5379K Series
Features
Package
2.5×5 Semi-Round shape type,
MBG,MPG : Pale Green Diffused epoxy
MPY,MAY : Pale Yellow Diffused epoxy
MAA : Pale Orange Diffused epoxy
MVR,BR,MPR : Pale Red Diffused epoxy
・Outer
Dimension 2.5×5 Semi-Round shape type
・Operation
temperature range.
Storage Temperature
:-30℃½100℃
Operating Temperature
:-30℃½85℃
・No
lead package and lead–free soldering compatible
・RoHS
compliant
Green
Yellow Green
Yellow
Orange
Red
: 558nm (MBG)
567nm (MPG)
: 572nm (MPY)
: 590nm (MAY)
: 606nm (MAA)
: 624nm (MVR)
647nm (BR)
630nm (MPR)
Single Color Semi-Round Shape Type
Product features
Dominant wavelength
Half Intensity Angle
MBG :
θx=28
deg.
θy=18
deg.,
MPG
θx=24
deg.
θy=15
deg.
MPY :
θx=25
deg.
θy=19
deg.,
MAY
θx=24
deg.
θy=18
deg.
MAA,BR :
θx=25
deg.
θy=15
deg., MVR
θx=23
deg.
θy=14
deg.
MPR
θx=24
deg.
θy=13
deg.
Die materials
Rank grouping parameter
Soldering methods
ESD
Packing
MBG, MPG, MPY, MPR : GaP
MAY, MAA, MVR : GaAsP
BR : GaAlAs
Sorted by luminous intensity per rank taping
TTW (Through The Wave) soldering and manual soldering
More than 2kV(HBM)
Bulk : 200pcs(MIN.)
Recommended Applications
Amusement Equipment, Electric Household Appliances, OA/FA, Other General Applications
2005.3.31
Page 1
5379K Series
Single Color Semi-Round Shape Type
Color and Luminous Intensity
Emitted
Color
L ens
Color
Dominant
Wavelength
λ
d (nm)
T YP.
I
F
MIN.
(Ta=25℃)
Luminous Intens ity
Iv (mc d)
T YP.
I
F
P art No.
Material
MBG5379K
MP G5379K
MP Y5379K
MAY5379K
MAA5379K
MVR5379K
B R5379K
MP R5379K
Ga P
Ga P
Ga P
Ga AsP
Ga AsP
Ga AsP
Ga AlAs
Ga P
Gre e n
Gre e n
Ye llow Gre e n
Ye llow
Ora ng e
Re d
Re d
Re d
P a le
Gre e n
558
567
572
590
Diffu se d
606
624
20
20
20
20
20
20
20
10
3
12
20
12
12
10
12
1.5
6
24
40
24
24
20
24
3.0
20
20
20
20
20
20
20
10
P a le
Ye llow
P a le
Ora ng e
P a le
Re d
647
630
2004.10.29
Page 2
5379K Series
Single Color Semi-Round Shape Type
Absolute Maximum Ratings
Absolute Ma x imum Ra ting s
MBG
70
25
60
0.33
4
MP G
70
25
60
0.33
4
MP Y
85
30
75
0.40
4
MAY
85
30
75
0.40
4
MAA
70
25
60
0.33
4
MVR
75
30
75
0.40
4
BR
100
50
300
0.67
4
(Ta=25℃)
Ite m
P ow e r Dissipa tion
F orwa rd Curre nt
P ulse F orw a rd
Curre nt
※
1
De ra ting
(T a =25
℃
or hig he r)
Re ve rse Volta g e
Ope ra ting
T e mpe ra ture
S tora g e
T e mpe ra ture
S ymbol
P
d
I
F
I
F R M
⊿
I
F
V
R
T
opr
T
s tg
MP R
75
30
75
0.40
4
Unit
mW
mA
mA
mA/
℃
V
℃
℃
-30
½
+85
-30
½
+100
※1
I
FRM
Measurement condition : Pulse Width≦1ms., Duty≦1/20.
2004.10.29
Page 3
5379K Series
Single Color Semi-Round Shape Type
Electro-Optical Characteristics(
MBG,MPG,MPY,MAY,MAA,MVR,BR
)
Characteristics
MBG
TYP.
Forward Voltage
I
F
=20mA
V
F
MAX.
Reverse Current
Peak Wavelength
Dominant
Wavelength
Spectral Line Half
Width
Half Intensity
Angle
V
R
=4V
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
R
λ
p
λ
d
⊿λ
MAX.
TYP.
TYP.
TYP.
2.8
20
555
558
30
28(θx)
I
F
=20mA
2θ1/2
TYP.
18(θy)
15(θy)
19(θy)
18(θy)
15(θy)
14(θy)
2.8
20
560
567
30
24(θx)
2.8
20
570
572
30
25(θx)
2.8
20
580
590
30
24(θx)
2.8
20
605
606
30
25(θx)
2.8
20
630
624
30
23(θx)
2.1
MPG
2.1
MPY
2.1
MAY
2.2
MAA
2.2
MVR
2.0
(Ta=25℃)
Item
Conditions
Symbol
Unit
BR
1.7
V
2.0
100
660
647
30
25(θx)
deg.
15(θy)
μA
nm
nm
nm
Electro-Optical Characteristics(MPR)
Item
Symbol
(Ta=25℃)
Characteristics
MPR
TYP.
2.1
Conditions
Unit
Forward Voltage
I
F
=10mA
V
F
MAX.
2.8
20
700
630
100
24(θx)
V
Reverse Current
V
R
=4V
I
R
λ
p
λ
d
⊿λ
MAX.
TYP.
TYP.
TYP.
μA
nm
nm
nm
Peak Wavelength I
F
=10mA
Dominant
I
F
=10mA
Wavelength
Spectral Line Half
I
F
=10mA
Width
Half Intensity
Angle
I
F
=10mA 2θ1/2
TYP.
13(θy)
deg.
2004.10.29
Page 4
5379K Series
Single Color Semi-Round Shape Type
Luminous Intensity Rank
I
V
（
mcd）
Rank
A
B
C
D
E
MBG
MPG
MPY
MAY
MAA
MVR
BR
(Ta=25℃)
MPR
I
F
=20mA
3.0
4.2
6.0
8.4
12.0
6.0
8.4
12.0
16.8
-
I
F
=20mA
12.0
16.8
24.0
33.6
48.0
24.0
33.6
48.0
67.2
-
I
F
=20mA
20
28
40
56
80
40
56
80
112
-
I
F
=20mA
12.0
16.8
24.0
33.6
48.0
24.0
33.6
48.0
67.2
-
I
F
=20mA
12.0
16.8
24.0
33.6
48.0
24.0
33.6
48.0
67.2
-
I
F
=20mA
10
14
20
28
40
20
28
40
56
-
I
F
=20mA
12.0
16.8
24.0
33.6
48.0
24.0
33.6
48.0
67.2
-
I
F
=10mA
1.5
2.1
3.0
4.2
6.0
3.0
4.2
6.0
8.4
-
MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX.
※Please
contact our sales staff concerning rank designation.
2004.10.29
Page 5
