NCP1200D100R2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> NCP1200D100R2

NCP1200D100R2: Description0.25A SWITCHING CONTROLLER, 116kHz SWITCHING FREQ-MAX, PDSO8, SOIC-8; CategoryPower/power management The power supply circuit; File Size940KB，17 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

NCP1200D100R2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	NCP1200D100R2	-	-	View	Buy Now

NCP1200D100R2 Overview

0.25A SWITCHING CONTROLLER, 116kHz SWITCHING FREQ-MAX, PDSO8, SOIC-8

NCP1200D100R2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Parts packaging code	SOIC
package instruction	SOIC-8
Contacts	8
Reach Compliance Code	unknown
Is Samacsys	N
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
Minimum input voltage	11 V
Nominal input voltage	11 V
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Humidity sensitivity level	NOT SPECIFIED
Number of functions	1
Number of terminals	8
Maximum output current	0.25 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
Certification status	COMMERCIAL
Maximum seat height	1.75 mm
surface mount	YES
Switch configuration	SINGLE
Maximum switching frequency	116 kHz
technology	CMOS
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	3.9 mm
Base Number Matches	1
