583679-1 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> 583679-1

Preview

583679-1: DescriptionCONNECTOR, 52 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER; CategoryThe connector The connector; File Size325KB，7 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

583679-1 Overview

CONNECTOR, 52 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER

583679-1 Parametric

Parameter Name	Attribute value
Maker	TE Connectivity
Reach Compliance Code	unknown
Is Samacsys	N
Other features	AMP-LEAF
Connector type	CARD EDGE CONNECTOR
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	583679
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Terminal pitch	3.17 mm
Termination type	SOLDER
Total number of contacts	52
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

583679-1 Related Products

	583679-1	1-583692-9	1-583679-4	2-583692-7	2-583692-6	4-583679-4	4-583692-2	583679-3
Description	CONNECTOR, 52 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER	CONNECTOR, 40 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER	CONNECTOR, 30 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER	CONNECTOR, 56 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER	CONNECTOR, 54 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER	CONNECTOR, 92 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER	CONNECTOR, 88 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER	CONNECTOR, 8 CONTACT(S), FEMALE, VERTICAL SINGLE PART CARD EDGE CONN, SOLDER
Reach Compliance Code	unknown	unknow	unknown	unknown	unknown	unknown	unknown	unknown
Other features	AMP-LEAF	AMP-LEAF	AMP-LEAF	AMP-LEAF	AMP-LEAF	AMP-LEAF	AMP-LEAF	AMP-LEAF
Connector type	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
DIN compliance	NO	NO	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	583679	583692	583679	583692	583692	583679	583692	583679
Mixed contacts	NO	NO	NO	NO	NO	NO	NO	NO
Installation method	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of rows loaded	2	2	2	2	2	2	2	2
Terminal pitch	3.17 mm	3.81 mm	3.17 mm	3.81 mm	3.81 mm	3.17 mm	3.81 mm	3.17 mm
Termination type	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER
Total number of contacts	52	40	30	56	54	92	88	8
UL Flammability Code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Base Number Matches	1	1	-	1	1	1	1	1
