Attenuators
SMA & 2.92mm
•
•
•
•
•
•
0.5 - 2 Watts
DC - 40.0 GHz
0.5 - 60 dB
Miniature Size
Flat Response
Stainless Steel
General Specifications
Impedance
50 ohms
Body: Plain & Hex
Stainless Steel
Connectors:
SMA or 2.92mm to MIL-C-39012
Stainless Steel
AA03-xxBR SMA Gold Plated Brass
Operating Temperature -55 +125C
(AA03-xxBR -40 +80C)
Power Derating:
Linear to +125C
Model No Freq
(Note 1) Range
(GHz)
AA03-xxBR DC-3.0
AA06-xx
DC-6.0
AA06-xxH DC-6.0
AA18-xxH
AA23-xx
AA26-xx
AA40-xx
AB02-xx
AB06-xx
AB18-xx
Standard
Attenuation
Values
(dB)
1-10, 12, 15, 20
0-10, 12, 15, 20, 30
0-12, 15, 20, 30
Atten
Steps
(dB)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Attenuation Accuracy (+/- dB)
0-6
(dB)
0.3
0.3
0.5
0.3
0.4
0.5
0.8
0.3
0.3
0.3
7-20 21-30 31-40 41-60
(dB) (dB) (dB) (dB)
0.3
0.5
0.5
0.5
0.6
0.6
1.0
0.5
0.5
0.5
VSWR
max.
(Note 2)
Average Power
(watts)
25C
125C
1.0
-
2.0
0.5
2.0
0.5
1.35 (30dB)
2.0
0.5
2.0
0.5
2.0
0.5
0.5
0.1
2.0
0.5
2.0
2.0
0.5
0.5
Figs
Conn.
Type
SMA
SMA
SMA
SMA
SMA
2.92mm
2.92mm
SMA
SMA
SMA
DC-18.0 0-10, 12 15, 20, 30
DC-23.0 0-10, 12, 15, 20, 30
DC-26.5
0, 3, 6, 10, 20, 30
DC-40.0
0, 3, 6, 10, 20, 30
DC-2.5 0-10, 12, 15, 20, 30,
40, 50, 60
DC-6.0 0-10, 12, 15, 20, 30,
40, 50, 60
DC-18.0 0-10, 12, 15, 20, 30,
40, 50, 60
0.5
-
-
1.25
0.75
-
-
1.20
1.20 (0-6dB)
0.75
-
-
1.25 (7-12dB) 1.30 (15, 20dB)
0.75
-
-
1.35
0.80
-
-
1.40
0.80
-
-
1.40
1.00
-
-
1.40
0.75
1.5
1.5
1.15
0.75
0.75
1.5
1.5
1.5
1.5
1.20
1.35
9
1&2
3
1&2
1&2
4&5
6
7&8
7&8
7&8
FIG
Atten.
(dB)
0-12
13-30
0-30
0-12
13-30
0-30
0-30 & 40
31-60 (except 40)
1-20
1
2
3
4
5
6
7
8
9
Dimensions
inches (mm)
Length L
Diameter D
0.86 (21.8)
0.28 (7.1)
0.99 (25.1)
0.28 (7.1)
0.86 (21.8)
0.28 (7.1)
0.88 (22.4)
0.28 (7.1)
1.01 (25.7)
0.28 (7.1)
0.88 (22.4)
0.28 (7.1)
1.21 (30.7)
0.36 (9.1)
1.49 (37.8)
0.36 (9.1)
0.83 (21)
0.31 (7.8)
Styles
Plain
Plain
Plain
Plain
Plain
Plain
Plain
Plain
Plain
Hex
Hex
Hex
Hex
Hex
Hex
Hex
Notes
(1) For complete part number add attenuation
value in place of -XX, e.g. AA06-10 for 10dB.
(2) Max VSWR is shown at highest operating
frequency. VSWR is lower at lower frequencies.
L
D
FEMALE
L
MALE
PLAIN STYLE
Options:
• For Hex version use suffix "H" after model no.
• For single sex versions use suffix "M" (Male) or "F" (Female) after model no.
• Dimensions are for Male/Female connectors. Please ask for size of single
sex versions.
• Between connector series attenuators.
• Custom frequency ranges, specifications and configurations are also available.
D
FEMALE
MALE
HEX STYLE
Outline is a typical illustration only,
for detailed outlines please consult factory
We reserve the right to change standard product specifications without notice but will be pleased to consider control drawings for quotation.
