NTE30041 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> NTE30041

NTE30041: DescriptionSuper Bright LED Indicators, 5mm; CategoryLED optoelectronic/LED photoelectric; File Size93KB，3 Pages; ManufacturerNTE; Websitehttp://www.nteinc.com; Environmental Compliance

Download Datasheet Parametric Compare View All

NTE30041 Overview

Super Bright LED Indicators, 5mm

NTE30041 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	NTE
Reach Compliance Code	unknow
Optoelectronic device types	SINGLE COLOR LED
Base Number Matches	1

Preview

Download Datasheet

View All

NTE30037 thru NTE30043,

NTE30045

Super Bright LED Indicators, 5mm

Features:

All Plastic Mold Type

/Water Clear Lens:

NTE30037 (Yellow Green, AllGaP/GaAs)

NTE30038 (Pure Green, GalnN/GaN)

NTE30039 (Yellow, AllnGaP/GaP)

NTE30040 (Orange, AllnGaP/GaAs)

NTE30041 (Deep Red, GaAlAs/GaAlAs)

NTE30042 (Amber, AllGaP/GaAs)

NTE30043 (Blue, GalnN/GaN)

NTE30045 (White, GalnN/GaN)

Absolute Maximum Ratings:

= +25°C unless otherwise specified)

Reverse Voltage, V

NTE30038

Only

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4V

All other devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V

Continuous Forward Current, I

NTE30037, NTE30038, NTE30040, NTE30041, NTE30042 . . . . . . . . . . . . . . . . . . . . . . 25mA

NTE30039, NTE30043, NTE30045 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30mA

Peak Forward Current (1.10 Duty Cycle, 0.1ms Pulse Width), I

NTE30037, NTE30040, NTE30041, NTE30042 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50mA

NTE30038, NTE30039, NTE30043, NTE30045 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mA

Power Dissipation, P

NTE30037, NTE30039, NTE30040, NTE30042 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mW

NTE30041 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110mW

NTE30038, NTE30043, NTE30045 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120mW

Operating Temperature Range, T

opr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +85°C

Storage Temperature Range, T

stg

NTE30038

Only

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−40°C

to +100°C

All other devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +100°C

Lead Temperature (During Soldering, .063 (1.6mm) from body, 5sec max), T

. . . . . . . . . . . +260°C

Electro−Optical Characteristics:

= +25°C unless otherwise specified)

Parameter

Forward Voltage

NTE30037

NTE30038

NTE30039

NTE30040

NTE30041

NTE30042

NTE30043

NTE30045

Symbol

Test Conditions

= 20mA

Min

−

Typ

2.2

3.5

2.25

2.0

1.86

2.0

3.5

3.6

Max

2.4

4.0

2.6

2.5

2.4

4.0

Unit

NTE30041 Related Products

	NTE30041	NTE30039	NTE30037	NTE30040	NTE30045	NTE30043
Description	Super Bright LED Indicators, 5mm	Super Bright LED Indicators, 5mm	Super Bright LED Indicators, 5mm	Super Bright LED Indicators, 5mm	Super Bright LED Indicators, 5mm	Super Bright LED Indicators, 5mm
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
Reach Compliance Code	unknow	unknow	unknown	unknow	unknow	unknown
Optoelectronic device types	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED
Maker	NTE	NTE	NTE	NTE	-	NTE
Base Number Matches	1	-	1	-	1	1
