Product Data Sheet
1 W
ATT
U
NREGULATED
DC/DC C
ONVERTERS
HB01U
APPLICATIONS
G
INDUSTRIAL PROCESS CONTROL
G
DC MOTOR DRIVE
G
INTRINSIC SAFETY SYSTEMS
G
GROUND LOOP ELIMINATION
G
MEDICAL EQUIPMENT
G
PORTABLE TEST EQUIPMENT
G
DATA ACQUISITION
DESCRIPTION
The HB01U Series offers a wide selection of input and
output voltages to choose from. Each model is offered in
a 24-pin DIP or SMD package and has an input to output
isolation rating of 2500Vrms making it ideal for applica-
tions requiring high isolation. The dielectric withstand
characteristics of each converter are measured in pro-
duction to ensure barrier integrity.
The HB01U Series is ideal for applications where the
output is susceptible to high voltage transients, such as
motor drive and industrial process control applications.
The low barrier capacitance gives excellent input to
output dV/dt characteristics thus protecting the input
control circuitry from peak transients appearing on the
output.
The HB01U Series uses a self-oscillating circuit design
technology to realize low cost and high performance. The
inherent current limiting capability of the high isolation
design reduces high current stresses during start-up thus
increasing the capacitive load capability while maintain-
ing high reliability.
As with all of our DC/DC converters, surface mount
construction combined with extensive qualification test-
ing assures low cost without sacrificing quality and reli-
ability.
FEATURES
G
G
G
G
G
G
G
G
G
G
HIGH ISOLATION
2500Vrms ISOLATION TEST VOLTAGE
BARRIER 100% PRODUCTION TESTED
LOW BARRIER CAPACITANCE - 10pF
LOW LEAKAGE CURRENT - 2µA MAX
24-PIN DIP AND SMD
INTERNAL FILTERING
NON-CONDUCTIVE CASE
LOW COST
LOW PROFILE - .375"
Internet: http://www.cdpowerelectronics.com
Power Electronics Division, United States
3400 E Britannia Drive, Tucson, Arizona 85706
Phone: 800.547.2537
Fax: 520.770.9369
HB01U 11/98 REV B
Power Electronics Division, Europe
C&D Technologies (Power Electronics) Ltd.
132 Shannon Industrial Estate, Shannon, Co. Clare, Ireland
Tel: +353.61.474.133
Fax:+353.61.474.141
Page 1
ELECTRICAL SPECIFICATIONS
Specifications typical at T
A
= +25°C, nominal input voltage, rated output current unless otherwise specified.
NOMINAL
INPUT
VOLTAGE
MODEL
HB01U05S05
HB01U05S12
HB01U05S15
HB01U12S05
HB01U12S12
HB01U12S15
HB01U15S05
HB01U15S12
HB01U15S15
HB01U24S05
HB01U24S12
HB01U24S15
HB01U05D05
HB01U05D12
HB01U05D15
HB01U12D05
HB01U12D12
HB01U12D15
HB01U15D05
HB01U15D12
HB01U15D15
HB01U24D05
HB01U24D12
HB01U24D15
(V
DC
)
5
5
5
12
12
12
15
15
15
24
24
24
5
5
5
12
12
12
15
15
15
24
24
24
RATED
OUTPUT
VOLTAGE
(V
DC
)
5
12
15
5
12
15
5
12
15
5
12
15
±5
±12
±15
±5
±12
±15
±5
±12
±15
±5
±12
±15
RATED
OUTPUT
CURRENT
(mA)
200
83
67
200
83
67
200
83
67
200
83
67
±100
±42
±34
±100
±42
±34
±100
±42
±34
±100
±42
±34
INPUT CURRENT
MIN LOAD
(mA)
63
63
63
20
20
20
25
25
25
13
13
13
63
63
63
20
20
20
25
25
25
13
13
13
RATED LOAD
(mA)
290
290
290
120
120
114
98
95
90
61
60
57
290
285
275
123
118
114
98
95
90
61
60
57
EFFICIENCY
(%)
68
70
73
68
70
73
68
70
73
68
70
73
68
70
73
68
70
73
68
70
73
68
70
73
COMMON SPECIFICATIONS
Specifications typical at T
A
= +25°C, nominal input voltage, rated output current unless otherwise specified.
