008016038504505: DescriptionRack and Panel Connector, 38 Contact(s), Male, Solder Terminal, Plug; CategoryThe connector The connector; File Size71KB，2 Pages; ManufacturerAVX; Environmental Compliance

Download Datasheet Parametric View All

008016038504505 Overview

Rack and Panel Connector, 38 Contact(s), Male, Solder Terminal, Plug

008016038504505 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	AVX
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	POLARIZED
Body/casing type	PLUG
Connector type	RACK AND PANEL CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL (100)
Contact completed and terminated	GOLD (10) OVER NICKEL (100)
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYESTER
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	8016
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell material	GLASS FILLED POLYESTER
Termination type	SOLDER
Total number of contacts	38
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

Varicon

®

Series 8016 – Rectangular Connector – 38 Way

PLUG

Actuating

Screw

PLUG

Fixed

Nut

SOCKET

Actuating

Screw

SOCKET

Fixed

Nut

PIN LAYOUT

38

Way

ORDERING CODE

00

Prefix

8016

Series

Number

038

Number of

Contacts

217

001

See

Variation

Code

CONNECTOR PLUG AND

RECEPTACLE COMBINATIONS

Receptacle

007/507/607

008/508/608

909/509/609

910/510/610

911/511/611

912/512/612

923/523/623

924/524/624

925/525/625

926/526/626

Plug

Contact Termination

*000 = Contacts not fitted and ordered separately,

see page 23 for full list of options

217 = Solder 0.098" x 2.49mm

218 = Wire Wrap –

0.025 x 0.050 x 0.567" / 0.64 x 1.27 x 14.4mm

296 = Wire Wrap –

0.025 x 0.026 x 0.579" / 0.64 x 1.27 x 19.3mm

504 = Solder Tail –

750 = Wire Wrap –

0.025 x 0.050 x 0.760" / 0.64 x 1.27 x 19.3mm

*Crimp contacts always ordered separately.

See page 23 for details.

001/501/601

002/502/602

903/503/603

904/504/604

905/505/605

906/506/606

919/519/619

920/520/620

921/521/621

922/522/622

931/531/631

932/532/632

933/533/633

934/534/634

Select variation code combinations marked with square in the table.

VARIATION CODE

European Version

Insulator

Body Type

Grey Polyester

Aluminum Cover

No Cover

Std.

Large Ex-Large

Clamp

Clamp Clamp

—

001

—

002

903

919

931

—

904

920

932

—

905

921

933

—

906

922

934

—

007

—

008

909

923

935

—

910

924

936

—

911

925

937

—

912

926

938

—

USA Version

Grey Polyester

Green Polyester

Aluminum Cover

No Cover

Aluminum Cover

No Cover

Std.

Large Ex-Large

Std.

Large Ex-Large

Clamp Clamp Clamp

Clamp

Clamp Clamp

—

501

—

601

—

502

—

602

503

519

531

—

603

619

631

—

504

520

532

—

604

620

632

—

505

521

533

—

605

621

633

—

506

522

534

—

606

622

634

—

507

—

607

—

508

—

608

509

523

535

—

609

623

635

—

510

524

536

—

610

624

636

—

511

525

537

—

611

625

637

—

512

526

538

—

612

626

638

—

Cover & Actu-

Cable ating

Entrance Screw

Male

(Exposed

Contacts)

Female

(Recessed

Contacts)

None

Top

Side

Top

Side

None

Top

Side

Top

Side

Yes

No

Yes

No

Yes

No

ELCO

935/535/635

936/536/636

937/537/637

938/538/638

Fixed

Nut

No

Yes

No

Yes

No

Yes

15
