"High Frequency Ceramic Solutions"
2450 / 5512 MHz Diplexer
Detail Specification: 07/21/03
P/N 2450DP15B5512
Page 1 of 2
General Specifications
Part Number
Frequency (MHz)
Attenuation
Low Band
Attenuation
High Band
Pass-band Return Loss
0.7 dB max.
15 dB min.
9.5 dB min.
20 dB min.
0.9 dB max.
9.5 dB min.
2450DP15B5512
2400-2500
5150-5875
Input Power
Impedance
Operating Temp.
Reel Quanity
3 Watts max.
50
Ω
-40 to +85°C
4,000
Terminal Configuration
No.
Function
GND
GND
GND
GND
GND
1
Mechanical Dimensions
In
L
0.079 ± 0.004
W
0.049 ± 0.004
T
0.033 ± 0.004
a
0.012 ± 0.004
b
0.008 ± 0.004
c
0.012
+.004/-.008
g
0.014 ± 0.004
p
0.026 ± 0.002
mm
2.00 ± 0.10
1.25 ± 0.10
0.85 ± 0.10
0.30 ± 0.10
0.20 ± 0.10
0.30
+0.1/-0.2
0.35 ± 0.10
0.65 ± 0.05
Unit : mm
L
a
p
a
c
W
2
Common Port (P1)
3
5
6
7
4
Low Freq. Port (P3)
8
High Freq. Port (P2)
T
g
b
Mounting Considerations
Mount these devices with brown mark facing up.
Line width should be designed to provide 50Ω impedance matching characteristics.
Units: mm
2.80
*
Solder Resist
0.35
1.65
*
0.30
Land
Through-hole ( 0.35)
*
0.35
1.0
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2003 Johanson Technology, Inc. All Rights Reserved
"High Frequency Ceramic Solutions"
2450 / 5512 MHz Diplexer
Detail Specification: 07/21/03
P/N 2450DP15B5512
Page 2 of 2
Typical Electrical Performance
)
)
)
Attenuation
)
)
)
)
0
)
)
-10
d B(S (3 ,1))
d B(S (2 ,1))
-20
-30
-40
-50
1
2
3
)
)
4
5
6
freq, GHz
)
)
Return Loss
0
)
-10
)
)
dB(S(3,3))
dB(S(2,2))
dB(S(1,1))
-20
-30
-40
-50
1
2
3
)
4
5
6
freq, GHz
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2003 Johanson Technology, Inc. All Rights Reserved
