5-1393779-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> relay> 5-1393779-4

5-1393779-4: DescriptionPOWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.067A (COIL), 3VDC (COIL), 200mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size101KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

5-1393779-4 Overview

POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.067A (COIL), 3VDC (COIL), 200mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT

5-1393779-4 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Maximum coil current (DC)	0.067 A
Coil power	200 mW
Coil resistance	20 Ω
Maximum coil voltage (DC)	3 V
Coil/Input Power Type	DC
Maximum contact current (AC)	1 A
Maximum contact current (DC)	1 A
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1393779
Installation features	THROUGH HOLE-STRAIGHT MOUNT
Guideline	CSA; UL
Relay action	MOMENTARY
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
surface mount	NO
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

T81H5D312-03 Product Details

Communications/Signal PC Board Relays

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

T81H5D312-03

(5-1393779-4)

T E I nternal N umber: 5 - 1 3 9 3 7 7 9 - 4

Product Highlights:

T81H Series

DC Actuating System

Input Voltage = 3 VDC

C ontact Arrangement = 1 Form C , SPDT, 1 C /O

C ontact C urrent Rating = 1 Amps.

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

T81N/T81H Ultraminiature, High Density PC Board Relay

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type = Through Hole

Electrical Characteristics:

Actuating System = DC

Input Voltage (VDC ) = 3

C ontact C urrent Rating (Amps.) = 1

C oil Resistance (?)

= 20

C oil Power, Nominal (mW) = 200

Body Related Features:

Series

= T81H

Contact Related Features:

Mounting Options = PC Board

Enclosure = Sealed

FC C Part 68 Isolation

= Yes

Approved Standards = C SA C ertified, UL Recognized

C ontact Base Material = Silver-Palladium Alloy with Gold Overlay

Configuration Related Features:

C ontact Arrangement

= 1 Form C , SPDT, 1 C /O

C oil Magnetic System

= Monostable

C oil Suppression Diode = Without

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Other:

Brand = Potter & Brumfield

Additional Information:

Product Line Information

Additional Product Images:

Schematic

PC B Layout

Wiring Diagram

5-1393779-4 Related Products

	5-1393779-4	T81H5D312-03
Description	POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.067A (COIL), 3VDC (COIL), 200mW (COIL), 1A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT	POWER/SIGNAL RELAY, SPDT, MOMENTARY, 0.067A (COIL), 3VDC (COIL), 200mW (COIL), 1A (CONTACT), 24VDC (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
package instruction	ROHS COMPLIANT	ROHS COMPLIANT
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Maximum coil current (DC)	0.067 A	0.067 A
Coil power	200 mW	200 mW
Coil resistance	20 Ω	20 Ω
Maximum coil voltage (DC)	3 V	3 V
Coil/Input Power Type	DC	DC
Maximum contact current (AC)	1 A	1 A
Maximum contact current (DC)	1 A	1 A
Contact/Output Power Type	AC/DC	AC/DC
Manufacturer's serial number	1393779	T81H
Installation features	THROUGH HOLE-STRAIGHT MOUNT	THROUGH HOLE-STRAIGHT MOUNT
Guideline	CSA; UL	CSA; UL
Relay action	MOMENTARY	MOMENTARY
Relay function	SPDT	SPDT
Relay type	POWER/SIGNAL RELAY	POWER/SIGNAL RELAY
surface mount	NO	NO
Termination type	SOLDER	SOLDER

Recommended Resources
