1437571-7

Description
PUSHBUTTON SWITCH, SPST, MOMENTARY, 0.02A, 20VDC, THROUGH HOLE-STRAIGHT
CategoryMechanical and electronic products    switch
File Size129KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

1437571-7 Overview

PUSHBUTTON SWITCH, SPST, MOMENTARY, 0.02A, 20VDC, THROUGH HOLE-STRAIGHT

1437571-7 Parametric

Parameter NameAttribute value
Brand NameAlcoswitch
Is it Rohs certified?incompatible
Objectid1279016842
Reach Compliance Codeunknown
ECCN codeEAR99
Actuator colorBLUE
Actuator length0.125 inch
Actuator materialTHERMOPLASTIC
Actuator stroke0.762 mm
Actuator typePUSHBUTTON
body width5.23 mm
body height8.13 mm
Body length or diameter8.13 mm
Casing diameter
Nozzle length
center contact materialCOPPER ALLOY
Center contact platingGOLD OVER NICKEL
Contact (AC) maximum rated power R load0.4VA@20VAC
Contact (AC) maximum rated R load.02A@20VAC
Maximum contact current (AC)0.02 A
Maximum contact current (DC)0.02 A
Contact (DC) maximum rated R load.02A@20VDC
Contact function(N.O.) (N.C.)
Contact resistance0.02 mΩ
contact timeBREAK-BEFORE-MAKE
Maximum contact voltage (AC)20 V
Maximum contact voltage (DC)20 V
Dielectric withstand voltage1000VAC V
Electrical life100000 Cycle(s)
End contact materialCOPPER ALLOY
End contact platingGOLD OVER NICKEL
Shell materialPOLYESTER
Insulation resistance1000000000 Ω
Installation featuresTHROUGH HOLE-STRAIGHT
Maximum operating force2.5 N
Maximum operating temperature65 °C
Minimum operating temperature-30 °C
PCB hole count3
sealEPOXY TERMINAL SEALED
surface mountNO
Switch actionMOMENTARY
switch functionSPST
Switch typePUSHBUTTON SWITCH
Terminal length0.13 inch
Terminal materialCOPPER ALLOY
Termination typeSOLDER

Preview

Download Datasheet
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Switches & Knobs > Product Feature Selector > Product Details
TP11CGPC6 Product Details
Pushbutton Switches
Not EU RoHS or ELV Compliant
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Switch
Not Tactile
Single Pole ­ Single Throw Configuration (Pole­Throw)
Contact Rating = 0.4VA
Operating Function = Normally Open, Momentary
TP11CGPC6
(1437571­7)
TE Internal Number: 1437571­7
View all Features
 Superseded
Search for Replacement Parts
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
PUSH BUTTON SWITCH TP11CG/FG­PC(*) AND TP21CCG/FFG­PC(*) (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Switch
Mount Angle = Vertical
Actuator Style = Square
Electrical Characteristics:
Contact Rating = 0.4VA
Termination Features:
Termination Type = Printed Circuit
Dimensions:
Actuator Length (mm [in]) = 3.15 [0.124]
Body Features:
Mount Style = Through­Hole
Actuator Profile = Extended
Actuator Color = Blue
Case Material = Polyester
Actuator Material = Polyamide
Contact Features:
Contact Plating = Gold over Nickel
Housing Features:
Process Sealed = No
Low Profile = No
Configuration Features:
Tactile = No
Configuration (Pole­Throw) = Single Pole ­ Single Throw
Operating Function = Normally Open, Momentary
Ganged = No
ESD Grounding Terminal = Without
Number of Actuators = Single
Illuminated = No
Dust Proof = No
Support Bracket = Without
Snap Action = Without
Industry Standards:
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
Conditions for Usage:
Temperature Rating = High
Operation/Application:
Actuator Force (g [oz]) = 50.00 – 400.00 [1.770 – 14.120]
Packaging Features:
Packaging Method = Loose Piece
Other:
Series = TP
Brand = Alcoswitch
Comment = No center terminal
