Document 175-1
ChipInductors
–
0603HSSeries(1608)
This series will be discontinued after May 31, 1998. Please use our 0603CS Series which is electrically
equivalent and has the same footprint.
Inductance
2
(nH)
SRF
Min
5
(MHz)
R
DC
I
DC
Max
6
Max
7
(Ohms) (mA)
Part Number
1
0603HS-1N8T_ BC
0603HS-3N9T _ BC
0603HS-6N8T _ BC
0603HS-10NT _ BC
0603HS-12NT _ BC
0603HS-15NT _ BC
0603HS-18NT _ BC
0603HS-22NT _ BC
0603HS-27NT _ BC
0603HS-33NT _ BC
0603HS-39NT _ BC
0603HS-47NT _ BC
0603HS-56NT _ BC
0603HS-68NT _ BC
0603HS-72NT _ BC
0603HS-82NT _ BC
0603HS-R10T _ BC
0603HS-R11T _ BC
0603HS-R12T _ BC
DISCONTINUED
AFTER
MAY 1998
1.8 @ 250 MHz
3.9 @ 250 MHz
6.8 @ 250 MHz
10 @ 250 MHz
12 @ 250 MHz
10
10
10
5
5
16
22
27
31
35
>6000
>6000
5800
4800
4000
4000
3100
3000
2800
2300
2200
2000
1900
1700
1700
.045
.080
.110
.130
.130
700
700
700
700
700
1.63
3.95
6.75
10
12.3
35
49
60
66
72
1.66
3.96
7.1
10.6
13.5
15 @ 250 MHz
18 @ 250 MHz
22 @ 250 MHz
27 @ 250 MHz
33 @ 250 MHz
39 @ 250 MHz
47 @ 200 MHz
56 @ 200 MHz
68 @ 200 MHz
72 @150 MHz
5
5
5
5,2
5,2
35
35
38
40
40
40
38
38
37
34
.170
.170
.190
.220
.220
.250
.280
.310
.340
.490
700
700
700
600
600
600
600
600
600
400
15.4
18.7
22.8
29.2
36
42.7
52.2
62.5
80.5
82.0
64
70
73
74
67
60
62
56
54
53
16.8
21.4
26.1
34.6
49.5
5,2
5,2
5,2
5,2
5,2
60.2
77.2
97
168
135
82 @ 150 MHz
100 @ 150 MHz
110 @ 150 MHz
120 @ 150 MHz
5,2
5,2
5,2
5,2
34
34
32
32
1700
1400
1350
1300
.540
.580
.610
.650
400
400
300
300
96.2
124
138
166
54
49
43
39
177
—
—
—
Inductance tolerance
G=2%, J=5%, K=10%
Table above shows stock tolerances in bold.
Other tolerances shown are available on special order.
Percent
Tolerance
3
Q
Min
4
900 MHz
L Typ Q Typ
1.7 GHz
L Typ Q Typ
Color
Code
50
67
81
83
83
89
69
71
65
42
40
35
26
21
20
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
21
—
—
—
• For environmental data see “Product Specifications” section (Document 121).
• For part marking data see “Color Coding” section (Document 174).
1. When ordering, please specify tolerance and packaging codes:
0603HS-R12T_BC
Packaging
C
= EIA RS-481 clear tape and reel (standard).
For orders of less than a full reel, there is a $25
per reel charge to make them machine-ready.
B
= Bulk. In a carrier tape but without leader or trailer.
2. Inductance measured using Coilcraft SMD-A fixture in HP4286 impedance
analyzer with Coilcraft-provided correlation pieces. For recommended test
procedures, contact Coilcraft.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using HP4291A with HP16193 test fixture and on HP8753D
with Coilcraft SMD-E test fixture.
5. SRF measured using HP8753D network analyzer and Coilcraft SMD-D
test fixture.
6. R
DC
measured on Cambridge Technology micro-ohmmeter and Coilcraft
CCF858 test fixture.
7. For 15°C rise.
8. Operating temperature range
−40°C
to +125°C.
ACCURATE
COILCRAFT
REPEATABLE
PRECISION
MEASUREMENTS
DOC. 126
TEST FIXTURES
Specifications subject to change without notice.
Document 175-1 Revised 11/17/97
Document 175-2
0603HS Series (1608)
TYPICALQvsFREQUENCY
100
For a free disk call
847/639-6400
12N
80
33N
68N
22N
60
Q
40
R12
3N9
20
0
1
10
100
1000
10000
Frequency (MHz)
B
overall
F
A
G
F
E
terminal
H
C
I
LvsFREQUENCY
200
175
J
I
Inductance (nH)
Land
Pattern
R12
150
125
100
75
50
25
0
1
10
100
1000
33N
22N
12N
3N9
68N
Terminal wraparound:
approx. .007/0,18 both ends
A
B
C
E
Max. Max. Max.
.067 .045 .040 .030
1,70 1,14 1,02 0,76
F
.013
0,33
G
.034
0,86
H
.040
1,02
I
.025
0,64
J
.025
0,64
Parts/reel: 7″ 2,000; 13″ 7,500 Tape width: 8mm
For packaging data see “Tape and Reel Specifications” (Document 173)
10000
Frequency (MHz)
Document 175-2 Revised 6/25/97
