PACE1754
SINGLE CHIP, 40MHz CMOS
PROCESSOR INTERFACE CIRCUIT (PIC)
FEATURES
The PACE1754 (PIC) is a support chip for the
PACE1750A/AE Processor. It eliminates the SSI/
MSI Logic and external system functions
required in typical 1750A implementations.
Provides a significant savings in part-count and
power dissipation enhancing reliability and
overall system speed performance.
Provides an optimal interface when used with
the PACE1753 MMU/COMBO in a full 1750A
implementation.
Provides the following additional important
system functions:
— Programmable READY for memory and I/O
— Automatic READY during self-test and
internal I/O instructions
— 100KHz timer clock output provided
— Programmable system watchdog—ranges
from 1 µs to 1 minute
— Programmable Bus time-out function
— Memory Parity generation/detection
— Error detection of unimplemented memory
and/or I/O space addressing
— First failing memory address register for
diagnostics
— High drive three-state address latches
— Built-in system test program—automatically
tests the PACE1750A/AE CPU, PACE1753
MMU/COMBO, PACE1754 PIC and system
address lines as well as memory and I/O
strobes
— System configuration decoding and buffering
— Interrupt acknowledge decoder and strobe
— Start up ROM support per MIL-STD-1750A
— Memory or I/O READ/WRITE three-state
strobes with external three-state control for
DMA applications
20, 30 and 40 MHz operation over full Military
Temperature Range
Single 5V ± 10% Power Supply
Power Dissipation over Military Temperature
Range
< 0.25 watts at 20 MHz
< 0.30 watts at 30 MHz
< 0.35 watts at 40 MHz
Available in:
— 64-Pin DIP or Gull Wing (50 Mil Pin centers)
— 68-Pin Pin Grid Array (PGA) (100 Mil centers)
— 68-Lead Quad Pack
PACE1754 PROCESSOR INTERFACE
CIRCUIT DESCRIPTION
The PACE1754 Processor Interface Circuit (PIC) is a
single chip implementation of many special system
functions that are often required when using the
PACE1750A/AE, single chip, 40MHz CMOS
Microprocessor. The PIC allows a system designer to
design a higher performance, more effecient
microprocessor system which uses less power and takes
up less board space than was previously possible.
In addition to providing significant savings in part count
and power dissipation the PIC uses only a 5V ±10%, single
supply and operates at 20, 30 and 40 MHz over the fully
Military Temperature Range. The PIC provides many
important system functions. These functions are governed
by respective bit positions in a programmable Control
Register which is incorporated in the PIC. The individual
bits of the control register are set to select the various
features and are set to a specified default value upon
Reset.
Document #
MICRO-5
REV C
Revised November 2005
PACE1754
ABSOLUTE MAXIMUM RATINGS
1
Supply Voltage Range
Input Voltage Range
Storage Temperature Range
Input Current Range
Current applied to any output
3
Maximum Power Dissipation
2
Lead Temperature Range
(soldering 10 seconds)
Thermal resistance (θ
JC
):
4
Cases X and T
Cases Y and U
Case Z
0.5V to +7.0V
0.5V to V
CC
+ 0.5V
–65°C to +150°C
–30mA to +5mA
150mA
1.5W
300°C
8°C/W
5°C/W
6°C/W
RECOMMENDED OPERATING
CONDITIONS
Case Temperature
–55°C to +125°C
GND
0
V
CC
4.5V to +5.5V
Notes:
1. Stresses above the absolute maximum rating may cause
permanent damage to the device. Extended operation at the
maximum levels may degrade performance and affect reliability.
2. Must withstand the added power dissipation due to short circuit
test e.g., I
OS
.
3. Duration 1 second or less.
4. Device Type Definitions from 5962-88642 SMD:
Case X: Dual In-Line
Case T: Dual In-Line with Gull-Wing Leads
Case Y: Leaded Chip Carrier with Gull-Wing Leads
Case U: Leaded Chip Carrier with Unformed Leads
Case Z: Pin Grid Array
Document #
MICRO-5
REV C
Page 2 of 20
PACE1754
DC ELECTRICAL SPECIFICATIONS
(Over recommended operating conditions)
Symbol
V
IH
V
IL
V
CD
V
OH
V
OL
V
OL
I
IH
Parameter
