BZM55C-BS
SERIES
4.7V to 36V
SILICON PLANAR ZENER DIODE
FEATURES
* Zener Voltage Range 4.7 to 36 Volts
* LS-31 (Micro-melf) Glass Package
MICRO-MELF
.0
53
m (1.
ax 35
)
.
.049 (1.25)
DIA.
.047 (1.20)
R > 2.5
Glass
.010 (0.26)
.008 (0.21)
.083 (2.10)
.075 (1.90)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Dimensions in inches and (millimeters)
MAXIMUM RATINGES
( @ T
A
= 25 C unless otherwise noted )
RATINGS
Power Dissipation @ R
th (j-a)
< 300 C/W
O
o
SYMBOL
P
D
Tstg
T
J
VALUE
500
-65 to +175
175
UNITS
mW
O
Storage Temperature
Junction Temperature
THERMAL RESISTANCE
From Junction to Ambient in free air
Form Junction to Tie point (Note 1)
Notes: 1. 35 um copper clad, 0.9mm
2
copper area per electrode.
2. "Fully RoHS Compliant", "100% Sn Plating (Pb-free)".
C
C
O
Rth(j-a)
Rth(j-l)
500
300
K/W
K/W
VD 2007-11
ELECTRICAL CHARACTERISTICS
V
ZT
@I
ZT
TYPE
MIN
BZM55C 30BS
BZM55C 30BSA
BZM55C 30BSB
BZM55C 30BSC
BZM55C 30BSD
BZM55C 33BS
BZM55C 33BSA
BZM55C 33BSB
BZM55C 33BSC
BZM55C 33BSD
BZM55C 36BS
BZM55C 36BSA
BZM55C 36BSB
BZM55C 36BSC
BZM55C 36BSD
26.99
26.99
27.70
28.36
29.02
29.68
29.68
30.32
30.90
31.49
32.14
32.14
32.79
33.40
34.01
(V)
(Note)
MAX
30.51
28.39
29.13
29.82
30.51
33.11
31.22
31.88
32.50
33.11
35.77
33.79
34.49
35.13
35.77
80
80
80
R
ZT
@I
ZT
(
W
)
MAX
(Note)
(@TA=25 C unless otherwise specified)
O
I
ZT
( mA )
I
R
@T
A
=25
O
C
( uA )
MAX
V
R
(V)
V
F
@ 100mA
(V)
5.0
0.2
23
1.0
5.0
0.2
25
1.0
5.0
0.2
27
1.0
NOTE: Pulse Condition : 20mS < tp < 50mS, Duty Cycle < 2%.
