Document 100-1
Chip Inductors – 0805CS Series (2012)
These compact inductors provide exceptional Q values,
even at high frequencies. They have a ceramic body and
wire wound construction to provide the highest SRFs
available in 0805 size.
Part number
1
Coilcraft
Designer’s Kit C103
contains samples of all
5% inductance tolerance parts. Kits with 2% tolerance
are also available. To order, contact Coilcraft or pur-
chase on-line at
http://order.coilcraft.com.
Q min
4
Inductance
2
(nH)
2.8 @
3.0 @
3.3 @
5.6 @
6.8 @
7.5 @
8.2 @
10 @
12 @
15 @
18 @
22 @
24 @
27 @
33 @
36 @
39 @
43 @
47 @
56 @
68 @
82 @
91 @
100 @
110 @
120 @
150 @
180 @
220 @
240 @
270 @
330 @
390 @
470 @
560 @
680 @
820 @
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
200 MHz
200 MHz
200 MHz
200 MHz
150 MHz
150 MHz
150 MHz
150 MHz
150 MHz
100 MHz
100 MHz
100 MHz
100 MHz
100 MHz
100 MHz
100 MHz
50 MHz
25 MHz
25 MHz
25 MHz
Percent
tolerance
3
20,10,5
20,10,5
20,10,5
20,10,5
20,10,5
20,10,5
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2,1
20,10,5,2,1
20,10,5,2,1
20,10,5,2,1
20,10,5,2,1
10,5,2,1
10,5,2,1
10,5,2,1
20,10,5,2,1
10,5,2,1
20,10,5,2
10,5,2,1
10,5,2,1
10,5,2,1
10,5,2
20,10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
10,5,2
80
65
50
65
50
50
50
60
50
50
50
55
50
55
60
55
60
60
60
60
60
65
65
65
50
50
50
50
50
44
48
48
48
33
23
23
23
SRF min
5
DCR max
6
(MHz)
(Ohms)
7900
7900
7900
5500
5500
4500
4700
4200
4000
3400
3300
2600
2000
2500
2050
1700
2000
1650
1650
1550
1450
1300
1200
1200
1000
1100
920
870
850
690
650
600
560
375
340
188
215
0.06
0.06
0.08
0.08
0.11
0.14
0.12
0.10
0.15
0.17
0.20
0.22
0.22
0.25
0.27
0.27
0.29
0.34
0.31
0.34
0.38
0.42
0.48
0.46
0.48
0.51
0.56
0.64
0.70
1.00
1.00
1.40
1.50
1.76
1.90
2.20
2.35
Irms
7
(mA)
800
800
600
600
600
600
600
600
600
600
600
500
500
500
500
500
500
500
500
500
500
400
400
400
400
400
400
400
400
350
350
310
290
250
230
190
180
Color
code
Gray
White
Black
Orange
Brown
Green
Red
Blue
Orange
Yellow
Green
Blue
Gray
Violet
Gray
Orange
White
Yellow
Black
Brown
Red
Orange
Black
Yellow
Brown
Green
Blue
Violet
Gray
Red
White
Black
Brown
Violet
Orange
Green
Blue
0805CS-020X_B_
0805CS-3N0X_B_
0805CS-030X_B_
0805CS-050X_B_
0805CS-060X_B_
0805CS-070X_B_
0805CS-080X_B_
0805CS-100X_B_
0805CS-120X_B_
0805CS-150X_B_
0805CS-180X_B_
0805CS-220X_B_
0805CS-240X_B_
0805CS-270X_B_
0805CS-330X_B_
0805CS-360X_B_
0805CS-390X_B_
0805CS-430X_B_
0805CS-470X_B_
0805CS-560X_B_
0805CS-680X_B_
0805CS-820X_B_
0805CS-910X_B_
0805CS-101X_B_
0805CS-111X_B_
0805CS-121X_B_
0805CS-151X_B_
0805CS-181X_B_
0805CS-221X_B_
0805CS-241X_B_
0805CS-271X_B_
0805CS-331X_B_
0805CS-391X_B_
0805CS-471X_B_
0805CS-561X_B_
0805CS-681X_B_
0805CS-821X_B_
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
@
1500 MHz
1500 MHz
1500 MHz
1000 MHz
1000 MHz
1000 MHz
1000 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
500 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
250 MHz
100 MHz
50 MHz
50 MHz
50 MHz
1. When ordering, please specify
tolerance
and
packaging
codes:
0805CS-821XGBC
1%
G
= 2%
J
= 5%
K
= 10%
M
= 20%
(Table shows stock tolerances in bold.)
7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (7500 parts per
full reel).
Tolerance: F
=
Packaging: C
=
B
=
D
=
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/
HP 4286A impedance analyzer with Coilcraft-provided correlation pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test
fixture.
5 SRF measured using an Agilent/HP 8720D network analyzer and a
Coilcraft SMD-D test fixture.
6. DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF858 test fixture.
7. Average current for a 15°C rise above 25°C ambient.
8. Operating temperature range
−40°C
to +125°C.
9. Electrical specifications at 25°C.
See Qualification Standards section
for environmental and test data.
Specifications subject to change without notice.
Please check our website for latest information.
Document 100-1
Revised 12/18/02
Document 100-2
0805CS Series (2012)
Typical Q vs Frequency
100
90
80
68 nH
6.8 nH
39 nH
Typical L vs Frequency
12 nH
22 nH
1000
3.3 nH
220 nH
100 nH
100
70
60
120 nH
Inductance (µH)
39 nH
Q Factor
50
40
30
20
10
0
10
100
270 nH
15 nH
10
3.3 nH
1
1000
10,000
10
100
1000
Frequency (MHz)
Frequency (MHz)
B
overall
F
A
G
F
E
terminal
C
I
J
I
D
Terminal wraparound:
approx 0.015/0,38 both ends
H
Recommended
Land Pattern
A max B max C max D ref
0.090
2,29
0.068
1,73
0.060
1,52
E
F
G
0.040
1,02
H
I
J
0.030
0,76
0.020 0.050 0.020
0,51
1,27
0,51
0.070 0.040
1,78
1,02
Weight:
10.2 – 11.6 mg
Terminations:
Platinum/palladium/silver
Tape and reel:
2000/7″ reel; 7500/13″ reel 8 mm tape width
For packaging data see Tape and Reel Specifications section.
Specifications subject to change without notice.
Please check our website for latest information.
Document 100-2
Revised 12/28/04