Input HIGH Voltage
Input LOW Voltage
Input Clamp Diode Voltage
Output HIGH Voltage
Output LOW Voltage,
except A
0
– A
15
Output LOW Voltage,
A
0
– A
15
Input HIGH Current,
except IB
0
– IB
15
, parity/IB
16
,
SING ERR, A
0
/EXT AD
0
,
A
1
/EXT AD
1
, STRBA
Input HIGH Current,
IB
0
– IB
15
, parity/IB
16
,
A
0
/EXT AD
0
, A
1
/EXT AD
1
Input HIGH Current,
STRBA, SING ERR
Input LOW Current,
except IB
0
– IB
15
, parity/IB
16
,
SING ERR, A
0
/EXT AD
0
,
A
1
/EXT AD
1
,
STRBD, TEST ON
Input LOW Current,
IB
0
– IB
15
, parity/IB
16
, SING ERR,
A
0
/EXT AD
0
, A
1
/EXT AD
1
Input LOW Current,
STRBD, TEST ON
Output Three-State Current
Output Three-State Current
Quiescent Power
Supply Current
(CMOS Input Levels)
Quiescent Power
Supply Current
(TTL Input Levels)
Dynamic Power
I
CCD
I
OS
C
IN
C
OUT
Supply Current
f = 20MHz
f = 30MHz
f = 40MHz
Output Short Circuit Current
2
Input Capacitance
Output/Bi-directional
Capacitance
–25
10
15
2.4
V
CC
– 0.2
0.5
0.2
0.5
0.2
10
Min
2.0
–0.5
Max
V
CC
+ 0.5
0.8
–1.2
Unit
V
V
V
V
V
V
V
V
V
µA
V
CC
= 4.5V, I
IN
= –18mA
V
CC
= 4.5V,
V
IN
= 0.8V, 2.0V
V
CC
= 4.5V,
V
IN
= 0.8V, 2.0V
V
CC
= 4.5V,
V
IN
= 0.8V, 2.0V
V
IN
= V
CC
,
V
CC
= 5.5V
V
IN
= V
CC
,
V
CC
= 5.5V
V
IN
= V
CC
,
V
CC
= 5.5V
V
IN
= GND,
V
CC
= 5.5V
V
IN
= GND,
V
CC
= 5.5V
V
IN
= GND,
V
CC
= 5.5V
V
OUT
= 2.4V, V
CC
= 5.5V
V
OUT
= 0.5V, V
CC
= 5.5V
V
IN
< 0.2V or > V
CC
– 0.2V
f = 0MHz, Outputs Open,
V
CC
= 5.5V
V
IN
= 3.4V, f = 0MHz,
All Inputs, Outputs Open,
V
CC
= 5.5V
V
IN
= 0V to V
CC
,
tr = tf = 2.5 ns typ.,
Outputs Open, V
CC
= 5.5V
V
OUT
= GND, V
CC
= 5.5V
Inputs Only
Outputs Only
(Including I/O Buffers)
I
OH
= –8.0mA
I
OH
= –300µA
I
OL
= 8.0mA
I
OL
= 300µA
I
OL
= 20.0mA
I
OL
= 300µA
Conditions
1
I
IH
I
IH
I
IL
50
µA
500
–10
µA
µA
I
IL
I
IL
I
OZH
I
OZL
I
CCQC
–50
–500
50
–50
10
µA
µA
µA
µA
mA
I
CCQT
50
40
50
60
mA
mA
mA
mA
mA
pF
pF
Notes:
1. 4.5V
≤
V
CC
≤
5.5V, –55°C
≤
T
C
≤
+125°C. Unless otherwise specified, testing shall be conducted at worst-case conditions.
2. Duration of the short should not exceed one second; only one output may be shorted at a time.
Document #
MICRO-5
REV C
Page 3 of 20
PACE1754
AC ELECTRICAL CHARACTERISTICS
1, 2
(V
CC
= 5V ± 10% Over Recommended Operating Conditions)
20 MHz
Symbol
tEX RDY (RDYD)
V
tC (RDYD)
V
tSTRBA
H
(A)
V
tIBA
V
(A)
V
tFC (R)
L
tSTRBD
H
(R)
H
tSTRBD
L
(W)
L
tSTRBD
H
(W)
H
tIBD
IN
(ME
PA ER)
L
tIBA
IN
(EX
AD ER)
tSTRBD
L
–
(STRT ROM)
V
tFC (IB OUT)
V
tC (TIMER CLK)
tIB IN
V
(IB16)
tEXT AD (CLKB3)
tEX
RDY1
(RDYD)
V
tFC (SCR
EN)
tSTRBD
H
(SCR
EN)
Parameter
Time from External Ready to
Ready Data Valid
Time from Clock Read to
Ready Data Valid
Time from Strobe Address HIGH to
Address Bus Valid
Time from Information Bus Address to
Address Bus Valid
Time from Falling Clock to
Read LOW
Time from Strobe Data HIGH to
Read HIGH
Time from Strobe Data LOW to
Write LOW
Time from Strobe Data HIGH to
Write HIGH
Time from Information Bus Data into
Memory Parity Error LOW
Time from Information Bus Address into
External Address Error
Time from Strobe Data LOW to
Start-up ROM Valid
Time from Falling Clock to
Information Bus Valid
Time from Rising Edge of Clock to
Timer Clock
Time from Information Bus Data to
Parity Valid
Extended Address
Setup Time
Time from External Ready Data to
Ready Data Valid
Time from Falling Clock to SCR Enable;
Case Types T and X only
Time from STRBD HIGH to SCR Enable;
Case Types T and X only
10
28
30
30
Min
Max
16
28
29
31
24
24
26
26
22
30
26
30
30
25
10
24
24
24
30MHz
Min
Max
14
22
21
22
18
18
20
20
17
25
20
25
25
20
10
21
24
24
40 MHz
Min
Max
12
16
19
20
12
12
15
15
12
20
15
25
20
18
Unit
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
Notes:
1. 4.5V
≤
V
CC
≤
5.5V, –55°C
≤
T
C
≤
+125°C. Unless otherwise specified, testing shall be conducted at worst-case conditions.
2. All measurements of delay times on active signals are related to the 1.5V levels.
Document #
MICRO-5
REV C
Page 4 of 20
