STM8057
SOLID STATE DEVICES, INC.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
Designer's Data Sheet
FEATURES:
• Available Voltages from 96V to 1600V. Consult Factory.
• Meets all Environmental Requirements of Mil-PRF-19500
• Custom Configurations Available
• Reverse Polarity Available (Add Suffix "R")
• 150
o
C Maximum Operating and Storage Temperature
• TX and TXV Level Screening Available
APPLICATIONS:
• Voltage Sensitive Components Protection
• Protection Against High Power Surges
• Lightning Protection
120 kWATTS
840 VOLTS
UNIDIRECTIONAL
TRANSIENT VOLTAGE
SUPPRESSOR
Maximum Ratings
Peak Pulse Power Dissipation
Stand off Voltage
Breakdown Voltage (Minimum)
Clamping Voltage at I
PP
2/
Peak Current
Operating and Storage Temperature
2/
SYMBOL
P
D
V
RWM
V
BR
V
CC
I
PP
Top, Tstg
VALUE
120
800
840
1,000
120
-65 to +150
UNITS
kW
V
W
V
A
o
C
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: TVS002A
STM8057
SOLID STATE DEVICES, INC.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
Electrical Characteristics
Reverse Leakage Current
(V
WM
= 800V, T
A
= 25
o
C, 300
µsec
pulse minimum)
Reverse Leakage Current
(V
WM
= 800V, T
A
= 0
o
C, 300
µsec
pulse minimum)
Breakdown Voltage
(I
BR
= 15mA, T
A
= 25
o
C, 300
µsec
pulse minimum)
Breakdown Voltage
(I
BR
= 15mA, T
A
= 0
o
C, 300
µsec
pulse minimum)
Clamping Voltage
(I
PP
= 120A
(pk)
, t
R
= 10µsec, t
P
= 1000µsec)
Package Outline:
SYMBOL
I
R1
I
R2
V
BR1
V
BR2
V
C
MIN
-
-
840
810
-
MAX
100
200
-
-
1000
UNITS
µΑ
µΑ
V
DC
V
DC
V
(pk)
Note:
This Surface to be Flush to
+.005" underflush with Plane -A-.
100
90
80
70
60
50
40
30
20
10
0
0
tp
1
2
3
4
TIME (ms)
Notes:
1. All voltages are measured with automated test set using 35
msec test time. Longer or shorter test times will have a
corresponding effect on the measured value due to the heat-
ing effects.
2. Current Pulse rises to peak value of I
PP
in 10
µ
sec and
decay to half value, I
PP
/2, in 1msec.
3. Pulse width (t
P
) is defined as the time from peak pulse
current I
PP
to the point where peak pulse current decayed
to 50% of rated I
PP
. (10
µ
sec x 100
µ
sec wave form as
defined by R.E.A.)
% PEAK VALUE
