3-1565030-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> socket> 3-1565030-1

3-1565030-1: DescriptionSOCKET, PGA478, IC SOCKET; CategoryThe connector socket; File Size106KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

3-1565030-1 Overview

SOCKET, PGA478, IC SOCKET

3-1565030-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Other features	STANDARD: UL 94V-0, LOW PROFILE
Contact to complete cooperation	GOLD (30)
Contact completed and terminated	GOLD (30)
Contact material	COPPER ALLOY
Device slot type	IC SOCKET
Type of equipment used	PGA478
Shell material	PLASTIC
JESD-609 code	e4
Manufacturer's serial number	1565030
Number of contacts	478
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Socket/C ard Products

Product Feature Selector

> Product Details

3-1565030-1 Product Details

Live Product Chat

Product View

PGA Sockets

5 of 6 EU R oHS/ELV C om plia nt

(

Find R oHS C om plia nt

Alte rna te s

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3-1565030-1

T E I nternal N umber: 3 - 1 5 6 5 0 3 0 - 1

Product Highlights:

Zero Insertion Force

Number of Positions = 478

PC B Mount Style = Surface Mount

Grid Size = 26x26

Grid Spacing = 1.27 x 1.27 mm

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

mPGA SOC KET 479&478X (3H) C AM TYPE for Mobile PC

(PDF, Japanese)

Application Specifications:

None Available

Instruction Sheets:

mPGA Socket 479&478X (3H) C AM TYPE for Mobile PC

(PDF, Japanese)

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Insertion Force

= Zero

Number of Positions

= 478

PC B Mount Style = Surface Mount

Grid Size

= 26x26

Grid Spacing (mm [in])

= 1.27 x 1.27 [.050 x .050]

C hip C ompatibility

= Intel? Pentium? 4 (mPGA478B pattern)

Frame Style

= Open

Heat Sink Attachment

= Without

ZIF Actuator

= Screwdriver/C am

Profile

= Low

C over Material = High Temperature Thermoplastic

Leg Style = Ball Grid Array (BGA)

Termination Related Features:

Socket Identifier = mPGA478M

Body Related Features:

Assembly Process Feature = Pick and Place C over, Tape

C over C olor = Gray

Socket Overall Height (mm [in]) = 3 [0.118]

Contact Related Features:

C ontact Style

= Stamped + Formed

C ontact Base Material = C opper Alloy

C ontact Mating Area Plating Material = Gold (30)

Housing Related Features:

Housing C olor = Black

Housing Material = High Temperature Thermoplastic

Housing Flammability Rating = UL 94V-0

Housing Material Temperature = High

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant, 5 of 6 C ompliant

Lead Free Solder Processes

= Not suitable for lead free processing

Operation/Application:

Application

= Production

Packaging Related Features:

Packaging Method = Tape Mounted on Reel

Packaging Quantity = 160 sockets/reel

Other:

Brand = AMP

Additional Information:

Product Line Information