PARAMETER
INPUT
Voltage Range
CONDITIONS
MIN
4.5
10.8
13.5
20
TYP
5
12
15
24
35
MAX
5.5
13.2
16.5
30
UNITS
V
DC
V
DC
V
DC
V
DC
mAp-p
Reflected Ripple Current
ISOLATION
Rated Voltage
Test Voltage
Resistance
Capacitance
Leakage Current
OUTPUT
Rated Power
Voltage Setpoint Accuracy
Temperature Coefficent
Ripple & Noise
Line Regulation
Load Regulation
GENERAL
Switching Frequency
Package Weight
MTTF per MIL-HDBK-217, Rev. F
Ground Benign
TEMPERATURE
Specification
Operation
Storage
60 Hz, 10 Seconds
3535
2500
10
10
1
1
±3
±0.02
50
25
±1.5
VDC
Vrms
GΩ
pF
µArms
W
%
%/°C
mVp-p
mVrms
%/% Vin
V
ISO
= 240V
AC
, 60Hz
2
±5
BW = DC to 10MHz
BW =10Hz to 2MHz
High Line to Low Line
See Performance Curves (Min Load =1mA)
160
12
Circuit Stress Method
T
A
= +25°C
-25
-40
-40
2,000,000
kHz
g
Hr
+70
+85
+110
°C
°C
°C
Page 2
HB01U 11/98 REV B
MECHANICAL
Package/Pinout "Y" and "Z"
SMD PACKAGE
1.285±0.010"
(32.64±0.25)
1514 13
DIP PACKAGE
1.285±0.010"
(32.64±0.25)
2423 22
2423 22
1514 13
0.525±0.010"
(13.34±0.25)
HB01UxxyzzY
TOP VIEWS
0.525±0.010"
(13.34±0.25)
HB01UxxyzzZ
0.695±0.015"
(17.65±0.38)
1 2 3
10 11 12
1 2 3
10 11 12
0.375±0.005"
(9.52±0.13)
0.015±0.005"
(0.38±0.13)
0.020±0.002"
(0.51±0.05)
SIDE VIEWS
0.100±0.010"
(2.54±0.25)
0.375±0.005"
(9.52±0.13)
0.015±0.005"
(0.38±0.13)
0.100±0.010"
(2.54±0.25)
0.020±0.002"
(0.51±0.05)
0°-15°
0.600"
(15.24)
0.125+0.030"
-0.000"
(3.18+0.76)
(
-0.00)
END VIEWS
0.014±0.002"
(0.36±0.05)
.015±.010"
(.38±.25)
NU = Do Not Use.
NC = No Internal Connection.
Duplicate pin functions are internally connected.
All dimensions are in inches (millimeters).
GRID: 0.100 inches (2.54 millimeters)
Typically Marked with: specific model ordered, date code, job code and Logo.
MATERIAL: Units are encapsulated in a low thermal resistance molding
compound which has excellent chemical resistance, wide operating
temperature range, and good electrical properties under high humidity
environments. The encapsulant and outer shell of the unit have UL94V-0
ratings. Lead material is brass with a solder plated surface to allow ease of
solderability.
PIN CONNECTIONS
PIN#
1
2
3
10
11
12
13
14
15
21
22
23
24
SINGLES
+V
OUT
-V
OUT
NU
-V
IN
NC
+V
IN
+V
IN
NC
-V
IN
NC
NU
-V
OUT
+V
OUT
DUALS
+V
OUT
Common
-V
OUT
-V
IN
NC
+V
IN
+V
IN
NC
-V
IN
NC
-V
OUT
Common
+V
OUT
RECOMMENDED LAND PATTERN
0.100"
(2.54)
2423 22
1514 13
RECOMMENDED REFLOW PROFILE
30 sec MAX
(>220°C)
250
235 °C MAX
220
200
190
TEMPERATURE (°C)
0.730"
(18.54)
0.040"
(1.02)
1 2 3
0.080"
(2.03)
150
10 11 12
100
1.150"
(29.21)
90 sec MAX
(>190°C)
50
TIME (seconds)
HB01U 11/98 REV B
Page 3
ABSOLUTE MAXIMUM RATINGS
Internal Power Dissipation...................................................0.5 Watt
Short Circuit Duration...............................................................5 Min
Lead Temperature (soldering, 10 seconds max)..................+300°C
*Note: Refer to Reflow Profile for SMD Models.
ORDERING INFORMATION
HB01U xxyzz Y/Z /H
Device Family
HB Indicates DC/DC Converter
Model Number
Where:
xx = Input Voltage
y = Number or Outputs (Single "S", Dual "D")
zz = Output Voltage
Package Option
Screening Option
*
T
YPICAL PERFORMANCE CURVES
Specifications typical at T
A
= +25°C, nominal input voltage, rated output current unless otherwise specified.
VOUT VS LOAD
(5Vout Models)
5.9
Vout (Volts)
VOUT VS LOAD
(±5Vout Models)
6.0
5.8
5.6
5.4
5.2
5.0
5.7
Vout (Volts)
5.5
5.3
5.1
4.9
1
20
100
80
Load (mA)
150
200
1
20
60
40
Load (mA)
80
100
VOUT VS LOAD
(12Vout Models)
12.7
12.6
Vout (Volts)
VOUT VS LOAD
(±12Vout Models)
12.5
12.4
Vout (Volts)
12.5
12.4
12.3
12.2
1
10
30
50
70
90
12.3
12.2
12.1
12.0
1
5
10
20
30
40
Load (mA)
Load (mA)
VOUT VS LOAD
(15Vout Models)
15.4
15.3
Vout (Volts)
Vout (Volts)
VOUT VS LOAD
(±15Vout Models)
15.4
15.3
15.2
15.1
15.0
14.9
15.2
15.1
15.0
14.9
1
10
20
40
60
67
Load (mA)
1
5
10
20
30
34
Load (mA)
EFFICIENCY VS LOAD
80
Efficiency (%)
70
60
50
40
30
20
40
60
Load (mA)
80
100
The information provided herein is believed to be reliable; however, C&D TECHNOLOGIES assumes no responsibility for inaccuracies or omissions. C&D TECHNOLOGIES assumes no responsibility
for the use of this information, and all use of such information shall be entirely at the user's own risk. Prices and specifications are subject to change without notice. No patent rights or licenses to any
of the circuits described herein are implied or granted to any third party. C&D TECHNOLOGIES does not authorize or warrant any C&D TECHNOLOGIES product for use in life support devices/systems
or in aircraft control applications.
Page 4
HB01U 11/98 REV B
