1-1437596-0 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> switch> 1-1437596-0

1-1437596-0: DescriptionRocker Switch, ROCKER SWITCH, DPDT, LATCHED, PANEL MOUNT; CategoryMechanical and electronic products switch; File Size107KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

1-1437596-0 Overview

Rocker Switch, ROCKER SWITCH, DPDT, LATCHED, PANEL MOUNT

1-1437596-0 Parametric

Parameter Name	Attribute value
Brand Name	Alcoswitch
Is it Rohs certified?	incompatible
Reach Compliance Code	unknown
ECCN code	EAR99
Actuator type	TOP ROCKER
illumination	GREEN AND RED LED
Manufacturer's serial number	1437596
Installation features	PANEL MOUNT
surface mount	NO
Switch action	LATCHED
switch function	DPDT
Switch type	ROCKER SWITCH
Termination type	WIRE
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Switches

Product Feature Selector

> Product Details

TRD21P10WLL25 Product Details

Live Product Chat

Rocker/Paddle Switches

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

TRD21P10WLL25

(1-1437596-0)

T E I nternal N umber: 1 - 1 4 3 7 5 9 6 - 0

Product Highlights:

C ontact Rating = 0.4VA

Double Pole - Double Throw C onfiguration (Pole-Throw)

Gold C ontact Plating

TRD Series

Operating Function = On Off On

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

ALC OSWITC H PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

C onfiguration (Pole-Throw) = Double Pole - Double Throw

Actuator Style = Rocker

Actuator Type = Top

Termination Type = Wire Lugs

Mount = Panel

Electrical Characteristics:

C ontact Rating = 0.4VA

Body Related Features:

Series = TRD

Actuator C olor = Black

Mount Style = 15/32" Round Hole

LED = With

Contact Related Features:

C ontact Plating = Gold

Configuration Related Features:

Operating Function = On Off On

LED C olor = Red/Green (Bi-C olor)

Indicator/Imprint Legend = None

Beveled Frame C olor = Black

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

Purchasing Information:

Lamp = Without

Other:

Brand = Alcoswitch

Additional Information:

Product Line Information

1-1437596-0 Related Products

	1-1437596-0	TRD21P10WLL25
Description	Rocker Switch, ROCKER SWITCH, DPDT, LATCHED, PANEL MOUNT	Rocker Switch, ROCKER SWITCH, DPDT, LATCHED, PANEL MOUNT
Brand Name	Alcoswitch	Alcoswitch
Is it Rohs certified?	incompatible	incompatible
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Actuator type	TOP ROCKER	TOP ROCKER
illumination	GREEN AND RED LED	GREEN AND RED LED
Manufacturer's serial number	1437596	TRD
Installation features	PANEL MOUNT	PANEL MOUNT
surface mount	NO	NO
Switch action	LATCHED	LATCHED
switch function	DPDT	DPDT
Switch type	ROCKER SWITCH	ROCKER SWITCH
Termination type	WIRE	WIRE
