5146140-5 Product Details
Live Product Chat
.100 inch AMPMODU Receptacles
Always EU R oHS/ELV C om pliant
(
Sta te m e nt of C om pliance
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5146140-5
T E I nternal N umber: 5 1 4 6 1 4 0 - 5
Product Highlights:
l
C onnector
l
C onnector Type = C onnector - Receptacle
l
Mod II
l
12 Positions
l
Number of Rows = Dual
View all Features
Active
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
AMPMODU_INTERC ONNEC TION_SYSTEM_SEC TION5
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
AMPMODU Mod II and Mod IV Printed C ircuit Board C onn...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type = C onnector - Receptacle
l
C onnector Series
= Mod II
l
Number of Positions
= 12
l
Profile
= Standard
l
Mount Angle
= Right Angle
l
Mounting Pattern (mm [in])
= 2.54 x 7.87 [.100 x .310]
l
Sealed
= No
l
Holddown Feature
= Without
l
PC B Retention Feature = No
l
C losed Entry = With
l
Board Standoff = With
l
C omment = 6.50 [.256] minimum positive pin stop to prevent
shorting between rows.; Tyco Electronics recommends mating gold
or duplex plated headers with duplex plated receptacle assemblies.
Mechanical Attachment:
l
Stackable
= Yes
Electrical Characteristics:
l
C ontact C urrent Rating (Amps.) = 2
l
C ontact Resistance (m?) = 12
l
Insulation Resistance (M?) = 5,000
l
Dielectric Withstanding Voltage (V) = 750
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.92 [0.115]
l
Solder Tail C ontact Plating = Tin over Nickel
Body Related Features:
l
Number of Rows
= Dual
l
C onnector Height (mm [in])
= 6.05 [0.238]
l
C enterline, Matrix (mm [in])
= 2.54 x 2.54 [.100 x .100]
Contact Related Features:
l
C ontact Termination Type
= Through Hole
l
C ontact Plating, Mating Area, Material
= Gold (10)
l
C ontact Base Material = Phosphor Bronze
l
Approved Standards = UL E28476, C SA LR7189
l
C ontact Type = Short Point
Housing Related Features:
l
Housing Entry Style = Side
l
Housing Material = Polyester PC T
l
Housing Flammability Rating = UL 94V-0
l
Housing C olor = Black
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Operating Temperature (?C ) = -55 – +125
l
High Temperature C ompatible = Yes
Packaging Related Features:
l
Packaging Method = Gang of Tubes
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
