Chip Inductors - 0603HC Series (1608)
With their high current ratings and ultra-small size, these
chip inductors are ideal for today’s high frequency, low
voltage applications like mobile phones. They feature
continuous current ratings up to 2.4 Amps DC and will
handle transient currents up to 50% higher. At low
inductance values, their Q factors are also higher than
our standard 0603CS Series.
CURRENT
HIGH
Document 218-1
Part number
1
0603HC-1N6XJL_
0603HC-3N6XJL_
0603HC-3N9XJL_
0603HC-6N8XJL_
0603HC-7N5XJL_
0603HC-10NX_L_
0603HC-12NX_L_
0603HC-15NX_L_
0603HC-18NX_L_
0603HC-22NX_L_
0603HC-24NX_L_
Inductance
2
Percent
(nH)
tolerance
3
1.6
5
3.6
5
3.9
5
6.8
5
7.5
5
10
5,2
12
5,2
15
5,2
18
5,2
22
5,2
24
5,2
Q
min
4
24
24
25
35
38
38
38
38
40
42
42
900 MHz
L typ Q typ
1.67
49
3.65
70
3.74
70
6.72
70
7.33
70
9.70
73
12.3
68
15.5
65
19.5
62
24.0
61
25.8
55
1.7 GHz
L typ Q typ
1.65
63
3.75
90
3.90
90
7.10
75
7.90
68
10.5
57
14.5
41
17.6
40
25.0
40
31.5
26
35.0
21
SRF
min
5
(MHz)
12500
5900
5900
5800
3700
3700
3000
2800
2800
2400
2400
DCR
max
6
Irms
7
(Ohms) (A)
0.030
2.4
0.048
2.3
0.054
2.2
0.054
2.1
0.059
2.1
0.071
2.0
0.075
2.0
0.080
1.9
0.099
1.9
0.099
1.8
0.105
1.8
Color
code
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
White
Black
1. When ordering, specify
tolerance, termination
and
packaging
codes:
0603HC-24NXJLW
Tolerance: G
= 2%
J
= 5% (Table shows stock tolerances in bold.)
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: W=
7″ machine-ready reel. EIA-481 punched paper tape
(2000 parts per full reel).
U
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter W instead.
2. Inductance measured at 250 MHz using Coilcraft SMD-A fixture in
Agilent/HP 4286 impedance analyzer with Coilcraft-provided correlation
pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured at 250 MHz using Agilent/HP 4291A with Agilent/HP 16193
test fixture.
5. SRF measured using Agilent/HP 8720D network analyzer and Coilcraft
SMD-D test fixture.
6. DCR measured on micro-ohmmeter and Coilcraft CCF858 test fixture.
7. Current that causes a 20°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Designer’s Kit C339
contains 10 of each of all 5% parts
Core material
Ceramic
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Weight
3.3 – 3.7 mg
Ambient temperature
–40°C to +125°C with
Irms
current,
+125°C to +145°C with derated current
Storage temperature
Component: –40°C to +155°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +125 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Packaging
2000 per 7″ reel. Paper tape: 8 mm wide, 1.0 mm thick,
4 mm pocket spacing
PCB washing
Only pure water or alcohol recommended
Specifications subject to change without notice.
Please check our website for latest information.
Document 218-1
Revised 10/03/08
© Coilcraft, Inc. 2010
