DUAL-IN-LINE
SOCKETS
SERIES 117, 317 • GULL WING SHRINK DIP SOCKETS & STRIPS, SMT SOLDER TAIL
0,38-0,64
0,25 * 0,46
317...105
B
2,64
•
Surface mount Gull Wing DIP & strip sockets
•
5,59
3,68
2,11
2,79
5,59
2,79
0,46
3,45 PAD
2,26
4,52
2,54
•
•
3,56
0,81
0,79
0,51 DIA.
0,99
•
•
117...105
5,08
See page 132 for Insulator Details
for devices featuring 1,78 lead spacing
Gull wing terminals provide maximum
strength and permit easy visual inspection of
solder joints
Hi-Rel, 4-finger BeCu #30 contact is rated at
3 amps. See page 253 for details
Series 117 and 317 use MM #1802 pins. See
page 169 for details
Insulators are high temperature thermoplastic,
suitable for all soldering operations
For Electrical, Mechanical and Environmental
Data, see page 264 for details
Total number
of pins
A
B
2,54
C
Quantity
per tube
ORDERING INFORMATION
A
14,53
B
7,62
C
9,91
16
28
30
48
20
28
40
42
48
52
56
64
68
64
35
20
18
12
28
20
14
13
12
11
10
9
8
8
117-XX-316-41-105000
117-XX-428-41-105000
117-XX-430-41-105000
117-XX-448-41-105000
117-XX-620-41-105000
117-XX-628-41-105000
117-XX-640-41-105000
117-XX-642-41-105000
117-XX-648-41-105000
117-XX-652-41-105000
117-XX-656-41-105000
117-XX-664-41-105000
117-XX-668-41-105000
117-XX-764-41-105000
RoHS - 2
25,20 10,16 12,45
26,97 10,16 12,45
42,98 10,16 12,45
18,08
25,20
35,86
37,64
42,98
46,53
50,09
57,20
60,76
15,24
15,24
15,24
15,24
15,24
15,24
15,24
15,24
15,24
17,53
17,53
17,53
17,53
17,53
17,53
17,53
17,53
17,53
57,20 19,05 21,34
PAGE 126 | IC SOCKETS / TO SOCKETS
XX=Plating Code
See Below
A = 37,64 FOR 21 POS.
2,64
1,78
2011/65/EU
If desired, we will supply any length up to 21 pins.
-
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
317-XX-121-41-105000
91
5,08μm Sn/Pb
0,25μm Au
SINGLE ROW STRIP SOCKET
21
37,64
---
2,64
See page 264 for coplanarity
information
41
5,08μm Sn
0,25μm Au
43
5,08μm Sn
0,76μm Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
