177-140h and 177-704h
MIL-DtL-83513 type Micro-D hermetic Connectors
solder Mount
Solder
these 177-140 hermetic Micro-D connectors. Featuring
a matched glass-to-metal seal, these socket receptacles
are designed for panel mounting.
Kovar
®
Shells and Contacts
comply with applicable MIL-
DTL-83513 requirements and are 100% intermateable
with standard connectors.
Choose 9 to 100 Contacts,
with gold-plated contacts and
nickel-plated shells. These connectors feature integral
female jackposts.
hoW to oRDER soLDER Cup AND pC tAIL CoNNECtoRs
series
177-140h
Micro-D Hermetic Socket
Receptacle, Solder or Weld
Mounting
Layout
Number of Contacts
9
15
21
25
31
37
51
100
Contact type
s
– Socket
termination type
s
–
Solder Cup
p
–
PC Tail
Sample Part Number
177-140h
15
s
p
hoW to oRDER pRE-WIRED CoNNECtoRs
series
177-704h
Layout
9
15
21
25
31
37
51
100
Contact type
s
–
Socket
Wire Gage
(AWG)
6
– #26
8
– #28
0
– #30
Wire type
K
–
M22759/11
600 Vrms
Teflon
®
(TFE)
(Not Available
in #30 AWG)
Wire Color
1
–
White
2
–
Yellow
5
–
Color-Coded
Wire Length
Inches
18
J
–
M22759/33
600 Vrms
Modified
Cross-Linked
Tefzel
®
(ETFE)
Stripes Per
MIL-STD-681
(#26 gage
only)
7
–
Ten Color
Repeat
Wire Length
In Inches. “18”
Specifies 18 Inches.
Sample Part Number
177-704h
25
s
6
K
1
– 18
© 2009 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
I-5
MIL-DTL-83513
Connectors
I
MIL-DTL-83513
Connectors
A
B
C
E
D
9-69 CONTACTS #2-56 THREADS
100 CONTACTS #4-40 THREADS
F
G
H
J
.025 (0.64) RADIUS 4 PLCS.
177-140H and 177-704H
MIL-DTL-83513 Type Micro-D Hermetic Connectors
Solder Mount
.125 ± .015
(3.18 ± 0.38)
.021/.018
(0.53/0.46)
PC TAIL
.076 ± .005
(1.93 ± 0.13)
SOLDER CUP
TWO ROW
.180 (4.57)
MAX.
THREE,
FOUR ROW
.260 (6.60)
MAX.
.500 (12.7) MAX.
WIRE LENGTH
+1.0 (2.54)/-0.0
PRE-WIRED
EPOXY POTTING
DIMENSIONS
A Max.
Layout
9S
15S
21S
25S
31S
37S
51S
2 row
51S
3 row
100S
In.
.785
1.030
1.180
1.280
1.430
1.580
1.930
1.530
2.260
B MAX.
In .
.695
.855
1.005
1.105
1.255
1.425
1.615
1.215
1.800
C
In .
mm.
D Max.
In.
.250
.250
.250
.250
.250
.250
.310
.310
.330
E Max.
In.
.310
.425
.425
.425
.425
.425
.425
.468
.517
F
In.
mm.
4.95
4.95
4.95
4.95
4.95
4.95
5.05
5.05
5.05
G Max.
In.
.394
.394
.394
.394
.394
.394
.394
.394
.394
H
In.
mm.
In.
J
mm.
6.81
6.48
6.48
6.48
6.48
6.48
7.5
9.0
mm.
19.94
26.16
29.97
32.51
36.32
40.13
49.02
38.86
57.40
mm.
± .003 ± 0.08
14.35
21.71
25.53
28.06
31.88
36.20
41.02
30.86
45.72
.565
.715
.865
.965
1.115
1.265
1.775
1.361
2.010
14.35
18.16
21.97
24.51
28.32
32.13
45.08
34.57
51.05
mm.
6.35
6.35
6.35
6.35
6.35
6.35
7.87
7.87
8.38
mm.
± .004 ± 0.10
7.87
10.80
10.80
10.80
10.80
10.80
10.80
11.89
13.13
.195
.195
.195
.195
.195
.195
.199
.199
.199
mm.
± .004 ± 0.10 ± .004 ± 0.10
10.01
10.01
10.01
10.01
10.01
10.01
10.01
10.01
10.01
.398
.535
.750
.785
.935
1.085
1.030
1.765
10.11
13.59
19.05
19.94
23.75
27.56
26.16
44.8
.268
.255
.255
.255
.255
.255
.297
.355
I
© 2009 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
I-6
