1 0 0 W Me di cal G rad e Desktop Switch in g P ower Adapter s
mpu100
series
Universal 85-265VAC Input
UL2601, EN60601 Approved
Regulated Outputs
4000V Isolation
IEC320-C14 Input
3.46”W x 7.7”L x2.0”H
model Number
SINGLE OuTpuT
MPU100-102
MPU100-103
MPU100-104
MPU100-105
MPU100-106
MPU100-107
MPU100-108
MPU100-109
MPU100-110
Output Voltage
Output Amps
Regulation
Output Watts Output Connector
5
6
10
12
15
18
24
30
36
14
13.33
9
8.33
6.66
5.55
4.16
3.33
2.77
5%
5%
4%
3%
3%
3%
2%
2%
2%
70W
80W
90W
100W
100W
100W
100W
100W
100W
8 Pin DIN
8 Pin DIN
5 Pin DIN
5 Pin DIN
5 Pin DIN
5 Pin DIN
2.1mm Coax
2.1mm Coax
2.1mm Coax
Order On-Line!
WWW.ASTRODYNE.COm
astrodyne.com
300 myles Standish Blvd., Taunton, mA 02780
ph: 1-800-823-8082
Fax: 508-823-8181
1 0 0 W Me di cal G rad e Desktop Switch in g P ower Adapter s
mpu100
series
Universal 85-265VAC Input
UL2601, EN60601 Approved
Regulated Outputs
4000V Isolation
IEC320-C14 Input
3.46”W x 7.7”L x2.0”H
model Number
DuAL OuTpuT
MPU100-200
MPU100-201
MPU100-202
MPU100-203
MPU100-204
MPU100-209
MPU100-210
MPU100-212
MPU100-215
TRIpLE OuTpuT
MPU100-300
MPU100-301
MPU100-302
MPU100-303
MPU100-304
MPU100-305
MPU100-306
MPU100-308
Output Voltage
Output Amps
Regulation
Output Watts Output Connector
3.3/12
5/12
5/15
5/24
3.3/5
+/-12
+/-15
24/-24
5/-24
3.3,+/-12
5/12/-5
5,+/-12
5,+/-15
5,+/-24
5/24/-12
3.3/12/-5
3.3/5/-12
10/3
10/3
10/3
10/2
10/5
7/1
6/1
3/1
5/1
10/3/1
10/3/1
10/3/1
10/3/1
10/3/1
10/3/1
10/3/1
10/3/1
7/5%
5/5%
5/6%
5/5%
7/5%
5/5%
5/5%
5/5%
5/5%
7/5/5%
5/5/5%
5/5/5%
5/6/5%
5/5/5%
5/5/5%
7/5/5%
7/5/5%
69W
80W
80W
80W
55W
80W
80W
80W
74W
80W
80W
80W
80W
74W
74W
60W
60W
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
5 Pin DIN
5 Pin DIN
5 Pin DIN
5 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN
Order On-Line!
WWW.ASTRODYNE.COm
astrodyne.com
300 myles Standish Blvd., Taunton, mA 02780
ph: 1-800-823-8082
Fax: 508-823-8181
1 0 0 W Me di cal G rad e Desktop Switch in g P ower Adapter s
INpuT SpECIFICATIONS
Input Voltage Range
Frequency Range
Leakage Current
85-265 VAC
47-63 Hz
0.1mA typ. @ 240VAC
mpu100
series
ENVIRONmENTAL SpECIFICATIONS
Oper. Temperature
Storage Temperature
Relative Humidity
MTBF
EMC
0 to +70°C
See Derate Curve
-40 to +85°C
*
5 to + 95%, non-cond
*
100,000 Hrs
Vin = 220VAC
CISPR-11 B
Vin = 110VAC
FCC Part 18 B
OuTpuT SpECIFICATIONS
Voltage and Current
Load Regulation
Line Regulation
Ripple/Noise
Hold Up Time
See Selection Charts
See Selection Charts
+/- 0.5%, typ (1% Max.)
0.5% Pk-Pk, typ (1% Max.)
16mS min. at 110VAC Input
OuTpuT DERATING CuRVE
GENERAL SpECIFICATIONS
Input-Output Isolation
Efficiency
Safety
4000VAC
70% min.
UL60601-1, EN60601-1
pHYSICAL SpECIFICATIONS
Size
Construction
Weight
7.7” x 3.46” x 2.0”
Desktop Style
1.7 (771g)
All specifications are typical at nominal input, full load, and 25°C unless other-
wise noted
*
These are stress ratings. Exposure of the devices to any of these conditions
may adversely affect long term reliability. Proper operation under conditions
other than the standard operating conditions is neither warranteed nor implied.
Astrodyne products are not authorized or warranteed for use
as critical components in life support systems, equipment used
in hazardous environments, nuclear controls systems, or other
mission-critical applications.
WWW.ASTRODYNE.COm
300 myles Standish Blvd., Taunton, mA 02780
ph: 1-800-823-8082
Fax: 508-823-8181
1 0 0 W Me di cal G rad e Desktop Switch in g P ower Adapter s
mECHANICAL DImENSIONS
Output Cord Length 72” typ.
H
mpu100
series
Input Connection
W
DC Output Connections
DIN Connector
Single Output
1. COM
2. COM
3. Vout
4. COM
5. Vout
6. COM
7. Vout
8. Vout
Shell = GND
Dual Output
1. COM
2. Vout2
3. Vout1
4. Vout2
5. Vout1
6. COM
7. Vout1
8. COM
Shell = GND
Triple Output
1. Vout1
2. COM
3. Vout3
4. Vout1
5. Vout2
6. Vout1
7. COM
8. COM
Shell = GND
Coaxial plug:
5.5mm outer diameter
2.1mm inner diameter, female
11mm length, center “+”
-Vout
+Vout
8 pin DIN
5 pin DIN
1
4
5
2
3
1. COM
2. COM
3. Vout
4. COM
5. Vout
Shell = GND
1. COM
2. COM
3. Output #1
4. No Connection
5. Output #2
Shell = GND
1. COM
2. COM
3. Output #1
4. Output #3
5. Output #2
Shell = GND
WWW.ASTRODYNE.COm
300 myles Standish Blvd., Taunton, mA 02780
ph: 1-800-823-8082
Fax: 508-823-8181
