"High Frequency Ceramic Solutions"
2.45 GHz Band Pass Filter
Detail Specification: 08/12/03
P/N 2450BP39C100C
Page 1 of 2
General Specifications
Part Number
Frequency (MHz)
Insertion Loss
Return Loss
Attenuation (min.)
Attenuation (min.)
Attenuation (min.)
Attenuation (min.)
Attenuation (min.)
2450BP39C100C
2400 - 2500
1.5 dB max.
9.5 dB min.
880 ~ 915MHz
1710 ~ 1785MHz
1850 ~ 1910MHz
4800 ~ 5000MHz
7200 ~ 7500MHz
30 dB
30 dB
25 dB
25 dB
15 dB
Terminal Configuration
No.
Input Power
Impedance
Operating Temperature
Reel Quanity
500 mW max.
50
Ω
-40 to +85°C
3,000
Function
GND
OUT
GND
IN
1
2
3
4
Mechanical Dimensions
In
L
0.098 ± 0.008
W
0.079 ± 0.008
T
0.035 ± 0.004
0.012 ± 0.008
b
0.024 ± 0.008
c
0.012 ± 0.008
a
mm
2.50 ± 0.20
2.00 ± 0.20
0.90 ± 0.10
0.30 ± 0.20
0.60 ± 0.20
0.30 ± 0.20
c
W
a
b
L
T
Mounting Considerations
Mount these devices with brown mark facing up.
Line width should be designed to provide 50Ω impedance matching characteristics.
Units: mm
2.50
Solder Resist
1.40
*
1.05
*
0.6
Land
Through-hole ( 0.35)
φ
1.0
1.9
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2003 Johanson Technology, Inc. All Rights Reserved
"High Frequency Ceramic Solutions"
2.45 GHz Band Pass Filter
Detail Specification: 08/12/03
P/N 2450BP39C100C
Page 2 of 2
Typical Electrical Characteristics (T=25°C)
)
)
)
)
)
)
)
)
Insertion/Return Loss
)
)
S11 (dB)
S22 (dB)
)
S12 (dB)
)
)
Frequency (GHz)
