LH1547AT1 datasheet, PDF - EEWORLD Datasheet

LH1547AT1: DescriptionTransistor Output SSR, 1-Channel, 5300V Isolation; CategoryLED optoelectronic/LED photoelectric; File Size70KB，2 Pages; ManufacturerSIEMENS; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

LH1547AT1 Overview

Transistor Output SSR, 1-Channel, 5300V Isolation

Parameter Name	Attribute value
Maker	SIEMENS
Reach Compliance Code	unknown
Is Samacsys	N
Other features	UL RECOGNIZED
Configuration	SINGLE
Maximum forward current	0.05 A
Maximum insulation voltage	5300 V
Number of components	1
Maximum on-state current	0.12 A
Maximum on-state resistance	34 Ω
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	TRANSISTOR OUTPUT SSR
Base Number Matches	1

	LH1547AT1	CR-06JHB---1R3	CR-0ADL9--294R
Description	Transistor Output SSR, 1-Channel, 5300V Isolation	Fixed Resistor, Metal Glaze/thick Film, 0.25W, 1.3ohm, 200V, 5% +/-Tol, 200ppm/Cel, Surface Mount, 1206, CHIP	Fixed Resistor, Metal Glaze/thick Film, 0.75W, 294ohm, 200V, 0.5% +/-Tol, 100ppm/Cel, Surface Mount, 2010, CHIP
Reach Compliance Code	unknown	compliant	compliant
Maximum operating temperature	85 °C	155 °C	155 °C
Minimum operating temperature	-40 °C	-55 °C	-55 °C
Other features	UL RECOGNIZED	-	HIGH PRECISION
Is it Rohs certified?	-	conform to	conform to
Objectid	-	7072040864	7072061444
package instruction	-	CHIP	CHIP
Country Of Origin	-	Taiwan	Taiwan
ECCN code	-	EAR99	EAR99
YTEOL	-	7.65	7.9
structure	-	Chip	Chip
JESD-609 code	-	e3	e3
Installation features	-	SURFACE MOUNT	SURFACE MOUNT
Number of terminals	-	2	2
Package height	-	0.55 mm	0.55 mm
Package length	-	3.1 mm	5 mm
Package shape	-	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
Package form	-	SMT	SMT
Package width	-	1.55 mm	2.5 mm
method of packing	-	TR, PAPER, 10 INCH	TR, EMBOSSED PLASTIC, 10 INCH
Rated power dissipation(P)	-	0.25 W	0.75 W
Rated temperature	-	70 °C	70 °C
resistance	-	1.3 Ω	294 Ω
Resistor type	-	FIXED RESISTOR	FIXED RESISTOR
size code	-	1206	2010
surface mount	-	YES	YES
technology	-	METAL GLAZE/THICK FILM	METAL GLAZE/THICK FILM
Temperature Coefficient	-	200 ppm/°C	100 ppm/°C
Terminal surface	-	Matte Tin (Sn) - with Nickel (Ni) barrier	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	-	WRAPAROUND	WRAPAROUND
Tolerance	-	5%	0.5%
Operating Voltage	-	200 V	200 V
