100E
±100PPM
(STD)
±100PPM
-40 ~ +85
F1100ER
±50PPM
0 ~ +70
F1145E
±50PPM
-40 ~ +85
F1145ER
±25PPM
0 ~ +70
F1144E
±25PPM
-40 ~ +85
F1144ER
Frequency
Range (MHz)
1.000 ~ 100.000
1.000 ~ 100.000
1.000 ~ 100.000
1.000 ~ 70.000
1.000 ~ 100.000
1.000 ~ 70.000
Learn more about:
Part Marking Identification
Mechanical Specification
Internet required
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Input Current
(I
DD
)
1.000 ~ 8.000 MHz
8.000+ ~ 24.000 MHz
24.000+ ~ 70.000 MHz
70.000+ ~ 100.000 MHz
Output Symmetry (1.4V Level)
1.000 ~ 8.000 MHz
8.000+ ~ 100.000 MHz
Rise Time (0.5V ~ 2.4V) (T
R
)
1.000 ~ 25.000 MHz
25.000+ ~ 70.000 MHz
70.000+ ~ 100.000 MHz
Fall Time (2.4V ~ 0.5V) (T
F
)
1.000 ~ 25.000 MHz
25.000+ ~ 70.000 MHz
70.000+ ~ 100.000 MHz
Output Voltage
1.000 ~ 25.000 MHz
(V
OL
)
25.000+ ~ 100.000 MHz
1.000 ~ 100.000 MHz
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
Start-up Time
(T
S
)
1.000 ~ 3.500 MHz
3.500+ ~ 4.000 MHz
4.000+ ~ 6.000 MHz
6.000+ ~ 20.000 MHz
20.000+ ~ 100.000 MHz
1
MAX
(unless otherwise noted)
1.000 ~ 100.000 MHz
-55ºC ~ +125ºC
5.0V ± 10%
15mA
30mA
70mA
80mA
45% ~ 55%
40% ~ 60%
10 nS
5 nS
4 nS
10 nS
5 nS
4 nS
0.4V
0.5V
2.4V Min
20mA Min
-1.0mA Min
10TTL
20mS
35mS
30mS
20mS
15mS
All dimensions are in millimeters.
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
All specifications subject to change without notice.
Rev. 6/1/04
68
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239)693-0099 FAX +1(239)693-1554
http://www.foxonline.com
© 2004 FOX ELECTRONICS
