STANDARD POWER INDUCTORS - SURFACE MOUNT
GP3042
TRADITIONAL
Pb
GP3042LF
*
PART
NUMBER
GP3042-1R2M
GP3042-2R2M
GP3042-3R3M
GP3042-4R7M
GP3042-6R8M
GP3042-100M
GP3042-120M
GP3042-150M
GP3042-180M
GP3042-220M
GP3042-270M
GP3042-330M
GP3042-390M
GP3042-470M
GP3042-560M
GP3042-680M
GP3042-820M
GP3042-101M
COMPLIANT
RoHS
Wirewound, Shielded
L
µH
1.2
2.2
3.3
4.7
6.8
10
12
15
18
22
27
33
39
47
56
68
82
100
TEST
FREQ
KHz
100
100
100
100
100
100
1
1
1
1
1
1
1
1
1
1
1
1
MAX
SRF
MHz
TYP
120
77
65
55
45
37
34
30
28
25
21
18
17
16
15
14
12
11
DCR
OHMS
MAX
0.019
0.023
0.032
0.045
0.060
0.083
0.100
0.115
0.150
0.160
0.190
0.215
0.290
0.320
0.365
0.480
0.520
0.700
0.185 ± 0.012
(4.7 ± 0.3)
CURRENT
RATING
A DC MAX
1.80
1.35
1.10
0.90
0.73
0.58
0.53
0.46
0.42
0.38
0.35
0.32
0.30
0.28
0.25
0.22
0.20
0.12
FERRITE CORE/FERRITE SLEEVE
All part numbers provide 20% tolerance on inductance
0.115
Custom designs are available to meet your specific requirements; please
(2.92)
factory
contact
*Add “LF” suffix for RoHS requirement. Example: GP3042-1R2MLF
(4.7 ± 0.3)
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
0.185 ± 0.012
NOTES:
TOP VIEW
0.115
(2.92)
MAX
0.185 ± 0.012
(4.7 ± 0.3)
BOTTOM VIEW
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C maximum
temperature rise, 10% maximum decrease in
inductance, at an ambient temperature of 25°C
• Terminals are solderable - more than 95% new
solder coverage when subjected to soldering
temperature
• Application Frequency Range:
To 1.0 MHz MIN (for L values 1.2 µH -
10 µH)
To 300 kHz MIN (for values > 10 µH)
• Weight maximum 0.85 grams
0.185 ± 0.012
(4.7 ± 0.3)
0.100
(2.54)
REF
0.065
(1.65)
REF
in. (mm)
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
500
8 mm
12 mm
13 in.
0.100
(2.54)
REF
