MSM80C51F-1XXXJS: DescriptionMicrocontroller, 8-Bit, MROM, 16MHz, CMOS, PQCC44, 0.650 INCH, PLASTIC, LCC-44; CategoryThe embedded processor and controller Microcontrollers and processors; File Size813KB，35 Pages; ManufacturerOKI; Websitehttp://www.oki.com

Download Datasheet Parametric Compare View All

MSM80C51F-1XXXJS Overview

Microcontroller, 8-Bit, MROM, 16MHz, CMOS, PQCC44, 0.650 INCH, PLASTIC, LCC-44

MSM80C51F-1XXXJS Parametric

Parameter Name	Attribute value
Parts packaging code	LCC
package instruction	QCCJ,
Contacts	44
Reach Compliance Code	unknown
Is Samacsys	N
Has ADC	NO
Address bus width	16
bit size	8
maximum clock frequency	16 MHz
DAC channel	NO
DMA channel	NO
External data bus width	8
JESD-30 code	S-PQCC-J44
length	16.59 mm
Number of I/O lines	32
Number of terminals	44
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
PWM channel	NO
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Certification status	Not Qualified
ROM programmability	MROM
Maximum seat height	4.55 mm
speed	16 MHz
Maximum supply voltage	6 V
Minimum supply voltage	2.5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
width	16.59 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1
