117215473 Product Details
Industrial Relays (General Purpose)
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
PCJ Series
Contact Current Class = 2A to 5A Class, Less Than
16A
Contact Rated Current = 5 A
Terminal Type = PCBTHT
Contact Arrangement = 1 Form A (NO)
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
117215473
TE Internal Number: 117215473
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
PCJWG,SPEC 000M CUSTOMER DRAWING (PDF, English)
Catalog Pages/Data Sheets:
PCJ Series Relay Data Sheet English (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact Current Class = 2A to 5A Class, Less Than 16A
Contact Rated Current (A) = 5
Contact Limiting Continuous Current (A) = 5
Contact Limiting Making Current (A) = 5
Contact Limiting Breaking Current (A) = 5
Insulation Initial Dielectric Between Coil/Contact Class = 3500V to
4000V Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 750
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
4000
Contact Rated Voltage (VAC) = 250
Contact Switching Voltage Max. (VAC) = 250
Contact Switching Voltage Max. (VDC) = 30
Contact Limiting ShortTime Current (A) = 5
Contact Switching Recommended Load, Min. = 100mA at 5V
Coil Rated Voltage (VDC) = 18
Coil Resistance (Ω) = 1620
Coil Rated Power, DC (mW) = 200
Coil Rated Power Class = 150mW to 200mW Class
Insulation Initial Insulation Resistance (MΩ) = 1000000
Insulation Creepage Class = 5.5mm to 8mm Class
Insulation Clearance Class = 5mm to 8mm Class
Insulation Special Features = 7000V Initial Surge Withstand Voltage
between Contacts and Coil
Dimensions:
Mechanical Length Class = 20mm to 25mm Class
Length (mm [in]) = 20.39 [0.803]
Mechanical Width Class = 6mm to 8mm Class
Width (mm [in]) = 7.00 [0.276]
Body Features:
Mount Type = PCB
Weight (g [oz]) = 4.00 [0.141]
Contact Features:
Terminal Type = PCBTHT
Contact Material = AgNi
Contact Number of Poles = 1
Configuration Features:
Contact Arrangement = 1 Form A (NO)
Coil Magnetic System = Monostable, DC
Coil Special Features = UL Coil Insulation Class F
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant
Approved/Registered Standards = CQC, UL, CSA, VDE
Environmental:
Environmental Category of Protection = RTIII
Environmental Ambient Temperature, Max. (°C [°F]) = 85 [185]
Environmental Ambient Temperature Class = 70°C to 85°C Class
Packaging Features:
Packaging Method = Box/Carton
Other:
Series = PCJ
Brand = OEG
